直升机桨叶气动外形多目标优化设计

孙伟; 张呈林

直升机桨叶气动外形多目标优化设计

孙伟,
张呈林

南京航空航天大学航空宇航学院直升机旋翼动力学重点实验室, 南京 210016

计量
- 文章访问数: 2051
- HTML浏览量: 117
- PDF量: 18
- 被引次数: 0
出版历程
- 收稿日期: 2010-06-29
- 修回日期: 2010-12-08
- 刊出日期: 2011-07-28

Multi-objective optimization for aerodynamic shape of helicopter blade

Science and Technology on Rotorcraft Aeromechanics Laboratory, College of Aerospace Engineering,Nanjing University of Aeronautics and Astronautics, Nanjing 210016,China

摘要

摘要: 基于自由尾迹方法建立了直升机桨叶空气动力学分析模型,应用人工神经网络方法建立代理模型,采用改进的多目标遗传算法构建了优化框架,对直升机的悬停和大速度前飞状态进行优化.以悬停效率、旋翼等效升阻比及桨叶叶素的最大阻力系数为约束,对两个飞行状态的需用功率进行优化,得到了Pareto最优解集.并以UH-60A直升机的桨叶为算例,对其外形进行优化设计,优化结果表明,提出的桨叶气动外形多目标优化框架是有效可行的.
- 直升机 /
- 桨叶设计 /
- 气动外形 /
- 多目标优化 /
- 代理模型 /
- 遗传算法
Abstract: An aerodynamic model of helicopter rotor was set up based upon free-wake theory,and a surrogate model was created with artificial neural networks.Based on the aerodynamic model and surrogate model,an optimization framework with improved multi-objective genetic algorithm was used to optimize blade aerodynamic shape in hover and large speed level flight.Rotor shaft powers were minimized in these two flight conditions with constraints of figure of merit,effective lift-drag-ratio and maximum drag coefficient of blade element,and Pareto front was generated.The blade of UH-60A helicopter was taken as an example in this paper. The result indicates that the multi-objective optimization framework of aerodynamic shape is feasible and efficient.
- helicopter /
- blade design /
- aerodynamic shape /
- multi-objective optimization /
- surrogate model /
- genetic algorithm

HTML

参考文献(13)

[1]	Walsh J L,Bingham G J,Riley M F.Optimization methods applied to the aerodynamic design of helicopter rotor blades .NASA-TM-89155,1987.
[2]	Kumar S,Bassett D.Rotor performance optimization for future light helicopters //The American Helicopter Society 43rd Annual Forum.Saint Louis,Missouri:AHS,Annual Forum,1987,1:345-355.
[3]	LaMarsh Ⅱ W J,Walsh J L,Rogers J L.Aerodynamic performance optimization of a rotor blade using a neural network as the analysis .AIAA-92-4837,1992.
[4]	Bagai A.Contributions to the mathematical modeling of rotor flow-fields using a pseudo-implicit free-wake analysis .Maryland:University of Maryland,1995.
[5]	赵景根,高正,徐国华.直升机旋翼/机身气动干扰的计算方法[J].南京航空航天大学学报,2000,32(4):369-374. ZHAO Jinggen,GAO Zheng,XU Guohua.A computational method for helicopter rotor/fuselage aerodynamic interaction[J].Journal of Nanjing University of Aeronautics and Astronautics,2000,32(4):369-374.(in Chinese)
[6]	Scbeiman J.A tabulation of helicopter rotor-blade differential pressures,stresses,and motions as measured in flight .NASA TM X-952,1964.
[7]	Postsdam M,Yeo H,Johnson W.Rotor airloads prediction using loose aerodynamic/structural coupling .Baltimore,MD:The American Helicopter Society 60th Annual Forum,2004.
[8]	Konak A,Coit D W,Smith A E.Multi-objective optimization using genetic algorithms:a tutorial[J].Reliability Engineering and System Safety,2006,91(9):992-1007.
[9]	孙伟,张呈林.基于多目标遗传算法的直升机总体参数优化设计[J].机械科学与技术,2010,29(2):265-269. SUN Wei,ZHANG Chenglin.Helicopter preliminary parameter optimization based on multi-objective genetic algorithm[J].Mechanical Science and Technology for Aerospace Engineering,2010,29(2):265-269.(in Chinese)
[10]	孙伟,张呈林.神经网络在直升机概念设计中的应用[J].南京航空航天大学学报,2009,41(1):121-125. SUN Wei,ZHANG Chenglin.Application of neural networks in helicopter conceptual design[J].Journal of Nanjing University of Aeronautics and Astronautics,2009,41(1):121-125.(in Chinese)
[11]	Johnson W.Performance and loads data form a wind tunnel test of a full-scale rotor with four blade tip planforms .NASA Technical Memorandum 81229 USAAVRADCOM TR 80-A-9,1980.
[12]	Totah J.A critical assessment of UH-60 main rotor blade airfoil data .AIAA-93-3413,1993.
[13]	Bousman W G.Aerodynamic characteristics of SC1095 and SC1094R8 airfoils .NASA/TP-2003-212265,2003.
