火焰筒切向进气发散小孔冷却数值模拟

汪涛; 索建秦; 梁红侠; 王蓉隽

火焰筒切向进气发散小孔冷却数值模拟

西北工业大学动力与能源学院,西安 710072

计量
- 文章访问数: 1627
- HTML浏览量: 1
- PDF量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-06
- 修回日期: 2010-08-26
- 刊出日期: 2011-05-28

Numerical study of tangential effusion cooling for combustor liner

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 针对发动机燃烧室由于高温升和低污染而使可用冷却空气大量减少的技术难题,设计了一套切向进气发散小孔的单管燃烧室模型.使用热流固耦合方法,通过对Navier-Stokes(N-S)方程的求解,对其流场特性和火焰筒壁温进行了数值模拟研究.计算在三维坐标系下,采用拉格朗日法计算燃油颗粒的轨迹,非预混模型计算燃烧,离散坐标模型计算辐射,使用标准k-ε湍流模型,在固壁附近运用壁面函数法,计算了两种工况的火焰筒壁温分布.结果表明,在燃烧室总油气比为0.046,冷却空气质量分数为30%,进口空气总温为830K,总压为3MPa工况下,燃烧室最高壁温为1015K,温度梯度最大为22.5K/cm,完全满足推质比为12一级的军用发动机和民用发动机对燃烧室火焰筒在冷却空气质量分数为30%、总油气比为0.046条件下对于壁温的要求.
- 燃烧室 /
- 火焰筒 /
- 冷却 /
- 发散小孔 /
- 高温升 /
- 低污染燃烧
Abstract: To solve technical difficulties resulting from high temperature rise and low emission of new generation engine combustor,a single tube combustor model with tangential effusion cooling technology was designed.Numerical simulation was conducted to study the flow field characteristics and wall temperature distribution of combustor liner by solving Navier-Stokes (N-S) equations with thermal fluid-solid coupling method.The liner wall temperature distribution was computed under two conditions by three-dimensional coordinate system,the fuel particle trajectory by Lagrange method,the combustion by non-premixed model,the radiation by discrete ordinates model,the turbulence by the standard k-ε model,and the neighborhood of the solid wall by the wall-function.The results show that,at the 0.046 fuel-air ratio condition,30% cooling air mass fraction,830K inlet air total temperature and 3MPa inlet air total pressure,the maximum wall temperature is 1015K and the maximum temperature gradient is 22.5K/cm,which meet the need of wall temperature level for 12 thrust-mass ratio military engines and low emission civil engines at 30% cooling air mass fraction,and 0.046 fuel-air ratio condition.
- combustor /
- liner /
- cooling /
- effusion hole /
- high temperature rise /
- low emission combustion

HTML

参考文献(14)

[1]	左渝钰,张宝诚.航空发动机主燃烧室火焰筒壁冷却的研究[J].航空发动机,2002(4):38-43. ZUO Yuyu,ZHANG Baocheng.Investigation of combustion liner wall cooling in gas turbine combustor[J].Aeroengine,2002(4):38-43.(in Chinese)
[2]	李彬,吉洪湖,江义军.浮动壁火焰筒壁温试验和计算分析[J].南京航空航天大学学报,2007,39(6):771-772. LI Bin,JI Honghu,JIANG Yijun.Experimental and numerical analysis of temperature distribution on floating-wall flame tube of combustor[J].Journal of Nanjing University of Aeronautics and Astronautics,2007,39(6):771-772.(in Chinese)
[3]	金如山,金捷.燃气轮机燃烧室火焰筒先进冷却技术综述[J].燃气涡轮试验与研究,1992(2):2-5.
[4]	Mayle R E,Camarata F J.Multihole cooling film effectiveness and heat transfer[J].ASME Transactions Journal of Heat Transfer,1975,97(4):534-538.
[5]	Bazdidi T F,Andrews G E.Full-coverage discrete hole film cooling:investigation of the effect of variable density ratio[J].ASME Transactions Journal of Engineering for Gas Turbines and Power,1994,116(3):587-596.
[6]	Le Brocq P V,Launder B E,Priddin C H.Discrete hole injection as a means of transpiration cooling:an experimental study[J].Proceedings of the Institution of Mechanical Engineers,1973,187:149-157.
[7]	Goldstein R J.Film cooling[J].Advances in Heat Transfer,1971,7:321-379.
[8]	宋波,林宇震,刘高恩,等.不同排列方式多斜孔壁气膜冷却绝热温比研究[J].航空动力学报,1999,14(1):91-94. SONG Bo,LIN Yuzhen,LIU Gaoen,et al.An investigation on film cooling effectiveness of inclined-multihole walls with different patterns[J].Journal of Aerospace Power,1999,14(1):91-94.(in Chinese)
[9]	赵梦梦,张弛,林宇震,等.弯曲多孔壁不同倾斜角气膜孔整体气膜冷却效率研究[J].航空动力学报,2007,22(2):210-215. ZHAO Mengmeng,ZHANG Chi,LIN Yuzhen,et al.Study of overall cooling effectiveness of discrete holes with different angles to concave wall[J].Journal of Aerospace Power,2007,22(2):210-215.(in Chinese)
[10]	SUO Jianqin,LIANG Hongxia,Chin J S.Study on gas turbine combustor cooling calculation .AIAA-2009-5292,2009.
[11]	张川,索建秦,金如山.民用飞机低污染燃烧室的技术成熟度划分[J].航空工程进展,2010,1(1):85-89. ZHANG Chuan,SUO Jianqin,JIN Rushan.Technology readiness level scale for low emission combustor of civil aircraft[J].Advances in Aeronautical Science and Engineering,2010,1(1):85-89.(in Chinese)
[12]	赵琳,胡江峰,刘振侠.流-固耦合计算的应用研究[J].沈阳航空工业学院学报,2006,23(4):55-56. ZHAO Lin,HU Jiangfeng,LIU Zhenxia.The research of liquid-solid coupled solution[J].Journal of Shenyang Institute of Aeronautical Engineering,2006,23(4):55-56.(in Chinese)
[13]	胡好生,蔡文祥,赵坚行.回流燃烧室燃烧过程的三维数值模拟[J].航空动力学报,2008,23(3):454-458. HU Haosheng,CAI Wenxiang,ZHAO Jianxing.Numerical simulation of three-dimensional combustion flows in annular reversed combustor[J].Journal of Aerospace Power,2008,23(3):454-458.(in Chinese)
[14]	Sparrow E M,Ortiz M C.Heat transfer coefficients for the upstream face of a perforated plate positioned normal to an oncoming flow[J].International Journal of Heat and Mass Transfer,1982,25(1):127-135.
