激光冲击强化提高压气机叶片疲劳性能研究
Laser shock peening on vibration fatigue behavior of compressor blade
-
摘要: 根据1Cr11Ni2W2MoV不锈钢材料性能,确定了激光冲击强化参数;并通过标准试片疲劳试验,验证了该参数条件下激光冲击强化提高不锈钢材料振动疲劳寿命的有效性.设计了不锈钢叶片振动疲劳试验,确定了叶片冲击强化部位和方式,对强化叶片进行了型面检查、一阶弯曲振动疲劳试验和强化机理研究.结果表明:激光冲击强化后的叶片各个截面尺寸在设计范围之内,强化后叶片的应力-循环次数(S-N)曲线往上移动,提高了叶片的疲劳强度,在660MPa应力水平下,叶片的振动中值疲劳寿命提高70%;激光冲击强化引起的残余应力和表层微观组织变化是疲劳强度提高的主要原因.Abstract: According to the mechanical performance of the 1Cr11Ni2W2MoV stainless steel, the technical parameters of laser shock peening(LSP) were determined. The standard coupons with/without LSP were tested for examining the fatigue performance. It proves that LSP, with the selected parameters, can improve the stainless steel's vibration fatigue life remarkably. From the experiment results of coupons, the vibration fatigue experiment for the compressor blade in one certain aero-engine was designed according to the structure and loads of the blade. The treated zone was designed on the surface where the vibration stress is the most severe. In order to avoid macroscopical deformation, the blades were treated on both sides simultaneously. This confirms that different section parameters after LSP on the blade are within the range of design requests. The vibration fatigue results indicate that the S-N (stress-number of cycles) curve with LSP moves up as compared with that one without LSP. When the max vibratory stress was about 660MPa, the blade fatigue life with LSP was prolonged for 70%. Finally, the reasons were analyzed from the residual compressive stress and micro structure after LSP.
-
Key words:
- laser shock peening /
- compressor blade /
- vibration /
- fatigue life /
- residual stress
-
[1] Yang J M,Her Y C,Han N,et al.Laser shock peening on fatigue behavior of 2024-T6 Al alloy with fastener holes and stop holes[J].Material Science Engineer,2001,A298:296-299. [2] Peyre P,Fabbro R.Laser shock processing:a review of the physics and applications[J].Opt. Quant. Electron.,1995,27(12):1213-1229. [3] Universal Technology Corporation.High cycle fatigue (HCF) science and technology program 2002 annual report .AFRL-PR-WP-TR-2000-2004,2002. [4] Tenaglia R D,Labrman D F.Preventing fatigue failures with laser peening[J].The AMPTIAC,2003,7(2):L3-7. [5] Peyre P,Fabbro R,Merrier P,et al.Laser shock processing of aluminum alloys:application to high cycle fatigue behavior[J].Materials Science and Engineering,1996,210(1-2):102-113. [6] 李应红,何卫锋,李伟,等.激光冲击强化提高发动机部件疲劳可靠性的研究 //第五届航空发动机可靠性学术交流会论文集.北京:中国航空学会,2009:564-571. [7] 李伟,何卫锋,李应红,等.激光冲击强化对K417材料振动疲劳性能的影响[J].中国激光,2009,36(8):2197-2201. LI Wei,HE Weifeng,LI Yinghong,et al.The effects of laser shock processing on the vibration fatigue properties of K417 material[J].China Laser,2009,36(8):2197-2201.(in Chinese) [8] 谭华.实验冲击波物理导引[M].北京:国防工业出版社,2007. [9] Fabbro R,Peyre P,Berthe L,et al.Physics and applications of laser-shock processing[J].Journal of Laser Apply,1998,10(6):265-279. [10] Fabbro R,Foumier J,Ballard P,et al.Physical study of laser-produced plasma in confined geometry[J].Journal of Applied Physics,1990,68(2):775-84. [11] 中华人民共和国航空工业部.HB5277-84 发动机叶片及材料振动疲劳试验方法[S].北京:中华人民共和国航空工业部,1984. [12] 中华人民共和国航空工业部.HB/Z112-86 材料疲劳试验统计分析方法[S].北京:中华人民共和国航空工业部,1986. [13] 李其汉,王延荣,王建军.航空发动机叶片高循环疲劳失效研究[J].航空发动机,2003,29(4):16-19. LI Qihan,WANG Yanrong,WANG Jianjun.Investigation of high cycle fatigue failures for the aero engine blades[J].Aeroengine,2003,29(4):16-19.(in Chinese) [14] 张定铨,何家文.材料中残余应力的X射线衍射分析和作用[M].西安:西安交通大学出版社,1999. [15] Suresh.材料的疲劳 [M].2版.王中光,译.北京:国防工业出版社,1999. [16] 张俊善.材料强度学[M].哈尔滨:哈尔滨工业大学出版社,2004.
