超临界翼型跨声速激波振荡数值模拟

魏志; 陶洋; 王红彪

超临界翼型跨声速激波振荡数值模拟

魏志^1,2,
陶洋^1,2,
王红彪^1,2

1.
中国科学技术大学工程科学学院近代力学系, 合肥 230026
2.
中国空气动力研究与发展中心高速空气动力研究所, 四川绵阳 621000

基金项目: 国家自然科学基金(10972233)

计量
- 文章访问数: 1605
- HTML浏览量: 122
- PDF量: 23
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-11
- 修回日期: 2010-08-31
- 刊出日期: 2011-07-28

Numerical simulation of transonic shock oscillations on a supercritical airfoil

1.
Department of Modern Mechanics,School of Engineering Science, University of Science and Technology of China,Hefei 230026,China
2.
High Speed Aerodynamics Institute, China Aerodynamic Research and Development Center,Mianyang Sichuan 621000,China

摘要

摘要: 应用DES(detached eddy simulation)方法研究了SC(2)-0714超临界翼型跨声速自维持激波振荡现象.使用的DES方法预测了激波在翼型上表面的周期性运动,分析了雷诺数对激波运动的减缩频率、平均激波位置、脉动压力系数等非定常特性的影响.结果表明:雷诺数对激波振荡运动特性的影响呈非线性关系;而雷诺数为6×10⁶时的激波振荡运动特性与雷诺数分别为15×10⁶及30×10⁶时的特性存在明显差异.
- 超临界翼型 /
- 跨声速流动 /
- 激波 /
- 自维持运动 /
- 数值模拟
Abstract: Detached eddy simulation(DES)method was applied to study the self-sustained shock oscillations phenomenon of SC (2) -0714 supercritical airfoil in this paper. The periodic shock motion on the upper surface of the airfoil was predicted using the two-dimensional DES method in present calculation. The effects of Reynolds number (Re) on the reduced frequency of the shock motion, mean shock position and coefficients of fluctuation pressures were also studied in the paper. The results show that Reynolds number has a non-linear influence on shock oscillation motion character. Compared with Re=15×10⁶ and Re=30×10⁶ flow condition, the shock oscillation character in case of Re=6×10⁶ condition is obviously different.
- supercritical airfoil /
- transonic flow /
- shock /
- self-sustained motion /
- numerical simulation

HTML

参考文献(12)

[1]	Lee B G K.Self-sustained shock oscillations on airfoils at transonic speeds[J].Progress in Aerospace Sciences, 2001,37(2):147-196.
[2]	Lee B G K.Oscillatory shock motion caused by transonic shock boundary-layer inter-action[J].AIAA Journal,1990,28(5):942-944.
[3]	Xiao Q,Tsai H M,Liu F.Numerical study of transonic buffet on a supercritical airfoil[J].AIAA Journal,2006,44(3):620-628.
[4]	Brunet V.Computational study of buffet phenomenon .AIAA Paper 2003-3679,2003.
[5]	Deck S.Numerical simulation of transonic buffet over a supercritical airfoil[J].AIAA Journal,2005,43(7):1556-1665.
[6]	Spalart P,Jou W H,Strlies M,et al.Comments on the feasibility of LES for wings,and on a hybrid RANS/LES approach //Proceedings of the 1st AFSOR International Conference on DNS/LES.Ruston,LA: ,1998:137-147.
[7]	Strelets M.Detached eddy simulation of massively separated flows .AIAA Paper 2001-0879,2001.
[8]	Spalart P R.Detached-eddy simulation[J].Annual Review Fluid Mech.,2009,41(1):181-202.
[9]	Loginov M S,Adams N A,Zheltovodov A A.Large-eddy simulation of shock-wave/turbulent-boundary-layer interaction[J].Journal of Fluid Mechanics,2006,565:135-169.
[10]	Lu X Y,Wang S W,Sung H G,et al.Large-eddy simulations of turbulent swirling flows injected into a bump chamber[J].Journal of Fluid Mechanics,2005,527:171-195.
[11]	Smagorinsky J.General circulation experiments with the primitive equationⅠ:the basic experiment[J].Monthly Weather Review,1963,91(3):99-165.
[12]	Bartels R E,Edwards J E.Cryogenic tunnel pressure measurements on a supercritical airfoil for several shock buffet conditions .NASA-TM 110272,1997.
