失谐叶盘结构振动模态局部化实验

廖海涛; 王建军; 王帅; 李其汉

失谐叶盘结构振动模态局部化实验

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家高技术研究发展计划项目(2008AA04Z403)

计量
- 文章访问数: 1635
- HTML浏览量: 1
- PDF量: 34
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-01
- 修回日期: 2010-10-27
- 刊出日期: 2011-08-28

Experimental investigation of the worst-case mode localization for a mistuned bladed disk assemblies

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 基于实际叶盘结构失谐振动模态局部化能量集中的物理特性,以及基于优化方法提出了确定失谐叶盘结构最坏状态模态局部化的方法.通过数值算例表明,该方法可以有效定量确定失谐叶盘结构最坏情形模态局部化,发现失谐跳变模态局部化现象.利用搭建的失谐叶盘模态局部化实验系统,针对典型的整体叶盘结构模型试件进行了失谐振动模态局部化实验,通过实验验证了失谐跳变模态局部化现象,实验测量与理论计算结果得到了较好的相互印证.
- 失谐叶盘结构 /
- 振动模态局部化 /
- 最坏失谐模式 /
- 失谐跳变-模态局部化现象
Abstract: Based on the vibration mode characteristics of mistuned bladed disk,the methods for analysis mode localization were presented to assess the worst-case mode localization of mistuned bladed disk,numerical example shows that the method presented is reliable and effective.An experimental investigation of a simple 12-bladed academic blisk was then presented.The purpose was to validate theoretical predictions about the occurrence of mistuning jump-localized modes and to gain greater insight into the mechanisms by which the phenomena occur.The experimental measurements of localized mode shapes were compared to predictions based on the finite element method.The experimental measurements were found to have excellent agreement with numerical simulation results.
- mistuned bladed disk /
- vibration modal localization /
- the worst mistuning pattern /
- mistuning jump-mode localization pheonmenon

HTML

参考文献(19)

[1]	王建军,李其汉,朱梓根.失谐叶片-轮盘结构系统振动局部化问题的研究进展[J].力学进展,2000,30(4):517-528. WANG Jianjun,LI Qihan,ZHU Zigen.Vibratory localization of mistuned bladed disk assemblies-a review[J].Advances in Mechanics,2000,30(4):517-528.(in Chinese)
[2]	Castanier M P,Pierre C.Modeling and analysis of mistuned bladed disk:status and emerging directions[J].Journal of Propulsion and Power,2006,22(2):384-396.
[3]	王建军,于长波,姚建尧,等.失谐叶盘振动模态局部化定量描述方法[J].推进技术,2009,30(4):457-461. WANG Jianjun,YU Changbo,YAO Jianyao,et al.Vibratory mode localization factors of mistuned bladed disk assemblies[J].Journal of Propulsion Technology,2009,30(4):457-461.(in Chinese)
[4]	王建军,于长波,李其汉.错频叶盘结构振动模态局部化特性分析[J].航空动力学报,2009,24(4):788-792. WANG Jianjun,YU Changbo,LI Qihan.Localization characteristics of vibratory mode for bladed disk assemblies[J].Journal of Aerospace Power,2009,24(4):788-792.(in Chinese)
[5]	王建军,姚建尧,李其汉.刚度随机失谐叶盘结构概率模态特性分析[J].航空动力学报,2008,23(2):256-262. WANG Jianjun,YAO Jianyao,LI Qihan.Probability characteristics for vibratory mode of bladed disk assemblies with random stiffness mistuning[J].Journal of Aerospace Power,2008,23(2):256-262.(in Chinese)
[6]	于长波,王建军,李其汉.错频叶盘结构的概率模态局部化特性分析[J].航空动力学报,2009,24(9):2040-2045. YU Changbo,WANG Jianjun,LI Qihan.Probability characteristics for vibratory mode of detuned bladed disk assemblies[J].Journal of Aerospace Power,2009,24(9):2040-2045.(in Chinese)
[7]	Klauke T,Kuhhorn A,Beirow B,et al.Numerical investigations of localized vibrations of mistuned blade integrated disks(blisks)[J].ASME Journal of Turbomachinery,2009,131:031002-01/11.
[8]	杨智春,杨飞.T尾结构振动的模态局部化判据研究[J].力学学报,2010,42(2):290-299. YANG Zhichun,YANG Fei.Mode localization prediction criterion for T-tail structure[J].Chinese Journal of Theoretical and Applied Mechanics,2010,42(2):290-299.(in Chinese)
[9]	杨智春,杨飞.失调参数对T尾结构振动模态局部化的影响[J].航空学报,2009,30(12):2328-2334. YANG Zhichun,YANG Fei.Effect of mistuned parameters on mode localization of T-tail structure[J].Acta Aeronautica et Astronautica Sinica,2009,30(12):2328-2334.(in Chinese)
[10]	Kruse M J,Pierre C.An experimental investigation of vibration localization in bladed disks,Part Ⅰ:free response proc.Orlando,Florida,USA:42nd ASME Gas Turbine and Aeroengine Cong.,1997.
[11]	Gordon R W,Hollkamp J J.An experimental investigation of non-uniform damping in bladed disks.AIAA-98-3747,1998.
[12]	Gordon R W,Hollkamp J J.An experimental investigation of piezoelectric coupling in jet engine fan blades.AIAA-2000-1700,2000.
[13]	Hollkamp J J,Gordon R W.Modal test experience with a jet engine fan model[J].Journal of Sound and Vibration,2001,248(1):151-165.
[14]	涂杰.谐调和失谐叶盘结构试验件振动模态特性实验与分析.北京:北京航空航天大学,2007. TU Jie.Experiment and analysis of vibration modes in tuned and mistuned blade disks.Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
[15]	LIAO Haitao,WANG Jianjun,LI Qihan.Mistuning forced response characteristics analysis of mistuned bladed disks[J].Journal of Engineering for Gas Turbines and Power,2010,132(12):122501.1-122501.11.
[16]	廖海涛,王建军,李其汉.随机失谐叶盘结构失谐特性分析[J].航空动力学报,2010,25(1):160-168. LIAO Haitao,WANG Jianjun,LI Qihan.Mistuning characteristics analysis of mistuned bladed disk assemblies[J].Journal of Aerospace Power,2010,25(1):160-168.(in Chinese)
[17]	王帅.整体叶盘结构失谐识别方法及动态特性实验研究.北京:北京航空航天大学,2010. WANG Shuai.Mistuning identification theory and daynamic characteristic experiment for integrally blade disk.Beijing:Beijing University of Aeronautics and Astronautics,2010.(in Chinese)
[18]	王建军,卿立伟,李其汉.旋转叶片频率转向与振型转换特性[J].航空动力学报,2007,22(1):8-11. WANG Jianjun,QING Liwei,LI Qihan.Frequency veering and mode shape interaction for rotating blades[J].Journal of Aerospace Power,2007,22(1):8-11.(in Chinese)
[19]	王红建,贺尔铭,赵志彬.叶盘系统频率转向与模态耦合特性分析[J].航空动力学报,2008,23(12):2214-2218. WANG Hongjian,HE Erming,ZHAO Zhibin.Characteristic analysis of frequency veering and mode interaction of bladed disks[J].Journal of Aerospace Power,2008,23(12):2214-2218.(in Chinese)
