压气机中尾迹/边界层作用模型的分析与验证
Analysis and verification of wake / boundary layer interaction model in compressor
-
摘要: 基于叶轮机中尾迹的负射流效应,考虑了边界层外缘黏性力项对边界层发展的影响,推导了尾迹/边界层相互作用的数学模型,并建立了边界层动量厚度与压气机叶片负荷变化的定量关系,对模型进行了数值模拟和实验验证.结果表明:①此模型能够较好地预测尾迹通过频率对压气机负荷的影响,压气机压升随着尾迹通过频率的变化存在极大值;②尾迹引起边界层当地压力梯度变化,是影响压气机负荷的主要因素.Abstract: A wake/boundary layer interaction model was derived based on negative jet effect of wake transport in turbomachinery,in consideration of the influences of outer boundary layer's viscous force on boundary layer development.Then,the relationship between pressure rise and momentum thickness was established.An experiment was designed to verify this model about effect of wake passing frequency on compressor pressure rise at fixed wake depth and wake width.Comparison of model and experimental results indicates that: (1) The model can be used to predict the effect of wake passing frequency on compressor pressure rise effectively. (2) The key factor of wake/boundary layer interaction is local pressure gradient that changes with wake,which leads to pressure rise finally.
-
[1] Halstead D E,Wisler D C,Okiishi T H,et al.Boundary layer development in axial compressor and turbine Part 1 of 4:composite picture[J].Journal of Turbomachinery,1997,119(1):114-127. [2] 邹正平,叶建,刘火星.低压涡轮内部流动及其气动设计研究进展[J].力学进展,2007,137(4):551-562. ZOU Zhengping,YE Jian,LIU Huoxing,et al.Research progress on low pressure turbine internal flows and related aerodynamic design[J].Advances in Mechanics,2007,137(4):551-562.(in Chinese) [3] Howell R J,Hodson H P,Schulte V,et al.Boundary layer development in the BR710 LP turbines:the implementation of high-lift and ultra-high-lift concepts[J].Journal of Turbomachinery,2002,124(3):385-392. [4] Ottavy X,Vilmin S,Hodson H,et al.The effect of wake-passing unsteadiness over a highly loaded compressor-like flat plate[J].Journal of Turbomachinery,2004,126(1):13-23. [5] Hilgenfeld L,Pfitzner M.Unsteady boundary layer development due to wake passing effects on a highly loaded linear compressor[J].Journal of Turbomachinery,2004,126(4):493-500. [6] Soranna F,Chow Y,Uzol O,et al.The effect of IGV wake impingement on a rotor boundary layer .AIAA Paper 2006-1305,2006. [7] 李志平.轴流压气机实现非定常耦合流型的实验研究 .北京:北京航空航天大学,2006. LI Zhiping.Experimental investigation of realizing unsteady cooperative flow type in axial-flow compressor .Beijing:Beijing University of Aeronautics and Astronautics,2006.(in Chinese) [8] 毛明明,宋彦萍,王仲奇.跨音压气机动静干涉效应的数值研究[J].航空动力学报,2007,22(9):1468-1474. MAO Mingming,SONG Yanping,WANG Zhongqi.Numerical research on influence of rotor-stator interactions in transonic compressor[J].Journal of Aerospace Power,2007,22(9):1468-1474.(in Chinese) [9] 郑新前,侯安平,周盛.二维扩压叶栅非定常分离流控制途径探索[J].力学学报,2003,35(5):599-605. ZHENG Xinqian,HOU Anping,ZHOU Sheng.Investigation on ways to control unsteady seperated flow in 2D compressor cascade[J].Acta Mechanica Sinica,2003,35(5):599-605.(in Chinese) [10] Mailach R,Lehmann I,Vogeler K.Periodical unsteady flow within a rotor blade row of an axial compressor Part Ⅰ:flow field at midspan[J].Journal of Turbomachinery,2008,130(4):041004(11 pages). [11] Van Zante D E,Adamczyk J J,Strazisar A J,et al.Wake recovery performance benefit in a high-speed axial compressor[J].Journal of Turbomachinery,2002,124(2):275-284. [12] Peltonen R.Viscous-inviscid method for airfoil analysis and design for aviation and windmills[J].Journal of Aircraft,2006,43(4):1069-1081.
