某超高速转子系统减振结构研究

陈巍; 杜发荣; 丁水汀; 韩树军; 李云清

某超高速转子系统减振结构研究

1.
中国科学院工程热物理研究所,北京 100190
2.
北京航空航天大学交通科学与工程学院,北京100191

基金项目: 国家985工程项目

计量
- 文章访问数: 1658
- HTML浏览量: 3
- PDF量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-16
- 修回日期: 2010-07-01
- 刊出日期: 2011-05-28

Research on vibration absorber for a super-high speed rotor system

1.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China
2.
School of Transportation Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为解决某超高速转子系统的失稳碰摩问题,以干摩擦阻尼耗散转子涡动能量理论为依据,采用一种自由安装式干摩擦片减振结构(干摩擦阻尼器).该结构在转轴上安装波形弹性垫片及干摩擦片,通过螺母预紧力矩向波形弹性垫片及各干摩擦片提供轴向正压力.干摩擦片随转子振动并产生相对运动,从而耗散转子涡动能量,达到减振、增强转子稳定性的目的.通过实验不同数量的干摩擦片和不同预紧力矩的组合寻找满足工程稳定性的减振器结构参数.结果表明:干摩擦阻尼器适用于高速、轻载转子系统的减振、增稳,可以有效降低转子振动,控制转子涡动发散的趋势;所用实验方法有助于快速获得满足工程稳定性的减振结构参数.
- 超高速转子 /
- 减振结构 /
- 干摩擦阻尼器 /
- 稳定性 /
- 转子振动
Abstract: A kind of freely assembled dry friction vibration absorber was presented to solve the problems of instability and rubbing faults for a super-high speed rotor system based on theory of dry friction dissipating energy from rotor vibration.In this structure,a wave-shaped elastic pad and some dry friction pads were freely assembled on shaft,and axial normal force was provided for elastic pad and dry friction pads by pre-loaded moment for nut.When friction pads moved with shaft,the relative movements between them could dissipate vibration energy from rotor system,absorb vibration and enhance system stability.The configuration format meeting the stability in engineering for the damper of the studied rotor system has been acquired by testing different groups of dry friction pads and pre-loaded moment.The results show that dry friction damper is suitable for high speed and light loaded rotor system to restrain vibration and enhance its stability.The testing routine is helpful to find a comfortable configuration format in engineering of dry friction damper.
- super-high speed rotor /
- vibration absorber /
- dry friction damper /
- stability /
- rotor vibration

HTML

参考文献(13)

[1]	范天宇.弹性支撑干摩擦阻尼器减振研究 .西安:西北工业大学,2006. FAN Tianyu,Vibratiom reduction by elastic support dry friction damper .Xi'an:Northwestern Polytechnical University.2006.(in Chinese)
[2]	周年发.某型发动机的减振与监控方法分析[J].航空发动机,2007(增刊):23-27. ZHOU Nianfa.Analysis for a engine vibration reduction and detection method[J].Aeroengine,2007(supplement):23-27.(in Chinese)
[3]	何衍宗.柔性转子受简谐扭矩激励时的涡动[J].振动工程学报,1991,4(3):1-9. HE Yanzong.Whirling of a flexible rotor excited by harmonic torque[J].Journal of Vibration Engineering,1991,4(3):1-9.(in Chinese)
[4]	闻邦椿,顾家柳,夏松波,等.高等转子动力学[M].北京:机械工业出版社,2000.
[5]	Rodriguez C G,Egusquiza E,Santos I F.Frequencies in the vibration induced by the rotor stator interaction in a centrifugal pump turbine[J].Journal of Fluid Engineering,2007,129(11):1428-1435.
[6]	Green I,Casey C.Crack detection in a rotor dynamic system by vibration monitoring Part Ⅰ:analysis[J].Journal of Engineering for Gas Turbines and Power,2005,127(2):425-436.
[7]	夏兆旺,单颖春,刘献栋,等.颗粒阻尼应用于平板叶片减振试验[J].振动测试与诊断.2008,30(3):269-272. XIA Zhaowang,SHAN Yingchun,LIU Xiandong,et al.Particle damping tests on cast steel plates[J].Journal of Vibration,Measurement & Diagnosis,2008,30(3):269-272.(in Chinese)
[8]	Lopez I,Busturia J M,Nijmeijer H.Energy dissipation of a friction damper[J].Journal of Sound and Vibration,2004,278(3):539-561.
[9]	Den Hartog J P.Forced vibrations with combined coulomb and viscous friction[J].Applied Mechan.J.AMSE,1931,53:107-115.
[10]	Pratt T K,Williams R.Nonlinear analysis of stick/slip motion[J].Journal of Sound and Vibration,1981,74(4):531-542.
[11]	Akay A.Acoustics of friction[J].Journal of the Acoustical Society of America,2002,11(4):1525-1548.
[12]	Beards C F,WoowatA.The control of frame vibration by friction damping in joints[J].Journal of Vibration,Acoustics Stress and Reliability in Design,1985,107(1):27-32.
[13]	Deimling K,Szilgyi P.Periodic solutions of dry-friction problems[J].Zeitschrift für Angewandte Mathematik und Physik(ZAMP),1994,45(1):53-60.
