桨尖喷气驱动旋翼设计中的功率匹配方法

李毅波; 马东立; 牛凌宇

桨尖喷气驱动旋翼设计中的功率匹配方法

1.
北京航空航天大学航空科学与工程学院,北京 100191
2.
北京系统工程研究所 8室,北京 100101

计量
- 文章访问数: 1847
- HTML浏览量: 0
- PDF量: 30
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-20
- 修回日期: 2011-05-16
- 刊出日期: 2011-08-28

Power-matching methodology in tip-jet drive rotor design

1.
School of Aeronautics Science and Engineering, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
The 8th Department,Beijing System Engineering Institute,Beijing 100101,China

摘要

摘要: 针对喷气旋翼内外流动高度耦合的特点,提出了喷气旋翼设计中的功率匹配方法,根据发动机喷流属性与管道流动建立起喷气驱动模型,管道流动计及面积、温度、摩擦、旋翼旋转的影响,应用经修正的叶素法计算旋翼拉力与扭矩,最后对一种喷气旋翼进行了设计,结果显示旋翼翼型相对厚度与转速是影响拉力与功率平衡的主要因素,该方法可用于总体阶段喷气旋翼设计参数的快速确定与发动机选型.
- 反作用驱动 /
- 管道流动 /
- 翼尖喷气 /
- 旋翼设计 /
- 气动力
Abstract: A power-matching methodology was promoted to decouple the interior-flow and external-flow of a tip-jet drive rotor,and a reaction drive model based on the engine exhaust gas property and duct flow condition was established,which including:influence of area,temperature,friction and rotor rotation.The rotor tension and torque was analyzed by a modified blade element method.The result shows that section thickness and rotary speed are main influential factors to the tension and power balance,and the represented method is a rapid approach to choose the jet rotor parameters in overall design stage.
- reaction drive /
- ducted flow /
- tip-jet /
- rotor design /
- aerodynamic force

HTML

参考文献(12)

[1]	Mitchell C A,Vogel B J.The canard rotor wing (CRW) aircraft:a new way to fly.AIAA 2003-2517,2003.
[2]	Head R E.Reaction drive rotors-lessons learned.AIAA-92-4279,1992.
[3]	Lee J W,Jeon K S,Kim M,et al.Rotor design for the performance optimization of canard rotor/wing aircraft//International Conference on Computational Science and its Applicaions.Glasgow:Springer Verlag,2006:932-941.
[4]	Kondor S,Heiges M.Active flow control for control of ducted rotor systems.AIAA 2001-0117,2001.
[5]	Weelden S D,Smith D E,Mullins B R.Preliminary design of a ducted fan propulsion system for general aviation aircraft.AIAA 96-0376,1996.
[6]	Crossley W A.Sizing methodology for reaction-driven,stopped-rotor vertical takeoff and landing concepts[J].Journal of Aircraft,1995,32(6):1367-1374.
[7]	Mavris D N,Tai J,Schrage D P.A multidisciplinary design optimization approach to sizing stopped rotor configurations utilizing reaction drive and circulation control.AIAA-94-4296-CP,1994.
[8]	Park K H,Goo N S,Park H C,et al.Design and test of power system for a reduced-scale tip-jet rotor using a small tubro-jet engine.AIAA 2003-6570,2003.
[9]	肖中云.旋翼流场数值模拟方法研究.绵阳:中国空气动力研究与发展中心,2007. XIAO Zhongyun.Investigation of computational modeling techniques for rotor flowfields.Mianyang:China Aerodynamics Research and Development Center,2007.(in Chinese)
[10]	Lind R,Nathman J K,Gilchrist I.Ducted rotor performance calculations and comparisons with experimental data.AIAA 2006-1069,2006.
[11]	王适存,徐国华.直升机旋翼空气动力学的发展[J].南京航空航天大学学报,2001,33(3):203-211. WANG Shicun,XU Guohua.Progress of helicopter rotor aerodynamics[J].Journal of Nanjing University of Aeronautics and Astronautics,2001,33(3):203-211.(in Chinese)
[12]	高正,陈文轩,施永正.直升机性能及稳定性和操纵性[M].北京:航空工业出版社,1990.
