七孔探针及其在叶栅二次流动测量中的应用

吴吉昌; 李成勤; 朱俊强

七孔探针及其在叶栅二次流动测量中的应用

1.
中国科学院工程热物理研究所,北京 100190
2.
中国科学院研究生院,北京 100190

基金项目: 国际合作专题项目(2010DFB70620); 国家高技术研究发展计划(2007AA050503)

计量
- 文章访问数: 1922
- HTML浏览量: 111
- PDF量: 37
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-15
- 修回日期: 2010-09-17
- 刊出日期: 2011-08-28

Seven-hole probe and its application in the secondary flow for a high-load compressor cascade

1.
Institute of Engineering Thermophysics, Chinese Academy of Sciences,Beijing 100190,China
2.
Graduate University of Chinese Academy of Sciences,Beijing 100190,China

摘要

摘要: 详细阐述了新研制的七孔探针(SHP)及其校准方法,利用亚声速风洞及自行设计的数据处理程序,获得了理想的各类无量纲参数的校准结果.依据校准结果,该七孔探针可以测量气流角与轴线偏离65°左右的复杂二次流动和旋涡流动.误差分析结果表明,校准实验能够保证气流速度和气流角的测量误差分别小于2.04%和1.99°.针对高负荷压气机平面叶栅出口截面气流角变化较大的复杂二次流动,利用该七孔探针能够得到比较准确可信的流场信息,为二次流模型的建立提供基础性的数据支持.
- 七孔探针 /
- 校准 /
- 二次流动 /
- 风洞实验 /
- 高负荷压气机叶栅
Abstract: The design and calibration methods for a new type of seven-hole probe were described,and better calibration results were obtained in this paper with the help of a subsonic wind tunnel and self-designed code on data reduction.Based on suitable distribution for all the non-dimension parameters,it indicates that the probe is capable of measuring complex secondary and vortex flow with the angle more than 65°.The error analysis based on calibration data shows that the probe can measure the flow velocity and angle at a relative error of 2.04% and 1.99°,respectively.For the complicated secondary flow at outlet of a highly-loading compressor cascade,the detailed flow field information can be captured by the probe,contributing to build up the secondary flow model in compressor passage.
- seven-hole probe /
- calibration /
- secondary flow /
- wind tunnel test /
- high-load compressor cascade

HTML

参考文献(12)

[1]	Schlichting H.Boundary-layer theory[M].6th ed.New York:McGraw-Hill,1968.
[2]	Benner M W.The Influence of leading-edge geometry on profile and secondary losses in turbine cascades.Ottawa,Canada:Carleton University,2003.
[3]	Ingram G L.Endwall profiling for the reduction of secondary flow in turbines.Durham,England:University of Durham,2003.
[4]	Gerner A A,Maurer C L.Calibration of seven-hole probes suitable for high angles in subsonic compressible flows.AIAA Paper No.82-0410,1982.
[5]	Everett K N,Durston D A,Gerner A A.The theory and calibration of non-nulling seven-hole cone probes for use in complex flow measurement.AIAA-1982-0232,1982.
[6]	齐孟卜,李京伯.测量很大流动角的七孔锥形探针的研制和低速校正.南京:南京航空航天大学科技报告,1983.
[7]	沈天荣,刘海涌,刘松龄,等.风洞七孔压力探针的校准技术[J].风机技术,2006(4):15-19. SHEN Tianrong,LIU Haiyong,LIU Songling,et al.Calibration technology of seven-hole pressure probe for wind tunnel[J].Compressor Blower & Fan Technology,2006(4):15-19.(in Chinese)
[8]	李彦,李卫东.七孔探针三维自动测速系统[J].实验技术与管理,2006,23(1):42-44. LI Yan,LI Weidong.3-D velocity automatic measuring system using 7-holes pitot tube[J].Experimental Technology and Management,2006,23(1):42-44.(in Chinese)
[9]	刘展,蔡国华.75°/45°双三角翼旋涡特性的试验研究[J].流体力学实验与测量,2003,17(2):41-44. LIU Zhan,CAI Guohua.Experimental investigation of the vortex characteristic over 75°/45° double delta wing[J].Experiments and Measurements in Fluid Mechanics,2003,17(2):41-44.(in Chinese)
[10]	顾蕴松,明晓.大迎角细长体非对称空间流场特性的试验研究[J].实验流体力学,2005,19(2):1-6. GU Yunsong,MING Xiao.Investigation of flow field characteristics on a slender body at high angle of attack[J].Experimental Fluid Mechanics,2005,19(2):1-6.(in Chinese)
[11]	杨洋,尹贵鲁,明晓.机身边条对双三角翼飞机升力特性的影响[J].空气动力学学报,2006,24(4):471-476. YANG Yang,YIN Guilu,MING Xiao.The effects of body-strake on lift characteristics of the double delta wing aircraft[J].Acta Aerodynamica Sinica,2006,24(4):471-476.(in Chinese)
[12]	孙明太,张尧卿,李鹏,等.某型反潜直升机腹部流场飞行测量研究[J].航空学报,2008,29(6):1467-1471. SUN Mingtai,ZHANG Yaoqing,LI Peng,et al.Meterage and study on flow field beneath bottom of a helicopter in flight[J].Acta Aeronautica et Astronautica Sinica,2008,29(6):1467-1471.(in Chinese)
