磁悬浮柔性转子系统变学习速率单神经元自适应PID控制
Adaptive PID control for flexible rotor supported by active magnetic bearings based on single neuron with varying learning rates
-
摘要: 为同时保证磁悬浮轴承柔性转子系统所需的低频和高频特性,在一般单神经元PID(proportion integration differentiation)控制的基础上,将转速信号引入磁悬浮轴承数字控制器,在不同转速段选择不同的学习速率以调节控制参数得到合适的磁悬浮轴承的刚度和阻尼.试验结果表明,变学习速率单神经元自适应PID控制能够明显减小转子在各阶临界转速时的振幅,有助于磁悬浮轴承柔性转子系统的安全稳定运行.Abstract: To satisfy the requirements of active magnetic bearing system that operates on both low frequency and high frequency,the signal of the rotation speed was introduced into the control based on normal single neuron PID (proportion integration differentiation) control,and different learning rates at varying rotation speeds were selected to adjust the control parameters and obtain the active magnetic bearings with suitable stiffness and damping.The experimental results show that adaptive PID control based on single neuron with varying learning rates can reduce vibration of the rotor obviously at critical speeds,and help the system operate safely.
-
[1] Adler K,Schalk C,Nordmann R,et al.Active balancing of a supercritical rotor on active magnetic bearings .Martigny,Switzerland:The 10th International Symposium on Magnetic Bearings,2006. [2] Fujiwara H,Ebina K,Ito M,et al.Control of flexible rotors supported by active magnetic bearings //Proceedings of the 8th International Symposium on Magnetic Bearings.Mito,Japan:Ibaraki University,2002:145-150. [3] Schonhoff U,LUO Jihao,LI Guoxin,et al.Implementation results of μ-synthesis control for an energy storage flywheel test rig //Proc.of the 7th Int.Symp.on Magnetic Bearings.Zurich:ETH,2000:317-322. [4] Murata M,Tajima H,Watanabe T,et al.New modeling and methods for flexible rotors with magnetic bearings toward passing through critical speeds caused by elastic mode .Martigny,Switzerland:The 10th International Symposium on Magnetic Bearings,2006. [5] ZHAO Lei,LI Hongwei,GU Huidong,et al.Investigation of an AMBs-flexible rotor for pass through two bending mode frequencies .Martigny,Switzerland:The 10th International Symposium on Magnetic Bearings,2006. [6] 谢振宇,李克雷,赵钦泉,等.带阻尼器磁悬浮轴承转子系统性能的实验分析[J].航空动力学报,2008,23(7):1312-1317. XIE Zhenyu,LI Kelei,ZHAO Qinquan,et al.Experimental analysis on characteristics of the system supported by magnetic bearings and magnetic damper[J].Journal of Aerospace Power,2008,23(7):1312-1317.(in Chinese) [7] 谢振宇,张景亭,高华,等.带阻尼器磁悬浮轴承转子系统的不平衡响应[J].中国机械工程,2009,20(3):327-329. XIE Zhenyu,ZHANG Jingting,GAO Hua,et al.Unbalance response of active magnetic bearing system with magnetic damper[J].China Mechanical Engineering,2009,20 (3):327-329.(in Chinese) [8] 谢振宇,王彤,张景亭,等.磁悬浮轴承金属 橡胶环组合支承转子系统的动态性能[J].航空动力学报,2009,24(2):378-383. XIE Zhenyu,WANG Tong,ZHANG Jingting,et al.Dynamic characteristics of active magnetic bearing system with metal rubber annuluses[J].Journal of Aerospace Power,2009,24(2):378-383.(in Chinese) [9] 闫辉,姜洪源,刘文剑,等.具有迟滞非线性的金属橡胶隔振器的参数识别研究[J].物理学报,2009,58(8):5238-5242. YAN Hui,JIANG Hongyuan,LIU Wenjian,et al.Identification of parameters for metal rubber isolator with hysteretic nonlinearity characteristics[J].Acta Physica Sinica,2009,58(8):5238-5242.(in Chinese) [10] 陶永华.新型PID控制及其应用[M].北京:机械工业出版社,2002. TAO Yonghua.New PID control and application[M].Beijing:China Machine Press,2002.(in Chinese) [11] 彭天好,徐兵,杨华勇.变频泵控马达调速系统单神经元自适应PID控制[J].中国机械工程,2003,14(20):1780-1783. PENG Tianhao,XU Bing,YANG Huayong.Single neuron adaptive PID control of variable frequency pump-control-motor speed governing system[J].China Mechanical Engineering,2003,14(20):1780-1783.(in Chinese) [12] 施虎,龚国芳,杨华勇,等.基于单神经元的盾构推进速度自适应PID控制[J].中国机械工程,2009,20(2):138-141. SHI Hu,GONG Guofang,YANG Huayong,et al.Adaptive PID control for thrust speed of shield based on single neuron[J].China Mechanical Engineering,2009,20(2):138-141.(in Chinese)
