叶轮机械叶片颤振的影响参数

张小伟; 王延荣; 徐可宁

叶轮机械叶片颤振的影响参数

北京航空航天大学能源与动力工程学院, 北京 100191

基金项目: 国家重点基础研究发展计划(2007CB210103); 北京航空航天大学博士研究生创新基金

计量
- 文章访问数: 2215
- HTML浏览量: 328
- PDF量: 24
- 被引次数: 0
出版历程
- 收稿日期: 2010-06-29
- 修回日期: 2010-09-21
- 刊出日期: 2011-07-28

Effects of parameters on blade flutter in turbomachinery

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 采用基于能量法的流固耦合数值预测方法对比研究了几个主要参数对叶轮机械叶片气动弹性稳定性的影响规律,并较深入地阐述了叶片颤振发作机理.以某型发动机第一级压气机叶片为例,在叶片的不同模态下,通过给定不同的进出口边界条件分别研究了叶片模态和叶间相位角对叶轮机械气动弹性稳定性的影响,并从叶片吸力面激波以及波后分离区共同作用的角度解释了叶轮机械叶片的颤振发作机理.计算结果表明:叶片模态和叶间相位角对叶轮机械叶片的颤振有关键性的影响,而吸力面激波以及波后分离区是导致叶片颤振发作的重要因素.
- 叶轮机械 /
- 叶片颤振 /
- 能量法 /
- 颤振机理 /
- 影响参数
Abstract: An aeroelastic stability prediction approach derived from energy method was used to investigate the effects of several parameters on the aeroelastic stability of rotor blades in turbomachinery,and the mechanism of flutter was determined in some details.Taking the first stage compressor rotor of an engine as an example,the aeroelastic analysis was computed under different working conditions for the oscillating cascades with different blade modes.Some parameters,such as mode shape and interblade phase angle,were included to investigate their effects on the flutter in turbomachinery.And the flutter mechanisms were also concluded from the interaction of shock wave on the suction surface and separation area behind shock.The result shows that mode shape and interblade phase angle are key parameters affecting the flutter characteristics,while the shock wave on the suction surface and the separation area behind the shock wave are important factors to induce the blade flutter.
- turbomachinery /
- blade flutter /
- energy method /
- flutter mechanism /
- influence parameter

HTML

参考文献(14)

[1]	Carta F O.Coupled blade-disk-shroud flutter instabilities in turbojet engine rotors[J].Journal of Engineering for Power,1967,89(3):419-426.
[2]	Bendiksen O O.A new approach to computational aeroelasticity .AIAA Paper 1991-0939,1991.
[3]	Srinivasan A V.Flutter and resonant vibration characteristics of engine blades[J].Journal of Engineering for Gas Turbines and Power,1997,119(4):742-775.
[4]	张扬军,陈乃祥,诸葛伟林.振荡叶栅非定常流动的相互作用对叶片颤振的影响[J].清华大学学报(自然科学版),1997,37(11):5-8. ZHANG Yangjun,CHEN Naixiang,ZHUGE Weilin.Effect of blade vibration interaction on aeroelastic stability[J].Journal of Tsinghua University(Sci.& Tech.),1997,37(11):5-8.(in Chinese)
[5]	Cinnella P,Palma P D,Pascazio G,et al.A numerical method for turbomachinery aeroelasticity[J].ASME Journal of Turbomachinery,2004,126(2):310-316.
[6]	Sadeghi M,Liu F.Computation of mistuning effects on cascade flutter .AIAA 2000-0230,2000.
[7]	张小伟,王延荣,张潇,等.涡轮机械叶片的流固耦合数值计算方法[J].航空动力学报,2009,24(7):1622-1626. ZHANG Xiaowei,WANG Yanrong,ZHANG Xiao,et al.Numerical method for fluid-structure interaction in turbomachinery bladings[J].Journal of Aerospace Power,2009,24(7):1622-1626.(in Chinese)
[8]	张小伟,王延荣.叶间相位角对叶片颤振的影响[J].航空动力学报,2010,25(2):412-416. ZHANG Xiaowei,WANG Yanrong.Influence of interblade phase angle on the flutter of rotor blades[J].Journal of Aerospace Power,2010,25(2):412-416.(in Chinese)
[9]	Carta F O,St Hilaire A O.Experimentally determined stability parameters of a subsonic cascade oscillating near stall[J].Journal of Engineering for Power,1978,100(1):111-120.
[10]	Carta F O,St Hilaire A O.Effect of interblade phase angle and incidence angle on cascade pitching stability[J].Journal of Engineering for Power,1980,102(2):391-396.
[11]	Panovski J,Kielb R E.A design method to prevent low pressure turbine blade flutter[J].Journal of Engineering for Gas Turbines and Power,2000,122(1):89-98.
[12]	Nowinski M,Panovsky J.Flutter mechanisms in low pressure turbine blades[J].Journal of Engineering for Gas Turbines and Power,2000,122(1):82-88.
[13]	Sadeghi M,Liu F,Lai K L,et al.Application of three-dimensional interfaces for data transfer in aeroelastic computations .AIAA Paper 2004-5376,2004.
[14]	宋兆泓.航空发动机典型故障分析[M].北京:北京航空航天大学出版社,1993. SONG Zhaohong.Typical fault analysis of aero-engine[M].Beijing:Beijing University of Aeronautics and Astronautics Press,1993.(in Chinese)
