高超声速低温喷管横向射流混合反应过程的非定常数值模拟

邵艳; 周进; 赖林; 汪洪波; 雷静

高超声速低温喷管横向射流混合反应过程的非定常数值模拟

国防科学技术大学航天与材料工程学院, 长沙 410073

基金项目: 国家自然科学基金(11002158)

计量
- 文章访问数: 1744
- HTML浏览量: 81
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2010-12-08
- 修回日期: 2011-03-03
- 刊出日期: 2011-07-28

Unsteady numerical investigation of mixing and reacting for transverse injection in HYLTE nozzle

College of Aerospace and Materials Engineering, National University of Defense Technology,Changsha 410073,China

摘要

摘要: 基于混合RANS/LES (Reynolds averaged Navier-Stokes/large eddy simulation)方法模拟了高超声速低温(HYLTE)喷管倾斜入射横向射流的非定常混合反应过程,研究了不同副喷管喷射角和副喷管间距对射流穿透、混合以及总压损失的影响.计算表明,射流穿透深度和混合程度随着副喷管喷射角的增大而增大,但是总压损失也随之增大;副喷管间距增大,燃料射流的穿透深度增大而且总压损失略有减小,但反转旋涡对(CVP)的集中会造成射流与来流的接触面积减小,侧面混合变差.因此优化副喷管喷射角和间距对于提高HYLTE喷管混合性能乃至激光器光学性能都十分重要.通过模拟HYLTE喷管和光腔耦合区域的12组分23方程的反应流场发现,在中心线附近有较强的小信号增益系数,混合RANS/LES相比RANS方法更能反映流场变量的细节变化.
- 高超声速低温喷管 /
- 横向射流 /
- 混合性能 /
- 总压恢复 /
- 穿透深度
Abstract: A hybrid Reynolds averaged Navier-Stokes/large eddy simulation (RANS/LES) approach was applied to simulate the unsteady mixing and reacting process of the angled transverse injection in the hypersonic low temperature (HYLTE) nozzle,while the influences of different injection angles and distances on the penetration height,mixing and total pressure loss were analyzed.It is found that the penetration height and mixing are enhanced with the increase of the injection angle,but together with the increasing total pressure loss.In addition,when the injection distance increases,the penetration height of the fuel injection increases and the total pressure loss decreases a little,but the counter vortex pairs are too close to produce larger contact regions and better lateral mixing.Optimum incident angle and injection distance are essential to enhance the mixing performance of HYLTE nozzle and optical performance of the deuterium fluoride(DF) chemical laser.Moreover,the reacting flowfield of the coupled region,including 12 chemical species and 23 reactions,was simulated.The small signal gain coefficient reaches the maximum in the vicinity of the centerline.Compared with the method of RANS,hybrid RANS/LES approach is more capable of predicting the changes of flowfield variables.
- hypersonic low temperature (HYLTE) nozzle[BFQ] /
- transverse injection /
- mixing performance /
- total pressure recovery /
- penetration height

HTML

参考文献(15)

[1]	Smith W.Simple model of the transverse injection chemical laser .AIAA 85-1599,1985.
[2]	怀英,贾淑芹,金玉奇.化学氧碘激光器内流场亚跨超音速混合的大涡模拟研究[J].强激光与粒子束,2009,21(7):977-981. HUAI Ying,JIA Shuqin,JIN Yuqi.Large eddy simulation of mixing process in chemical oxygen-iodine laser[J].High Power Laser and Particle Beams,2009,21(7):977-981.(in Chinese)
[3]	Lohn P D,Haflinger D E,Fink S F.Fluid dynamics design for space-based lasers .AIAA 99-3574,1999.
[4]	袁圣付.连续波DF/HF化学激光器新型增益发生器的理论设计 .长沙:国防科学技术大学,2002. YUAN Shengfu.Theoretical design of latest gain generator for continuous wave DF/HF chemical lasers .Changsha:National University of Defense Technology,2002.(in Chinese)
[5]	雷静,赖林,王振国.高超声速低温喷管副喷管参数化设计[J].强激光与粒子束,2007,19(11):1766-1770. LEI Jing,LAI Lin,WANG Zhenguo.Parameterized design for HYLTE secondary nozzle[J].High Power Laser and Particle Beams,2007,19(11):1766-1770.(in Chinese)
[6]	Baurle R A,Tam C J,Edwards J R,et al.Hybrid simulation approach for cavity flows:blending algorithm and boundary treatment issues[J].AIAA Journal,2003,41(8):1463-1484.
[7]	Menter F R.Two equation eddy viscosity turbulence models for engineering applications[J].AIAA Journal,1994,32(8):1589-1605.
[8]	Yoshizawa A,Horiuti K.A statistically-derived subgrid scale kinetic energy model for large-eddy simualtion of turbulent flows[J].Journal of the Physical Society of Japan,1985,54(8):2834-2839.
[9]	Fan T C,Tian M,Edwards J R,et al.Validation of a hybrid Reynolds-averaged/large eddy simulation method for simulating cavity flameholder configurations .AIAA 2001-2929,2001.
[10]	孙明波,梁剑寒,王振国.二维凹腔超声速流动的混合RANS/LES模拟[J].推进技术,2006,27(2):119-123. SUN Mingbo,LIANG Jianhan,WANG Zhenguo.Hybrid RANS/LES simulation of supersonic flow over two-dimensional cavities[J].Journal of Propulsion Technology,2006,27(2):119-123.(in Chinese)
[11]	王卫东.垂直射流混合的三维湍流数值模拟[J].推进技术,1998,19(2):58-62. WANG Weidong.CFD mixing analysis of vortex generator jets injected into confined crossflow in rectangular duct[J].Journal of Propulsion Technology,1998,19(2):58-62.(in Chinese)
[12]	吕俊明,胡宗民,姜宗林.亚声速段横向射流对COIL性能影响的数值研究[J].计算物理,2008,25(4):414-420. LV Junming,HU Zongmin,JIANG Zonglin.Effect of penetration in HPCOIL[J].Chinese Journal of Computational Physics,2008,25(4):414-420.(in Chinese)
[13]	Cohen L S,Coulter L J,Egan W J.Penetration and mixing of multiple gas jets subjected to a cross flow[J].AIAA Journal,1971,9(4):718-724.
[14]	Tam C J,Gruber M R.Numerical study of jet injection into a supersonic crossflow .AIAA 99-2254,1999.
