气体润滑弹性波箔片轴承动态特性分析

许怀锦; 刘占生; 吕伟剑; 李华峰

气体润滑弹性波箔片轴承动态特性分析

1.
中国船舶重工集团公司武汉第二船舶设计研究所,武汉 430000
2.
哈尔滨工业大学能源科学与工程学院,哈尔滨 150001

计量
- 文章访问数: 1914
- HTML浏览量: 269
- PDF量: 26
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-27
- 修回日期: 2010-08-16
- 刊出日期: 2011-05-28

Dynamic characteristics analysis of bump foil journal bearings with air lubrication

1.
Wuhan Second Ship Design and Research Institute, China Shipbuilding Industry Corporation, Wuhan 430064, China
2.
School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 通过摄动方法并结合气体润滑压力控制Reynolds方程和气膜压力、气膜厚度及箔片变形等变量的Taylor展开式,推导出弹性波箔片轴承气膜动力特性系数计算微分方程组.同时,考虑气体可压缩性等因素,建立气膜厚度、箔片变形和气膜压力三者之间关系的数学模型方程组.运用Newton-Raphson迭代法和有限差分法耦合求解气膜动力特性系数计算微分方程组和气膜厚度数学模型方程组,得到弹性波箔片轴承气膜刚度和阻尼等动力特性系数随偏心率、转速、扰动频率及轴承长径比等参数变化的规律特性,为箔片轴承设计、优化和弹性波箔片轴承-转子系统理论及试验分析奠定基础.计算结果表明,随着偏心率和转速的增大,润滑气膜主刚度均有不同程度的提高,同时,润滑气膜刚度和阻尼的大小与扰动频率关系密切.
- 气体润滑 /
- 弹性波箔片轴承 /
- 气膜厚度数学模型 /
- 耦合解 /
- 动态特性
Abstract: Differential equations of air film in elastic bump foil journal bearing were deducted by the perturbation method with air lubrication Reynolds equation and series expansions of air film,air film thickness and foil deformation.The mathematics model of the relations among air film thickness,bump foil deformation and air film pressure was developed in consideration of air compressibility.Both finite difference method and Newton-Raphson method were applied to solve the coupled differential equations and air film thickness mathematics model equations,while the variation rules of air film stiffness and damping coefficients were achieved with different eccentricities,speeds,perturbation frequencies and different length-diameter ratios.This provides a basis for bump foil journal bearing design,optimization and theoretical and test analysis of rotor-elastic foil bearing system.The numerical results show that the main air film stiffness is enhanced when eccentricity and speed increase,and the value of air film stiffness and damping of bump foil journal bearing are connected strongly with the perturbation frequencies.
- air lubrication /
- elastic bump foil journal bearing /
- air film thickness mathematics model /
- coupling solution /
- dynamic characteristics

HTML

参考文献(17)

[1]	Ku C P P,Heshmat H.Compliant foil bearing structural stiffness analysis Part 1:theoretical model including strip and variable bump foil geometry[J].ASME Journal of Tribology,1992,114(2):394-400.
[2]	Peng Z C,Khonsari M M.Hydrodynamic analysis of compliant foil bearings with compressible gas flow[J].ASME Journal of Tribology,2004,126(3):542-546.
[3]	Peng Z C,Khonsari M M.A thermohydrodynamic analysis of foil journal bearings[J].ASME J.Tribol.,2006,128(3):534-541.
[4]	刘占生,许怀锦.波箔型动压气体径向轴承的应用与研究进展[J].轴承,2008(1):39-43. LIU Zhansheng,XU Huaijin.Application and research progress of bump-type foil aerodynamic journal bearings[J].Bearing,2008(1):39-43.(in Chinese)
[5]	Howard S A,DellaCorte C.Gas foil bearings for space propulsion nuclear electric power generation .NASA TM-2006-214115,2006.
[6]	Agrawal G L.Foil air/gas bearing technology—an overview .ASME 97-GT-347,1997.
[7]	DellaCorte C.A new foil air bearing test rig for use to 700℃ and 70000rpm .NASA TM-1997-107405,1997.
[8]	Stanford M K,DellaCorte C.Friction and wear characteristics of Cu-4Al foil bearing coating at 25 and 650℃ .NASA TM-2004-212972,2004.
[9]	Heshmat H,Hryniewicz P,Walton J F,Ⅱ,et al.Low-friction wear-resistant coating for high-temperature foil bearings .WTC 2005-63684,2005.
[10]	Bali c ＇ E E,Blanchet T A.Thrust-washer tribological evaluation of PS304 coating against Rene 41[J].Wear,2005,259(7-12):876-881.
[11]	Howard S A.Misalignment in gas foil journal bearings:an experimental study[J].ASME Journal of Engineering for Gas Turbines and Power,2009,131(3):02250(7 pages).
[12]	Radil K,Zeszotek M.An experimental investigation into the temperature profile of a compliant foil air bearing[J].NASA TM-2004-213100,2004.
[13]	虞烈.弹性箔片轴承的气弹润滑解[J].西安交通大学学报,2004,38(3):327-330. YU Lie.Solution of elasto-aerodynamic lubrication for compliant foil bearings[J].Journal of Xi'an Jiaotong University,2004,38(3):327-330.(in Chinese)
[14]	虞烈,戚社苗,耿海鹏.弹性箔片空气动压轴承的完全气弹润滑解[J].中国科学E辑,2005,35(7):746-760. YU Lie,QI Shemiao,GENG Haipeng.Solution of whole elasto-aerodynamic lubrication for compliant foil bearings[J].Science in China,Ser.E,2005,35(7):746-760.(in Chinese)
[15]	Peng J P,Carpino M.Calculation of stiffness and damping coefficients for elastically supported gas foil bearings[J].ASME Journal of Tribology,1993,115(2):20-27.
[16]	许怀锦,刘占生,张广辉,等.波箔片气体动压径向轴承气膜压力分布特点[J].轴承,2008(6):23-27. XU Huaijin,LIU Zhansheng,ZHANG Guanghui,et al.Characteristics of film pressure distribution of bump foil gas bearings[J].Bearing,2008(6):23-27.(in Chinese)
[17]	Heshmat H,Walowit J A,Pinkus O.Analysis of gas-lubricated foil journal bearings[J].ASME Journal of Lubrication Tribology,1983,105(10):647-655.
