基于伴随算子的气动布局优化技术及其在大飞机机翼减阻中的应用

吴文华; 陶洋; 陈德华; 王元靖; 黄勇

基于伴随算子的气动布局优化技术及其在大飞机机翼减阻中的应用

吴文华^1,2,
陶洋²,
陈德华^1,2,
王元靖²,
黄勇²

1.
中国空气动力研究与发展中心空气动力学国家重点实验室, 四川绵阳 621000
2.
中国空气动力研究与发展中心高速空气动力研究所, 四川绵阳 621000

基金项目: 国家自然科学基金(10972233); 国际科技合作项目(2007DFA70880)

计量
- 文章访问数: 2071
- HTML浏览量: 187
- PDF量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-11
- 修回日期: 2011-03-24
- 刊出日期: 2011-07-28

Wing optimization of large airplane by adjoint method

1.
State Key Laboratory of Aerodynamics, China Aerodynamics Research and Development Center,Mianyang Sichuan 621000,China
2.
High Speed Aerodynamics Institute, China Aerodynamics Research and Development Center,Mianyang Sichuan 621000,China

摘要

摘要: 为了提高大型飞机机翼的气动性能,发展了基于Bezier-Bernstein曲线的机翼气动布局参数化技术和网格变形技术,以及基于Navier-Stokes方程的流场解算器、伴随算子解算器和二次规划寻优算法,形成了气动布局优化软件.通过改变约束条件、设计参数范围和初始点,对机翼进行了一系列的极多参数和多约束的气动布局精细优化设计,得到了良好的优化结果,优化结果表明该优化方法是高效和可靠的.
- 气动布局 /
- 优化 /
- 伴随算子 /
- 减阻 /
- 机翼
Abstract: The optimization software was developed to improve the performance of the wing of large airplane.This software include the three main techniques:the aerodynamic configuration parameterization and grid update technique based on Bezier-Bernstein curve parameterization method;the flow solver and adjoint solver based on three-dimensional (3-D) Reynolds averaged Navier-Stokes equations;the optimization method based on sequential quadratic programming algorithm.This paper did series optimization for a wing with many design variables and different constraints and get some excellent results,The analysis to the result shows the optimization method is reliable and efficient.
- aerodynamic configuration /
- optimization /
- adjoint /
- drag reduction /
- wing

HTML

参考文献(12)

[1]	Moigne A L.A discrete Navier-Stokes adjoint method for aerodynamic optimization of blended wing-body configurations .Cranfield:Cranfield University,2002.
[2]	Müller B,Rizzi A. Navier-Stokes solution for transonic flow over wings //Proceedings of the Seventh GAMM-Conference on Numerical Methods in Fluid Mechanics.Vieweg,Louvain-La-Neuve,Belgium:GAMM,1987:47-255.
[3]	Radespiel R,Rossow C,Swanson R C.Efficient cell-vertex multigrid scheme for the three-dimensional Navier-Stokes equations[J].AIAA Journal,1990,28(8):1464-1472.
[4]	汪光文,周正贵,胡骏.基于优化算法的压气机叶片气动设计[J].航空动力学报,2008,23(7):1218-1224. WANG Guangwen,ZHOU Zhenggui,HU Jun.Aerodynamic design of compressor blade using optimization algorithm[J].Journal of Aerospace Power,2008,23(7):1218-1224.(in Chinese)
[5]	Leoviriyakit K,Jameson A.Multi-point wing planform optimization via control theory .AIAA 2005-450,2005.
[6]	Jameson A,Leoviriyakit K,Shankaran S.Multi-point aero-structural optimization of wings including planform variations .AIAA 2007-764,2007.
[7]	Koc S,Kim H J,Nakahashi K.Aerodynamic design optimization of wing-body configurations .AIAA 2005-331,2005.
[8]	Lee B J,Kim C.Viscous aerodynamic shape optimization of wing body configuration with overset mesh techniques .AIAA 2007-2872,2007.
[9]	Lee B J,Kim C.Aerodynamic design of wing-body-nacelle-pylon configuration .AIAA 2005-4856,2005.
[10]	Osher S,Solomon F.Upwind difference schemes for hyperbolic systems of conservation laws[J].Mathematics of Computation,1982,38(158):339-374.
[11]	Chakravarthy S R,Osher S.Numerical experiments with the Osher upwind scheme for the Euler equations .AIAA Journal,1983,21(9):1241-1248.
[12]	Baldwin B S,Lomax H.Thin layer approximation and algebraic model for separated turbulent flows .AIAA Paper 78-257,1978.
