一种改进的压气机叶尖泄漏流堵塞预估模型及数值验证

程朝青; 崔健; 李志平; 龚一方; 李秋实

一种改进的压气机叶尖泄漏流堵塞预估模型及数值验证

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

基金项目: 国家自然科学基金(10902008,50906001)

计量
- 文章访问数: 1772
- HTML浏览量: 155
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-23
- 修回日期: 2010-11-09
- 刊出日期: 2011-05-28

Modified blockage model of tip leakage flow and its validation

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 基于压气机叶尖间隙内的流动为Couette流动的实际情况,改进了适用于低速压气机的麻省理工学院Khalid叶尖泄漏堵塞预估模型;同时考虑叶尖泄漏流经过激波后堵塞迅速增加,发展了适用于跨声速压气机的叶尖泄漏流堵塞预估模型.对某低速轴流压气机单转子、跨声压气机单转子进行全三维黏性数值模拟,将计算得到的叶尖泄漏堵塞量与模型预测得到的堵塞量进行对比,结果表明此模型较Khalid模型能够更加准确地预测低速压气机的堵塞,同时能够用于预测跨声压气机叶尖泄漏流堵塞.
- 压气机 /
- 叶尖间隙 /
- 泄漏流 /
- 泄漏涡 /
- 堵塞
Abstract: Based on the common cognition of the tip clearance flow,which has a significant influence on compressor performance and MIT (Massachusetts Institute of Technology) Khalid tip leakage model,a blockage model of tip leakage flow in the condition of low-speed and transonic was deduced in this paper.With analysis of the real flow case in tip clearance and diffusion passage,the aerodynamic design parameters,such as loading,cord length,etc,on the rotor tip and the influence of shock wave on tip leakage loss were analyzed in this model.The three-dimensional numerical simulation results show that this model can track the behaviors of jam resulted from compressor tip clearance flow.
- compressor /
- tip clearance /
- leakage flow /
- leakage vortex /
- blockage

HTML

参考文献(12)

[1]	Stauter R C.Measurement of the three-dimensional tip region flow field in an axial compressor[J].ASME Journal of Turbomachinery,1993,115(3):468-476.
[2]	Foley A C,Ivey P C.Measurement of tip-clearance flow in a multistage,axial flow compressor[J].ASME Journal of Turomachinery,1996,118(2):211-217.
[3]	Rains D A.Tip clearance flows in axial flow compressors and pumps .Pasadena,California:California Institute of Technology,1954.
[4]	Chen G T,Greitzer E M,Tan C S,et al.Similarity analysis of compressor tip clearance flow structure[J].ASME Jounral of Turbomachinery,1991,113(2):260-271.
[5]	杨策,马朝臣,王延生,等.透平机械叶尖间隙流场研究的进展[J].力学进展,2001,31(1):70-83. YANG Ce,MA Chaochen,WANG Yansheng,et al.A review of studies on turbomachinery tip gap leakage flow[J].Advances in Mechanics,2001,31(1):70-83.(in Chinese)
[6]	Khalid S A,Khalsa A S,Waitz I A,et al.Endwall blockage in axial compressors[J].ASME Journal of Turbomachinery,1999,121(3):499-509.
[7]	Khalid S A.The effects of tip clearance on axial compressor pressure rise .Massachusetts:Massachusetts Institute of Technology,1995.
[8]	Kang S,Hirsch C.Numerical simulation of three-dimensional viscous flow in a linear compressor cascade with tip clearance[J].ASME Journal of Turbomachinery,1996,118(3):492-505.
[9]	Inoue M,Kuroumaru M,Fukuhara M.Behavior of tip leakage flow behind an axial compressor rotor[J].ASME Journal of Engineering for Gas Turbines and Power,1986,108(1):7-14.
[10]	Lakshminarayana B,Zaccaria M,Marathe B.The structure of tip clearance flow in axial flow compressors[J].ASME Journal of Turbomachinery,1995,117(3):336-347.
[11]	陈懋章,粘性流体力学基础[M].北京:高等教育出版社,2002.
[12]	Storer J A,Cumpsty N A.Tip leakage flow in axial compressors[J].ASME Journal of Turomachinery,1991,113(2):252-259.
