FRS技术对瞬态高速喷流的可视化研究

王晟; 胡志云; 张振荣; 刘晶儒; 叶景峰; 张立荣

FRS技术对瞬态高速喷流的可视化研究

西北核技术研究所激光与物质相互作用国家重点实验室,西安 710024

计量
- 文章访问数: 1501
- HTML浏览量: 62
- PDF量: 28
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-09
- 修回日期: 2011-01-13
- 刊出日期: 2011-08-28

Research on visualization of transient high speed exhaust flow by FRS technique

State Key Laboratory of Laser Interaction with Matter, Northwest Institute of Nuclear Technology,Xi'an 710024,China

摘要

摘要: 为了诊断瞬态高速喷流的结构特征,开展了基于分子滤波瑞利散射(FRS)技术的可视化研究.介绍了FRS技术的基本原理,分析了散射光的多普勒频移对诊断的影响.针对瞬态高速喷流特点,建立了FRS诊断系统,设计了两种不同的激光入射方式.采用与流场方向垂直的激光入射方式,获得了喷流与空气作用的湍流结构.而采用与流场轴向平行的激光入射方式,则获得了喷流自身的结构.FRS技术对瞬态高速喷流的可视化研究,对研究超声速湍流混合层流场具有重要指导意义.
- 激光光谱 /
- 湍流结构 /
- 可视化 /
- 分子滤波 /
- 瑞利散射
Abstract: A visualization technique based on of molecular filtered Rayleigh scattering (FRS) was studied for diagnosing the structures of transient high speed exhaust flow.The diagnostics system was composed of a narrow line width laser,a molecular/atomic absorption filter and a collection device such as ICCD(intensified charge coupled device).The absorption filter was used to modify the spectra of the Rayleigh scattering signal from the flow field illuminated by a laser sheet from a Nd : YAG (neodymium-doped yttrium aluminium garnet) pulsed laser.The laser was tuned to an absorption line of iodine vapor contained in the filter.This caused background scattering from solid particles and surface to be strongly absorbed,while much of Doppler broadened Rayleigh scattering was transmitted through the filter.FRS diagnostic system was described.FRS technique was used to diagnose transient high speed exhaust flows.The turbulence structures on the area of laser action were obtained.These demonstrate the ability of the FRS technique to diagnose supersonic flow.
- spectroscopy /
- turbulence structures /
- visualization /
- molecular filter /
- Rayleigh scattering

HTML

参考文献(13)

[1]	张平,程雪玲.国外燃烧诊断技术的新进展[J].固体火箭技术,1998,21(2):66-70. ZHANG Ping,CHENG Xueling.Recent development on combustion diagnostics technique[J].Journal of Solid Rocket Technology,1998,21(2):66-70.(in Chinese).
[2]	胡志云,刘晶儒,关小伟,等.燃烧场参数的激光诊断技术研究[J].强激光与粒子束,2002,14(5):702-706. HU Zhiyun,LIU Jingru,GUAN Xiaowei,et al.Study on laser diagnostics applied to combustion and flame[J].High Power Laser and Particle Beams,2002,14(5):702-706.(in Chinese)
[3]	徐翔,谢爱民,吕治国,等.聚焦纹影显示技术在激波风洞的初步应用[J].实验流体力学,2009,23(3):75-79. XU Xiang,XIE Aimin,LV Zhiguo,et al.Application of focusing schlieren visualization system in shock tunnel experiment[J].Journal of Experiments in Fluid Mechanics,2009,23(3):75-79.(in Chinese)
[4]	梁获胜,高伟,许全宏,等. 超临界航空煤油喷射到大气环境的喷射特性[J].航空动力学报 ,2009,24(6):1258-1263. LIANG Huosheng,GAO Wei,XU Quanhong,et al.Injection characteristics of the supercritical jet fuel injected into the atmospheric environment[J].Journal of Aerospace Power,2009,24(6):1258-1263.(in Chinese)
[5]	Koch A,Voges H.Planar imaging of laboratory flame and of internal combustion in an automobile engine using UV Rayleigh and fluorescence Light[J].Applied Physics B Photophysics and Laser Chemistry,1993,56(3):177-184.
[6]	Stojkovic B D,Fansler T D,Drake M C,et al.High-speed imaging of OH and soot temperature and concentration in a stratified-charge direct-injection gasoline engine[J].Proceedings of the Combustion Institute,2005,30(2):2657-2665.
[7]	Jiang L Y,Sislian J P.Rayleigh scattering in supersonic high temperature exhaust plumes.AIAA 2000-0779,2000.
[8]	Panda J,Seasholtz R G.Density fluctuation measurement in underexpanded supersonic jets using rayleigh scattering.AIAA 98-0281,1998.
[9]	Elliott G S.Toward multiple property measurements.AIAA 2001-0301,2001.
[10]	Hoffman D,Munch K U,Leipertz A.Two-dimensional temperature determination in sooting flames by filtered Rayleigh scattering[J].Optics Letters,1996,21(7):525-527.
[11]	Kearney S P,Beresh S J.A filtered Rayleigh scattering apparatus for gas phase and combustion temperature imaging.AIAA 2003-584,2003.
[12]	Tenti G,Boley C D,Desair R C D.On the kinetic model description of Rayleigh-scattering from molecular gases[J].Canadian Journal of Physics,1974,52(4):285-290.
[13]	王晟,刘晶儒,胡志云,等.参考谱线法测量倍频Nd : YAG激光器调谐波长的研究[J].激光技术,2008,33(6):565-567. WANG Sheng,LIU Jingru,HU Zhiyun,et al.Measurement of tuning wavelength of frequency-doubled Nd : YAG laser by means of reference spectrum[J].Laser Technology,2009,33(6):565-567.(in Chinese)
