微小型航空发动机滚动轴承复合润滑冷却技术

李果; 韩树军; 丁水汀; 杜发荣

微小型航空发动机滚动轴承复合润滑冷却技术

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 2651
- HTML浏览量: 58
- PDF量: 51
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-14
- 修回日期: 2011-03-16
- 刊出日期: 2011-08-28

Complex lubrication and cooling technology of rolling bearing on micro aero-engines

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 通过CFD(计算流体动力学)分析,研究了调节喷入轴承腔内的混合油流量对腔内压力、气液两相分布规律的影响以及油气比的变化对轴承润滑冷却效果的影响.结果表明:混合油流量增大时,油气比增大,但轴承腔内压力分布规律基本不变,滚珠和保持架上受力不均效果增加;气液两相在轴承腔上游分布不均匀,滚珠位置对分布有影响;滚珠和保持架上油膜厚度分布不均,混合油流量的增加并不代表润滑效果的提升;混合油的冷却作用大于空气,油气比增大时可以增强轴承的冷却效果.
- 微小型航空发动机 /
- 轴承腔 /
- 油气比 /
- 润滑 /
- 冷却
Abstract: Based on computational fluid dynamics (CFD) method,the pressure and gas/liquid distribution in rolling bearing chamber and the effect of lubrication and cooling through varied gas-oil ratio were researched.The results show that the pressure distribution is not clearly changed with the increase of gas-oil ratio but the inhomogeneous force is enlarged in ball and cage.The gas/liquid two-phase flow distribution is not homogenized in rolling bearing chamber upstream,and then gradually becomes regular downstream and the position of ball influences the two-phase flow distribution.The thickness of oil slick distribution is not homogenized and the effect of lubrication is not enhanced with oil increase.The cooling effect of rolling bearing mainly depends on the gas-oil ratio and the large gas-oil ratio can enhance cooling effect.
- micro aero-engine /
- bearing chamber /
- gas-oil ratio /
- lubrication /
- cooling

HTML

参考文献(17)

[1]	郑龙席,王茉瑚.油雾润滑在微型航空涡轮发动机上的应用[J].润滑与密封,2003(4):87-89. ZHENG Longxi,WANG Mohu.Application of oil mist lubrication technology on micro turbo engine[J].Lubrication Engineering,2003(4):87-89.(in Chinese)
[2]	田爱华,王毅间,关金贵,等.气液两相流体润滑技术在滚动轴承中的试验研究[J].吉林化工学院学报,2003,20(3):73-75. TIAN Aihua,WANG Yijian,GUAN Jingui,et al.Experimental study on the bubbly liquid lubrication technology in the spindle bearing[J].Journal of Jilin Institute of Chemical Technology,2003,20(3):73-75.(in Chinese)
[3]	Prince M J,Blanch H W.Bubble coalescence and break-up in air-sparged bubble columns[J].AIChE Journal,1990,36(10):1485-1499.
[4]	Lee C W,Palma P C,Simmons K,et al.Comparison of computational fluid dynamics and particle image data for the airflow in an aeroengine bearing chamber[J].Transactions of the ASME,Journal of Engineering for Gas and Turbines Power,2005,127(10):697-703.
[5]	杨和中,刘厚飞.Turbolub油气润滑技术(一)[J].润滑与密封,2003(1):107-110. YANG Hezhong,LIU Houfei.Turbolub oil-air lubrication technology Part 1[J].Lubrication Engineering,2003(1):107-110.(in Chinese)
[6]	吴昊天,陈国定.轴承腔油气两相泡沫流动的数值研究[J].机械工程学报,2008,44(9):70-75. WU Haotian,CHEN Guoding.Numerical research on two-phase gas/oil bubble flow in bearing chamber[J].Chinese Journal of Mechanical Engineering,2008,44(9):70-75.(in Chinese)
[7]	吴昊天,陈国定.气液两相流对发动机主轴承润滑性能影响的分析[J].机械科学与技术,2007,26(2):217-220. WU Haotian,CHEN Guoding.Influence of gas/liquid two-phase flow on lubrication performance of an engine bearing[J].Mechanical Science and Technology,2007,26(2):217-220.(in Chinese)
[8]	Maqableh A,Simmons K,Hibberd S,et al.CFD modeling of three-component air/oil flow and heat transfer in a rotating annulus //Proceedings of the 11th International Conference of CFD.Vancouver,Canada:IME,2003:192-200.
[9]	Busam S,Glahn A,Witting S.Internal bearing chamber wall heat transfer as a function of operating conditions and chamber geometry[J].Transactions of the ASME,Journal of Engineering for Gas Turbines and Power,2000,122(4):314-320.
[10]	何立东,闫通海,王凡.气液两相流体润滑机理的试验研究[J].润滑与密封,1996(1):33-36. HE Lidong,YAN Tonghai,WANG Fan.Experimental study on lubrication mechanism of bubby liquid[J].Lubrication Engineering,1996(1):33-36.(in Chinese)
[11]	Glahn A,Witting S.Two-phase flow in aero engine bearing chambers:characterization of oil film flows[J].Transactions of the ASME,Journal of Engineering for Gas and Turbines Power,1996,118(7):578-583.
[12]	康宁,曾文彬.空气压力对油雾发生器雾化特性的影响[J].润滑与密封,2009,34(8):14-16. KANG Ning,ZENG Wenbin.Effect of air pressure on mist characteristics of oil mist lubrication device[J].Lubrication Engineering,2009,34(8):14-16.(in Chinese)
[13]	康宁,曾文彬.温度及油温对油雾发生器雾化特性的影响[J].润滑与密封,2009,34(12):14-17. KANG Ning,ZENG Wenbin.Effect of air temperature and oil temperature on mist characteristics of oil mist lubrication device[J].Lubrication Engineering,2009,34(12):14-17.(in Chinese)
[14]	ANSYS,Inc.Multiphase flow modeling[M]//ANSYS CFX-Solver Modeling Guide ANSYS CFX Release 11.0.Canonsburg,PA:ANSYS,Inc.,2006:141-178.
[15]	ANSYS,Inc.Multiphase flow theory[M]//ANSYS CFX-Solver Theory Guide ANSYS CFX Release 11.0.Canonsburg,PA:ANSYS,Inc.,2006:123-184.
[16]	Astridge D G,Smith C F.Heat generation in high-speed cylindrical roller bearings //Proceedings of the Institute of Mechanical Engineers,Elasto-hydrodynamic Lubrication.Leeds,UK:IME,1973:83-94.
[17]	刘志全,张永红,苏华.高速滚动轴承热分析[J].润滑与密封,1998(4):66-68. LIU Zhiquan,ZHANG Yonghong,SU Hua.Thermal analysis of high speed rolling bearings[J].Lubrication Engineering,1998(4):66-68.(in Chinese)
