气量分配对轴径向旋流杯燃烧室贫熄边界的影响

谢法; 黄勇; 苗辉; 胡斌

气量分配对轴径向旋流杯燃烧室贫熄边界的影响

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 1848
- HTML浏览量: 1
- PDF量: 30
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-25
- 修回日期: 2010-11-10
- 刊出日期: 2011-08-28

Effects of airflow split and primary holes arrangement on the lean blowout limits of a combustor with axial-radial swirl cup

National Key Laboratory Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 针对轴径向旋流杯燃烧室,研究了头部进气面积及主燃孔布局对此类燃烧室贫熄特性的影响.实验结果表明:减小一级轴向旋流器进气面积和增加主燃孔个数对燃烧室贫熄性能有较大影响.一级进气面积减小20%可拓宽贫熄边界9.7%;增加主燃孔为4个时,燃烧室贫熄边界变宽约7.6%.此外,增加一级进气面积20%,改变二级进气面积20%及改变主燃孔个数为2个等情况对燃烧室贫熄边界影响较小.
- 燃烧室 /
- 轴径向旋流杯 /
- 气量分配 /
- 主燃孔布局 /
- 贫油熄火
Abstract: An experiment was conducted for studying the effect of the variations of dome air entry areas and the arrangements of primary holes on the lean blowout (LBO) limits of a single dome rectangular model combustor with axial-radial swirl cup.The experimental results show that the decrease of air entry areas of the primary axial-swirler and the increase of primary holes' number have great effect on the LBO limits of the combustors.Decreasing of air entry areas into the primary axial-swirler by 20% will improve the combustor lean blowout limits about 9.7%,and increase of the number of primary holes to 4 will improve the combustor lean blowout limits about 7.6%.Besides,increase of air entry areas into the primary axial-swirler by 20%,change of air entry areas into the secondary radial-swirler by 20% and change of the number of primary holes to 2 have little effect on the combustor LBO limits.
- combustor /
- axial-radial swirl cup /
- airflow split /
- primary hole arrangements /
- lean blowout

HTML

参考文献(15)

[1]	Bahr D W.Technology for the design of high temperature rise combustors.AIAA Paper 85-1292,1985.
[2]	Zukowski E E,Marble F E.The role of wake transition in the process of flame stabilization on bluff bodies[M]//AGARD Combustion Researches and Reviews.London:Butterworth Scientific Publishers,1955:167-180.
[3]	Plee S L,Mellor A M.Characteristic time correlation for lean blowoff of bluff-body-stabilized flames[J].Combustion and Flame,1979,35:61-80.
[4]	Longwell J P,Frost E E,Weiss M A.Flame stability in bluff body recirculation[J].Journal of Industrial and Engineering Chemistry,1953,45(8):1629-1633.
[5]	Ballal D R,Lefebvre A H.Weak extinction limits of turbulent flowing mixtures[J].Journal of Engineering for Power,1979,101(3):343-348.
[6]	Ballal D R,Lefebvre A H.Weak extinction limits of turbulent heterogeneous fuel/air mixtures[J].Journal of Engineering for Power,1980,102(2):416-421.
[7]	XIE Fa,HUANG Yong,WANG Fang,et al.Visualization of the lean blowout process in a model combustor with a swirl cup.ASME Paper 2010-GT-22534,2010.
[8]	徐浩鹏,王方,黄勇,等.头部气量分配对旋流杯结构燃烧室贫熄性能的影响[J].航空动力学报,2009,24(2):347-352. XU Haopeng,WANG Fang,HUANG Yong.Effects of flow split among swirlers and primary holes on the lean blow-off limits of a combustor with swirl cup[J].Journal of Aerospace Power,2009,24(2):347-352.(in Chinese)
[9]	Ateshkadi A,McDonell V G,Samuelsen G S.Effect of mixer geometry on fuel spray distribution,emission and stability.AIAA Paper 98-0247,1998.
[10]	Ateshkadi A,McDonell V G,Samuelsen G S.Lean blowout model for a spray-fired swirl-stabilized combustor[J].Proceedings of the Combustion Institute,2000,28(1):1281-1288.
[11]	Mongia H C,Vermeersch M,Thomsen D D,et al.A simple reactor based approach for correlating lean blowout of turbo-propulsion engine combustors.AIAA Paper 2001-3240,2001.
[12]	Mongia H C,Michael L,Vermeersch M,et al.Data reduction and analysis (DRA) for emissions and lean blowout.AIAA Paper 2003-0823,2003.
[13]	Mongia H C.Perspective of combustion modeling for gas turbine combustors.AIAA Paper 2004-156,2004.
[14]	Mongia H C.Recent progress in comprehensive modeling of gas turbine combustion.AIAA Paper 2008-1445,2008.
[15]	徐浩鹏.旋流杯结构燃烧室下游流场特性及贫油熄火特性研究.北京:北京航空航天大学,2007. XU Haopeng.A research of the downstream flowfields and lean blowout limits of combustors with swirl cups.Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
