涡轮叶片复合疲劳特性曲线及其规律的试验

闫晓军; 孙瑞杰; 邓瑛; 刘芝娜; 聂景旭

涡轮叶片复合疲劳特性曲线及其规律的试验

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家自然科学基金(10872015); 教育部“新世纪优秀人才支持计划”(NCET-06-0178); 航空科学基金(2008ZB51017); 全国优秀博士学位论文作者专项资金(200351)

计量
- 文章访问数: 1967
- HTML浏览量: 213
- PDF量: 85
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-28
- 修回日期: 2010-11-02
- 刊出日期: 2011-08-28

Experimental study on fatigue curve law of turbine blade under combined high and low cycle loading

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 为了解高周振动载荷对于涡轮叶片高温疲劳性能的影响,对某型涡轮叶片进行高低周复合疲劳试验.试验结果表明,在低周载荷基础上叠加高频振动载荷,显著缩短了叶片的疲劳寿命;复合疲劳的分散性很大,且不存在疲劳极限,当叶片高周循环次数超过10⁷时,继续试验叶片仍会发生断裂;在双对数坐标下,叶片的振动应力与其高周循环寿命成线性关系,即复合疲劳特性曲线(应力-寿命曲线、概率-应力-寿命曲线)服从双对数线性规律,进一步研究发现该规律对于高温合金材料的复合疲劳特性曲线具有普遍性.
- 涡轮叶片 /
- 高低周复合疲劳 /
- 振动应力 /
- 疲劳特性曲线 /
- 双对数线性
Abstract: The effect of the high cycle vibration load on the high-temperature fatigue properties of the turbine blade were addressed.Combined high and low cycle fatigue tests were carried out on several blade specimens.The results show that the superposition of high-frequency vibration on low-cycle load can significantly reduce the fatigue life of the blade.It is noteworthy that combined high and low cycle fatigue has two features:great dispersion and no fatigue limit.The former is exhibited by much broader life range than the low cycle fatigue (LCF) test,and the latter indicated by fracture of the blades over 10⁷ high cycles (which is considered as the life limit of the metal materials for the invariable-amplitude fatigue).In addition,the fatigue data suggest a double logarithmic linear relationship between vibration stress level and the combined fatigue life.Further research has found that the law for superalloys operates universally.
- turbine blade /
- combined high and low cycle fatigue /
- vibration stress /
- fatigue curve /
- double logarithmic linear

HTML

参考文献(16)

[1]	陆榕海,廖振魁.略论发动机涡轮叶片的振动疲劳[J].洪都科技,1997:19-23. LU Ronghai,LIAO Zhenkui.Briefing on vibration fatigue of engine turbine blade[J].Hongdu Science and Technology,1997:19-23.(in Chinese)
[2]	Cesare M A,Sues R H,Wu Y T.Probabilistic high cycle fatigue of jet engine blades.AIAA-2001-1379,2001.
[3]	Naeem M,Singh R,Probert D.Implications of engine deterioration for a high-pressure turbineblade's low-cycle fatigue life-consumption[J].International Journal of Fatigue,1999,21(8):831-847.
[4]	Salam I,Tauqir A,Khan A Q.Creep-fatigue failure of an aero engine turbine blades[J].Engineering Failure Analysis,2002,9(3):335-347.
[5]	王海清.DZ-22定向合金高低周复合疲劳特性研究 //全国热疲劳学术会议论文集.大连:中国金属学会,1998:63-69.
[6]	侯学勤,刘新灵,陶春虎.FGH95合金高低周复合疲劳行为[J].粉末冶金材料科学与工程,2008,13(4):201-207. HOU Xueqin,LIU Xinling,TAO Chunhu.Combined fatigue behavior of low-and-high cycle stress for FGH95 alloy[J].2008,13(4):201-207.(in Chinese)
[7]	Oakley S Y,Nowell D.Prediction of the combined high- and low-cycle fatigue performance of gas turbine blades after foreign object damage[J].International Journal of Fatigue,2007,29(1):69-80.
[8]	Hou N X,Wen Z X,Yu Q M,et al.Application of a combined high and low cycle fatigue life model on life prediction of SC blade[J].International Journal of Fatigue,2009,31(4):616-619.
[9]	王红,左华付,何训,等.某航空发动机第三级涡轮叶片失效分析[J].失效分析与预防,2007,2(1):24-28. WANG Hong,ZUO Huafu,HE Xun,et al.Failure analysis of 3rd turbine blade of aero-engines[J].Failure Analysis and Prevention,2007,2(1):24-28.(in Chinese)
[10]	王时越,李建云,刘其勇.高低周复合载荷下的P-S-N曲线研究[J].昆明理工大学学报,2006,31(2):90-92. WANG Shiyue,LI Jianyun,LIU Qiyong.Investigation of P-S-N curve under high-low cycle complex loading[J].Journal of Kunming University of Science and Technology,2006,31(2):90-92.(in Chinese)
[11]	Ding J,Hall R F,Bytne J,et al.Fatigue crack growth from foreign object damage under combined low and high cycle loading Part Ⅰ:experimental studies[J].International Journal of Fatigue,2007,29(7):1339-1349.
[12]	陈传尧.疲劳与断裂[M].武汉:华中科技大学出版社,2002.
[13]	YAN Xiaojun,NIE Jingxu.Creep-fatigue tests on full scale directionally solidified turbine blades[J].Journal of Engineering for Gas Turbines and Power,2008,130(4):044501.1-044501.5.
[14]	孙瑞杰,闫晓军.涡轮叶片榫齿部位疲劳/蠕变试验的新特点[J].航空动力学报,2007,22(3):419-424. SUN Ruijie,YAN Xiaojun.New characteristics of fatigue-creep tests on serration of turbine blades[J].Journal of Aerospace Power,2007,22(3):419-424.(in Chinese)
[15]	刘芝娜.全尺寸涡轮叶片高低周复合疲劳试验研究.北京:北京航空航天大学,2009. LIU Zhina.Combined fatigue test methods on full-scale aero-engine turbine blades.Beijing:Beijing University of Aeronautics and Astronautics,2009.(in Chinese)
[16]	高镇同.疲劳应用统计学[M].北京:国防工业出版社,1986.
