轴向间距对某跨声速轴流压气机叶排间干扰的影响规律

史亚锋; 吴虎; 陈立新; 王征; 杨金广; 李密

轴向间距对某跨声速轴流压气机叶排间干扰的影响规律

1.
西北工业大学动力与能源学院, 西安 710072
2.
河南省电力公司河南省电力勘测设计院,郑州 450007

计量
- 文章访问数: 1567
- HTML浏览量: 4
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-29
- 修回日期: 2010-09-03
- 刊出日期: 2011-05-28

Effect of different axial spacing between blade rows on transonic axial compressor performance

1.
School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072
2.
Henan Electric Power Survey and Design Institute, Electric Power of Henan, Zhengzhou 450007, China

摘要

摘要: 对不同轴向间距下的某跨声速轴流压气机内流场在设计转速时进行了定常数值模拟,结果表明当转子与上游静子轴向间距减小时,压气机的效率和压比有明显降低,而转子和下游静子间距减小时,压气机的效率和压比反而有所提高.进一步的非定常数值模拟结果表明:①转子与上游静子轴向间距减小时,转子前激波与静子尾缘干扰增强,造成了效率和压比的下降;②转子与下游静子轴向间距减小时,由于转子尾迹通过静子叶排时的恢复效应,由尾迹造成的掺混损失会减小,效率和压比会有所提高.
- 轴向间距 /
- 压气机 /
- 叶排 /
- 干扰 /
- 尾迹
Abstract: The steady flow field of a transonic axial compressor under design rotation speed was numerically simulated,proving that the close spacing between upstream stator and rotor can largely reduce the efficiency and pressure ratio,however the close spacing between rotor and downstream stator can improve the efficiency and pressure ratio.The unsteady numerical simulation indicates: (1) the close spacing between upstream stator and rotor can enlarge the interaction of rotor shock on the stator wake,causing the deterioration of performance; (2) the wake recovery effect under the close spacing between rotor and downstream stator decreases the mixing loss,thus slightly improving the performance.
- axial spacing /
- compressor /
- blade rows /
- interaction /
- wake

HTML

参考文献(14)

[1]	Gorrell S E,Okiishi T H,Copenhaver W W.Stator-rotor interactions in a transonic compressor Part 1:effect of blade-row spacing on performance[J].ASME Journal of Turbomachinery,2003,125(2):328-335.
[2]	Van Zante D E,Adamczyk J J.Wake recovery performa-nce benefit in a high-speed axial compressor[J].ASME Journal of Turbomachinery,2002,124(2):275-284.
[3]	Adamczyk J J.Wake mixing in axial flow compressors .ASME Paper 1998-GT-29,1998.
[4]	Denton J D.Loss mechanisms in turbomachines[J].ASME Journal of Turbomachinery,1993,115(4):621-656.
[5]	Ottavy X,Trébinjac I,Vouillarmet A.Analysis of the interrow flow field within a transonic axial compressor Part 1:experimental investigation[J].ASME Journal of Turbomachinery,2001,123(1):49-56.
[6]	Ottavy X,Trébinjac I,Vouillarmet A.Analysis of the interrow flow field within a transonic axial compressor Part 2:unsteady flow analysis[J].ASME Journal of Turbomachinery,2001,123(1):57-63.
[7]	Gorrell S E,Okiishi T H,Copenhaver W W.Stator-rotor interactions in a transonic compressor Part 2:effect of blade-row spacing on performance[J].ASME Journal of Turbomachinery,2003,125(2):336-345.
[8]	党政,席光,王尚锦.轴向间隙对动/静相干叶排内部非定常特性的影响[J].工程热物理学报,2000,21(5):584-586. DANG Zheng,XI Guang,WANG Shangjin.Axial spacing effects on unsteady rotor/stator interaction flow[J].Journal of Engineering Thermophysics,2000,21(5):584-586.(in Chinese)
[9]	闫朝,季路成,陈江.叶排间轴向间距对时序效应影响的数值研究[J].推进技术,2004,25(5):417-420. YAN Chao,JI Lucheng,CHEN Jiang.Numerical invest-igations for the influence of the axial gap on the use of clocking effect[J].Journal of Propulsion Technology,2004,25(5):417-420.(in Chinese)
[10]	李传鹏,胡骏,张燎原,等.轴向间距变化对轴流压气机全流量特性的影响[J].推进技术,2004,25(6):508-511. LI Chuanpeng,HU Jun,ZHANG Liaoyuan,et al.Effects of axial spacing on compressor performance in all flow range[J].Journal of Propulsion Technology,2004,25(6):508-511.(in Chinese)
[11]	张环,胡骏,李传鹏,等.轴向间距对压气机气动稳定性的影响[J].航空动力学报,2005,20(1):120-124. ZHANG Huan,HU Jun,LI Chuanpeng,et al.Effect of axial spacing between rotor and stator on axial compressor stability[J].Journal of Aerospace Power,2005,20(1):120-124.(in Chinese)
[12]	Sanger N L.Performance of a 1.57-pressure-ratio transonic fan stage with a screen-induced 90° circumferential inlet flow distortion .NASA TN-D8163,1975.
[13]	Gorrell S E,Copenhaver W W,Chriss R M.Upstream wake influences on the measured performance of a transonic compressor stage[J].AIAA Journal of Propulsion and Power,2001,17(1):43-48.
[14]	Smith L H,Jr.Wake ingestion propulsion benefit[J].AIAA Journal of Propulsion and Power,1993,9(1):74-82.
