拉伸载荷下管路连接副的密封性分析

王振兴; 邱明星; 王建军

拉伸载荷下管路连接副的密封性分析

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司沈阳发动机设计研究所,沈阳 110015

基金项目: 国家高技术研究发展计划(2008AA04Z403)

计量
- 文章访问数: 1603
- HTML浏览量: 3
- PDF量: 25
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-18
- 修回日期: 2010-11-18
- 刊出日期: 2011-08-28

Sealing performance of pipeline connection under the tensile load

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
Shenyang Aeroengine Research Institute, Aviation Industry Corporation of China,Shenyang 110015,China

摘要

摘要: 研究了航空发动机钛合金管路连接副在拉伸载荷下的密封性能.首先,建立了连接副的等效刚性模型, 分析其在拉伸载荷下的受力,研究了密封面的接触力随拉伸载荷的变化规律,从机理上分析了拉伸载荷下管路连接副的密封性.第二,建立了管路连接副在拉伸载荷下的多体弹性接触模型,并对其进行有限元分析.采用初始渗透接触法,实现连接副的预紧状态,在此基础上施加拉伸载荷,然后再进行有限元求解.同时,研究了连接副密封面的接触力、接触面积和接触应力随拉力的变化规律,从而定量地分析连接副的密封性.
- 管路连接 /
- 密封 /
- 多体接触 /
- 有限元法 /
- 拉伸载荷
Abstract: The sealing performance of aircraft engine pipeline connection was investigated under the tensile load in two aspects. Firstly, the contact force change of the pipeline connection sealing surface was studied to make a mechanical analysis of the sealing performance, by establishing the equivalent rigid model and the force balance equations of the pipeline connection under tensile load. Secondly, the multi-body contact elastic model of pipeline connection was established and the numerical simulation was made by finite element method(FEM) under the pre-tightening force and tensile load, whilst the contacts with initial penetration were established to realize the implementation of preload. On the basis of the simulation results, this paper made a detailed quantitative analysis of pipeline connection's sealing performance, through investigation of contact forces, contact area and contact stress on the sealing surface.
- pipeline connection /
- sealing /
- multi-body contact /
- finite element method /
- tensile loading

HTML

参考文献(13)

[1]	彭艳萍,曾凡昌,王俊杰,等.国外航空钛合金的发展应用及其特点分析[J].材料工程,1997(10):3-6. PENG Yanping,ZENG Fanchang,WANG Junjie,et al.Development,application and feature of titanium alloys in foreign aviation industry[J].Journal of Materials Engineering,1997(10):3-6.(in Chinese)
[2]	Adib A M L,Baptista C A R,Barboza M J R,et al.Aircraft engine bleed system tubes:material and failure mode analysis[J].Engineering Failure Analysis,2007,14(8):1605-1617.
[3]	李松梅,蒋唯沧,刘建华,等.新型航空T-31钛合金导管连接件在模拟服役环境中的抗腐蚀性能研究[J].材料工程,2004(2):32-36. LI Songmei,JIANG Weicang,LIU Jianhua,et al.Study on corrosion resistance of aircraft conduit connector of T-31 titanium alloy at simulated service environment[J].Journal of Materials Engineering,2004(2):32-36.(in Chinese)
[4]	李松梅,刘建华,孙忠志,等.模拟服役环境中航空导管连接件耐蚀性能研究[J].北京航空航天大学学报,2005,31(4):430-433. LI Songmei,LIU Jianhua,SUN Zhongzhi,et al.Study on corrosion resistance of aircraft conduit connector at simulated service environment[J].Journal of Beijing University of Aeronautics and Astronautics,2005,31(4):430-433.(in Chinese)
[5]	王小刚,张方晓,黄鹏.基于ANSYS的管路锥形密封结构参数分析[J].兵工自动化,2009,28(8):25-27. WANG Xiaogang,ZHANG Fangxiao,HUANG Peng.Analysis of parameters of pipeline cone sealing structures based on ANSYS[J].Ordnance Industry Automation,2009,28(8):25-27.(in Chinese)
[6]	王小刚,张方晓,黄鹏.基于ANSYS的锥头-锥孔管路锥形密封结构分析[J].机械,2009,36(8):37-40. WANG Xiaogang,ZHANG Fangxiao,HUANG Peng.Design of cone-head & cone-hole pipeline cone sealing structure based on ANSYS[J].Machinery,2009,36(8):37-40.(in Chinese)
[7]	冉光斌,张方晓.双锥形接头密封管路联接结构的稳健设计[J].润滑与密封,2008,33(5):88-90. RAN Guangbin,ZHANG Fangxiao.Robust design method of the sealing pipeline joint structure with double-cone pipe union[J].Lubrication Engineering,2008,33(5):88-90.(in Chinese)
[8]	张淼,孟庆春,张行.无扩口管路连接件疲劳寿命预估的损伤力学-有限元法[J].航空学报,2009,30(3):435-443. ZHANG Miao,MENG Qingchun,ZHANG Xing.Damage mechanics-finite element method for fatigue life prediction of flare-free pipeline connection assemblies[J].Acta Aeronautica et Astronautica Sinica,2009,30(3):435-443.(in Chinese)
[9]	李俊昇,罗建平,孙忠志,等.HB5966-2008 24°无扩口导管连接件通用规范[S].北京:中国航空综合技术研究所,2008:1-14.
[10]	李会勋,胡迎春,张建中.利用ANSYS模拟螺栓预紧力的研究[J].山东科技大学学报,2006,25(1):57-59. LI Huixun,HU Yingchun,ZHANG Jianzhong.Study on simulating bolt pretension by using ANSYS[J].Journal of Shandong University of Science and Technology,2006,25(1):57-59.(in Chinese)
[11]	祖炳辉,付光琦,徐玉梁,等.车用柴油机缸孔在缸盖螺栓预紧力下变形的数值模拟和试验研究[J].内燃机工程,2010,37(2):98-104. ZU Binghui,FU Guangqi,XU Yuliang,et al.Numerical simulation and expermental investigation on cylinder bore deformation of automotive diesel engines under cylineder-head bolt pretightened[J].Chinese Internal Combustion Engine Engineering,2010,37(2):98-104.(in Chinese)
[12]	李婕,蔡纪宁,张秋翔,等.机械密封环过盈联接的有限元分析[J]. 润滑与密封,2009,34(8):62-65. LI Jie,CAI Jining,ZHANG Qiuxiang,et al.The finite element analysis of interference fit in mechanical seal ring[J].Lubrication Engineering,2009,34(8):62-65.(in Chinese)
[13]	周鹤群,汪中厚,谢云波,等.基于FEA的传动轴过盈配合精密分析[J].机械传动,2010,34(1):60-65. ZHOU Hequn,WANG Zhonghou,XIE Yunbo,et al.Precision analysis of interference fits for drive shaft based on FEA[J].Journal of Mechanical Transmission,2010,34(1):60-65.(in Chinese)
