侧压式进气道动态攻角特性的风洞实验

刘凯礼; 张堃元; 郭斌

侧压式进气道动态攻角特性的风洞实验

1.
南京航空航天大学能源与动力学院,南京 210016
2.
中国航天科技集团公司中国航天空气动力技术研究院,北京 100074

计量
- 文章访问数: 1731
- HTML浏览量: 2
- PDF量: 27
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-11
- 修回日期: 2010-12-03
- 刊出日期: 2011-08-28

Experiments of sidewall compression scramjet inlet on dynamic characteristic of angle-of-attack

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China
2.
China Academy of Aerospace Aerodynamics, China Aerospace Science and Technology Corporation,Beijing 100074,China

摘要

摘要: 为了研究攻角导致的来流条件非定常变化对高超声速进气道性能的影响,以一个设计马赫数为6的侧压式进气道为研究对象,结合数值模拟的方法,在马赫数为3.85条件下进行了攻角动态变化的风洞实验,攻角变化范围为0°~8.2°,最大频率达到10.4Hz.研究结果表明:工作在大攻角时,侧压式进气道出现不起动现象,流场特征出现很大变化;攻角动态变化时,进气道重复出现起动-不起动-再起动现象,由于受到壁面运动的影响,壁面点压力随攻角的变化曲线出现一定的迟滞现象,这在不起动时尤为明显;当进气道攻角动态频率增加时,进气道不起动时的攻角逐渐增加,而再起动时的攻角逐渐减小.
- 高超声速进气道 /
- 不起动 /
- 风洞实验 /
- 攻角动态变化 /
- 非定常流动
Abstract: In order to research the influence of dynamic angle-of-attack on the performance of hypersonic inlet,wind tunnel experiments were conducted on a sidewall compression scramjet inlet with Ma=3.85,range of angle-of-attack 0°~8.2° and frequency up to 10.4 Hz.The present work suggests that:with the high angle-of-attack,the inlet could work in unstart mode,and flow field features are significantly altered and also analyzed by a computational fluid dynamics (CFD) solver.In the dynamic process of angle-of-attack,the inlet could go through a start-unstart-restart process but the pressure on the wall has the hysteresis effect,especially when the inlet is unstart.With the rise of frequency,the value of unstarting angle-of-attack could increase and restarting value could decrease in the oscillation.
- hypersonic inlet /
- unstart /
- wind tunnel experiment /
- dynamic angle-of-attack /
- unsteady flow

HTML

参考文献(12)

[1]	Tartabini P V,Bose D M,Thornblom M N.Mach 10 stage separation analysis for the X43-A.AIAA 2006-1038,2006.
[2]	王翼.高超声速进气道启动问题研究.长沙:国防科学技术大学,2008. WANG Yi.Investigation on the starting characteristics of hypersonic inlet.Changsha:National University of Defense Technology,2008.(in Chinese)
[3]	Mirmirani M,Wu C.Modeling for control of a generic airbreathing hypersonic vehicle.AIAA 2005-6256,2005.
[4]	Bahm C,Baumann E,Martin J,et al.The X-43A Hyper-X Mach 7 flight 2 guidance,navigation,and control overview and flight test results.AIAA 2005-3275,2005.
[5]	Hass N E,Smart M K,Paull A.Flight data analysis of HyShot 2.AIAA 2005-3354,2005.
[6]	Walker S,Rodgers F,Paull A,et al.HyCAUSE flight test program.AIAA 2008-2580,2008.
[7]	梁德旺,袁化成,张晓嘉.影响高超声速进气道起动能力的因素分析[J].宇航学报,2006,27(4):714-719. LIANG Dewang,YUAN Huacheng,ZHANG Xiaojia.Research on the effects of start ability of hypersonic inlet[J].Journal of Astronautics,2006,27(4):714-719.(in Chinese)
[8]	常军涛,于达仁,鲍文.攻角引起的高超声速进气道不起动/再起动特性分析[J].航空动力学报,2008,23(5):816-821. CHANG Juntao,YU Daren,BAO Wen.Characteristic analysis of unstart/restart of hypersonic inlets caused by variations of attack angle of freestream[J].Journal of Aerospace Power,2008,23(5):816-821.(in Chinese)
[9]	柳长安,吴宝元,杨铁成.进气道俯仰振荡状态的非定常数值仿真[J].火箭推进,2008,34(3):23-26. LIU Changan,WU Baoyuan,YANG Tiecheng.Unsteady simulation of the pitching intake[J].Journal of Rocket Propulsion,2008,34(3):23-26.(in Chinese)
[10]	刘凯礼,张堃元.迎角动态变化对二元高超声速进气道起动特性的影响[J].航空学报,2010,31(4):709-714. LIU Kaili,ZHANG Kunyuan.Effect of dynamic angle-of-attack on unsteady aerodynamic characteristics of 2-D hypersonic inlet[J].Acta Aeronautica et Astronautica Sinica,2010,31(4):709-714.(in Chinese)
[11]	郭斌,张堃元.攻角动态变化的侧压式进气道风洞实验[J].航空动力学报,2009,24(7):1601-1605. GUO Bin,ZHANG Kunyuan.Wind tunnel experiment of sidewall compression inlet with adjustable attack angle[J].Journal of Aerospace Power,2009,24(7):1601-1605.(in Chinese)
[12]	郭斌,张堃元.攻角动态变化对侧压式进气道起动特性影响的风洞试验[J].航空动力学报, 2009,24(10):2221-2227. GUO Bin,ZHANG Kunyuan.Wind tunnel experiment of the influence of dynamic change of attack angle on start property of sidewall compression scramjet inlet[J].Journal of Aerospace Power,2009,24(10):2221-2227.(in Chinese)
