基于螺旋桨特性的活塞发动机涡轮废气阀的调节

胡延领; 徐斌; 杨世春

基于螺旋桨特性的活塞发动机涡轮废气阀的调节

北京航空航天大学交通科学与工程学院,北京 100191

计量
- 文章访问数: 2181
- HTML浏览量: 224
- PDF量: 36
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-27
- 修回日期: 2010-11-18
- 刊出日期: 2011-08-28

Regulating turbine exhaust valve about piston engine based on analyzing propeller

School of Transportation Science and Engineering, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 通过发动机螺旋桨功率特性分析,对巡航状况下增压发动机涡轮废气调节阀的调节规律进行了研究,并且预测飞机的经济运行状态.对飞机在4000m海拔高度以恒定速度180km/h巡航工况进行了研究,调节涡轮废气放气阀开度控制空气盒的目标压力,桨距角的变化随螺旋桨特性曲线进行调节.运行的结果显示,通过变桨距调节和涡轮废气阀调节的共同作用,可实现与增压器匹配的压气机运行在68%~76%的高效率区域.
- 活塞发动机 /
- 涡轮废气阀调节 /
- 螺旋桨特性 /
- 涡轮增压 /
- 仿真分析
Abstract: The regulation of turbocharger exhaust valve was studied in cruising condition by analysis of engine propeller's power characteristic.The economy of aircraft operation was also predicted.Cruising condition of constant 180km/s was researched at 4000 meters altitude,the target pressure of air box could be reached by adjusting exhaust valve,and the propeller pitch was determined by propeller characteristic map.The results show that compressor matched with turbocharger is working within 68%~76% high efficiency area by regulating propeller pitch and turbocharger exhaust valve at constant speed of the airplane.
- piston engine /
- turbine exhaust valve adjustment /
- propeller characteristic /
- turbocharger /
- simulation analysis

HTML

参考文献(12)

[1]	王兴海,马震,郑勇.无人机用小型航空活塞发动机的发展//尖兵之翼-2006中国无人机大会论文集.北京:中国航空学会,2006:523-527.
[2]	郭宝录,李朝荣,乐洪宇.国外无人机技术的发展动向与分析[J].舰船电子工程,2008,28(9):46-49. GUO Baolu,LI Chaorong,LE Hongyu.Development trend and analysis of the technology of the abroad UAV[J].Ship Electronic Engineering,2008,28(9):46-49.(in Chinese)
[3]	刘艳华.活塞发动机与无人机性能匹配分析.北京:尖兵之翼-2006中国无人机大会,2006.
[4]	刘艳华,孙颖,孙智孝.活塞发动机与无人机性能匹配分析[J].飞机设计,2007,27(4):10-12. LIU Yanhua,SUN Ying,SUN Zhixiao.Performance matching of piston engine to unmanned aerial vehicle[J].Aircraft Design,2007,27(4):10-12.(in Chinese)
[5]	张学平.小型无人机活塞式发动机高度特性.西安:西北工业大学,2001.(in Chinese) ZHANG Xueping.Mini-UAV piston engine characteristics on the altitude.Xi'an:Northwestern Polytechnical University,2001.(in Chinese)
[6]	王少海,丁松滨.螺旋桨小型无人机总体参数和性能参数统计分析.天津:中国航空学会维修分会2008年学术年会,2008.
[7]	刘沛清.空气螺旋桨理论及其应用[M].北京:北京航空航天大学出版社,2006.
[8]	Gamma Technologies Inc. Gt-Post user's manual,Vertion 6.1[M].America:Gamma Technologies,Inc.,2004.
[9]	林海英,龙向阳.某型增压航空活塞发动机仿真研究[J].航空动力学报,2009,24(6):1332-1338. LIN Haiying LONG Xiangyang.Simulation study of an aero-piston engine with single stage turbocharger[J].Journal of Aerospace Power,2009,24(6):1332-1338.(in Chinese)
[10]	马蓉,刘沛清,胡颖.高空无人机螺旋桨的气动分析研究[J].航空科学技术,2007(1):35-38. MA Rong,LIU Peiqing,HU Ying.Aerodynamic characteristics study for high altitude UAV propeller[J].Aeronautical Science and Technology,2007(1):35-38.(in Chinese)
[11]	唐梓杰,丁水汀,杜发荣,等.航空二冲程活塞发动机与定距螺旋桨的匹配研究[J].航空动力学报,2010,25(2):379-383. TANG Zijie,DING Shuiting,DU Farong,et al.Method for match of two-stroke piston engine and set propeller[J].Journal of Aerospace Power,2010,25(2):379-383.(in Chinese)
[12]	Kotwani K,Sane S K,Arya H,et al.Experimental characterization of propulsion system for mini aerial vehicle//Proccedings of 31st National Conference on FMFP.Kolkata:Jadavpur University,2004:1-8.
