温变环境中测试信号传输的仿真及试验

门秀花; 李舜酩; 杨东

温变环境中测试信号传输的仿真及试验

1.
济南大学机械工程学院, 济南 25002
2.
南京航空航天大学能源与动力学院, 南京 210016

基金项目: 济南大学校博士基金(XBS1003)

计量
- 文章访问数: 1535
- HTML浏览量: 66
- PDF量: 13
- 被引次数: 0
出版历程
- 收稿日期: 2010-06-03
- 修回日期: 2010-12-12
- 刊出日期: 2011-07-28

Simulation and experimental investigation of test signal transmission on temperature changing environment

1.
School of Mechanical Engineering,University of Jinan,Jinan 25002
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 信号传输理论应用于电路网络中,由基尔霍夫定律推导了离散的温度-时间信号传输模型.给出了一种基于电压和电流的迭代算法,分别实现了导线升温、降温过程的信号传输仿真分析.研究表明:测试信号幅值随温度升高而逐渐衰减,在300℃时,幅值衰减了10%左右,而在升、降温并存环境中幅值衰减更加明显.在此基础上,设计了温变环境下的振动测试试验,所得结果与仿真分析结果一致.该研究为提高振动测试信号的精度提供了一种新方法.
- 振动测试 /
- 信号传输 /
- 温变环境 /
- 渐变温模型 /
- 信号幅值
Abstract: The signal transmission theory was applied to circuit network to obtain discrete temperature-time signal transmission model derived by Kirchhoff's law.And then,an iterative algorithm based on voltage and current was proposed,realizing the signal transmission with different temperature change processes.It shows that the amplitude of output signal gradually attenuates with the rise of conductor temperature,by 10% at 300℃.And the amplitude attenuation is more evident due to the coexistence of conductor temperature rise and drop.The corresponding experiment has been conducted,and the results can meet that of proposed model.It provides a new method for improving the accuracy of vibration test signal.
- vibration test /
- signal transmission /
- temperature changing environment /
- temperature gradient model /
- signal amplitude

HTML

参考文献(12)

[1]	廖庆斌,李舜酩,覃小攀.车辆振动信号的特征提取方法比较[J].吉林大学学报(工学版),2007,37(4):910-914. LIAO Qingbin,LI Shunming,QIN Xiaopan.Comparison of feature extraction methods of vehicle vibration signal[J].Journal of Jilin University(Engineering and Technology Edition),2007,37(4):910-914.(in Chinese)
[2]	孙强,张忠平,柴桥,等.航空发动机压气机叶片振动频率与温度的关系[J].应用力学学报,2004,21(4):137-139. SUN Qiang,ZHANG Zhongpin,CHAI Qiao,et al.Temperatue effect on vibration frequency of aero-engine compressor blade[J] Chinese Journal of Applied Mechanics,2004,21(4):137-139.(in Chinese)
[3]	Djordjevic A R,Sarkar T K,Harrington R F.Time-domain resonse of multiconductor transmission lines[J].Proceedings of the IEEE,1987,75(6):743-764.
[4]	Antonini G,Orlandi A,Paul C R.An improved method of modeling lossy transmission lines finite-difference time-domain analysis[J].IEEE International Symposium on Electromagnetic Compatibility,1999,1:435-439.
[5]	Ruehli A E,Cangellaris A C.Progress in the methodologies for the electrical modeling of interconnects and electronic packages[J].Proceedings of the IEEE,2001,89(5):740-771.
[6]	Paul C R.Incorporation of terminal constraints in the FDTD analysis of transmission lines[J].IEEE Trans. Electromagn. Compat.,1994,36(2):85-91.
[7]	Hoefer W J R.The transmission-line matrix method:theory and applications[J].IEEE Trans.on MTT,1985,33(10):882-893.
[8]	Lau F C M.Waveform relaxation analysis of lossy coupled transmission line sets in cascade[J].IEE Proc-Circuits Devices Syste.,1995,142(6):373-378.
[9]	郭裕顺.用NILT导出的传输线瞬态分析模型[J].电子学报,2002,30(3):381-385. GUO Yushun.Transmission line model of transient simulation derived using the NLIT technique[J].Acta Electronic Sinica,2002,30(3):381-385.(in Chinese)
[10]	Gomes S,Jr.,Martins N,Varricchio S L,et al.Modal analysis of electromagnetic transients in ac networks having long transmission lines[J].IEEE Trans. Power Del.,2005,20(4):2623-2630.
[11]	Caniggia S,Maradei F.Spice-like models for the analysis of the conducted and radiated immunity of shielded cables[J].IEEE Trans.Electromagn. Compat.,2004,46(4):606-616.
[12]	门秀花,李舜酩,胡瑞,等.高温环境对振动测试信号传输参数的影响[J].航空动力学报,2009,24(9):1731-1735. MEN Xiuhua,LI Shunming,HU Rui,et al.Effects on transmission parameters of vibration measurement for high temperature environment[J].Journal of Aerospace Power,2009,24(9):1731-1735.(in Chinese)
