基于离散单元法的二维颗粒阻尼研究

唐伟; 王延荣; 王相平; 杨剑秋

基于离散单元法的二维颗粒阻尼研究

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司沈阳航空发动机设计研究所,沈阳 110015

基金项目: 国家重点基础研究发展计划(2007CB210103)

计量
- 文章访问数: 1692
- HTML浏览量: 111
- PDF量: 18
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-17
- 修回日期: 2010-08-07
- 刊出日期: 2011-05-28

Numerical study of particle damping in two dimensions by use of discrete element method

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Shenyang Aeroengine Research Institute, Aviation Industry Corporation of China, Shenyang 110015, China

摘要

摘要: 针对自由端带空腔的L型悬臂梁建立了二维颗粒阻尼物理模型,发展并利用离散单元法(DEM)对二维颗粒阻尼进行了数值仿真,重点考查了二维空腔尺寸对颗粒阻尼的影响规律:①高度非线性的颗粒阻尼能够显著地抑制结构振动,阻尼值至少比金属材料阻尼大一个数量级;②当无量纲加速度Γ<1时,颗粒阻尼很小;当Γ>1时,随Γ增加,颗粒阻尼先增大后减小,即存在临界无量纲加速度使得阻尼最大;③颗粒阻尼的峰值随水平无量纲碰撞间隙的增加而增大,并向Γ减小方向略微偏移;而随垂直无量纲碰撞间隙增加,该峰值也增大,但却向Γ增大方向偏移.所发展方法的计算值与实验结果吻合很好,可用于颗粒阻尼器的设计及应用.
- 颗粒阻尼 /
- 离散单元法 (DEM) /
- 振动抑制 /
- 空腔尺寸 /
- 非线性阻尼
Abstract: The physical model of particle damping in two dimensions was developed for the cavity with particles inside located at the free end of an L-shaped beam,and discrete element method (DEM) was used to investigate the effects of two-dimensional cavity sizes on particle damping.The results show that: (1) the highly nonlinear particle damping,which is at least one order of magnitude higher than the intrinsic material damping of metals,can significantly suppress the vibration of structures;(2) when dimensionless acceleration amplitude Γ<1,particle damping is very small;however,when Γ>1,it firstly increases and then decreases with the increase of Γ,indicating that there is a critical dimensionless acceleration amplitude for the highest damping;(3) the peak value of particle damping increases and appreciably shifts to the lower Γ with the increase of horizontal dimensionless impact clearance.However,it also increases but shifts to a higher Γ with the increase of vertical dimensionless impact clearances.The simulation results agree well with the experimental data,and can be applied to the practical design of a particle damper.
- particle damping /
- discrete element method (DEM) /
- vibration suppression /
- cavity size /
- nonlinear damping

HTML

参考文献(19)

[1]	张锦,刘晓平.叶轮机械振动模态分析理论及数值方法[M].北京:国防工业出版社,2001.
[2]	Hollkamp J J,Gordon R W.Experiment with particle damping //Proceedings of SPIE Conference on Smart Structures and Materials:Passive Damping and Isolation.San Diego,CA:SPIE,1998,3327:2-12.
[3]	Panossian H V.An overview of NOPD:a passive damping technique[J].Shock and Vibration,1991,1(6):4-10.
[4]	Kielb R,Macri F,Oeth D,et al.Advanced damping system for fan and compressor blisk AIAA-98-3863,1998.
[5]	Fowler B L.Multiparticle impact damping(MPID) design methodology for extreme environments .Mountain View,CA:CAS Engineering Inc.,2003.
[6]	Flint E M.Experimental measurements of the particle damping effectiveness under centrifugal loads //Proceedings of the 4th National Turbine Engine High Cycle Fatigue Conference.Los Angeles,CA: ,1999,61:1-6.
[7]	Friend R D,Kinra V K.Particle impact damping[J].Journal of Sound and Vibration,2000,233(1):93-118.
[8]	Bhatti R A,WANG Yanrong,WANG Zhoucheng.Particle impact damping in two dimensions[J].Journal of Key Engineering Materials,2009,413-414:415-422.
[9]	Saeki M.Impact damping with granular material in a horizontally vibrating system[J].Journal of Sound and Vibration,2002,251(1):153-161.
[10]	Saeki M.Analytical study of multi-particle damping[J]. Journal of Sound and Vibration,2005,281(3-5):1133-1144.
[11]	Bai X M,Shah B,Keer L M,et al.Particle dynamics simulations of a piston-based particle damper[J].Powder Technology,2009,189(1):115-125.
[12]	Bai X M,Keer L M,Wang Q J,et al.Investigation of particle damping mechanism via particle dynamics simulations[J].Granular Matter,2009,11(6):417-429.
[13]	CHEN Tianning,MAO Kuanmin,HUANG Xieqing,et al.Dissipation mechanisms of non-obstructive particle damping using discrete element method //Proceedings of SPIE International Symosium on Smart Structures and Materials:Damping and Isolation. Newport Beach,CA:SPIE,2001,4331:294-301.
[14]	XU Zhiwei,WANG Yu,CHEN Tianning.Particle damping for passive vibration suppression:numerical modeling and experimental investigation[J].Journal of Sound and Vibration,2005,279(3-5):1097-1120.
[15]	MAO Kuanmin,Wang Y M,XU Zhiwei,et al.DEM simulation of particle damping[J].Powder Technology,2004,142(2-3):154-165.
[16]	Tsuji Y,Tanaka T,Ishida T.Lagrangian numerical simulation of plug flow of cohesionless particle in a horizontal pipe[J].Powder Technology,1992,71(3):239-250.
[17]	Kruggel-Emden H,Sturm M,Wirtz S,et al.Selection of an appropriate time integration scheme for the discrete element method(DEM)[J].Computer and Chemical Engineering,2008,32(10):2263-2279.
[18]	Yao Z H,Cheng M,Wang J S.New O(N) neighbor list method for molecular dynamics .Pist,Italy:URSI EMTS,2004.
[19]	Fang X,Tang J.A highly efficient discrete element approach for granular damping analysis //Proceedings of SPIE Conference on Smart Structures and Materials:Damping and Isolation.San Diego,AC,USA:SPIE,2006,6169:205-214.
