波瓣喷射器强化混合的数值研究

单勇; 张靖周; 朱华萍

波瓣喷射器强化混合的数值研究

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1819
- HTML浏览量: 141
- PDF量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-30
- 修回日期: 2010-12-18
- 刊出日期: 2011-09-28

Numerical study on mixing enhancement of lobed injector

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 利用FLUENT CFD(computational fluid dynamics)数值计算软件,对波瓣喷射器中无化学反应异类气体的混合过程进行了数值研究,二氧化碳气体作为主流从波瓣状狭缝中喷出,与同向空气流在混合管内进行混合.获得了两股气流相互混合过程中的速度分布、流向涡分布、组分分布等相关信息,分析了波瓣喷射器结构参数对流向涡环流强度的影响.波瓣喷射器诱导的流向涡强化了同向流动气体之间的混合效率,组分分布较为均匀.
- 波瓣喷射器 /
- 流向涡 /
- 混合特性 /
- 数值计算 /
- 强化混合
Abstract: The mixing characteristics of two different kinds of fluids with non-reaction in the lobed injector were numerically studied by using FLUENT CFD(computational fluid dynamics) software. The primary flow (CO₂) was injected from the lobed slot between two corrugated plates, and then mixed with the coflowing secondary flow (air) in the mixing duct. The velocity fields, streamwise vortice structures and species distribution were obtained to analyze the effects of lobed injector parameters on the circulation intensity of streamwise vortices. The streamwise vortices induced by the lobed injector are helpful to improve the mixing efficiency of the two coflowing fluids, and make the species distribution more uniform.
- lobed injector /
- streamwise vortice /
- mixing characteristics /
- numerical calculation /
- mixing enhancement

HTML

参考文献(12)

[1]	单勇,张靖周.波瓣喷管引射-混合器的数值研究与验证[J].推进技术,2004,25(4):320-324. SHAN Yong,ZHANG Jingzhou.Numerical computation and examination of a lobed mixer-ejector[J].Journal of Propulsion Technology,2004,25(4):320-324.(in Chinese)
[2]	张靖周,谢志荣,李立国.三维强迫混合波瓣结构流场的数值研究[J].推进技术,2001,22(3):205-208. ZHANG Jingzhou,XIE Zhirong,LI Liguo.Numerical investigation of three dimensional flow fields for forced mixer lobe configuration[J].Journal of Propulsion Technology,2001,22(3):205-208.(in Chinese)
[3]	McCormick D C,Bennett J C.Vortical and turbulent structure of a lobed mixer free shear layer[J].AIAA Journal,1994,32(9):1852-1859.
[4]	Eckerie W A,Sheibani H,Awad J.Expermental measurement of the vortex development downstream of a lobed forced mixer[J].Journal of Engineering for Gas Turbines and Power,1992,114(1):63-71.
[5]	Presz W M,Gousy R G,Morin B L.Forced mixer lobes in ejector designs .AIAA Paper 86-1614,1986.
[6]	Tsui Y Y,Wu P W.Investigation of the mixing flow structure in multilobe mixers[J].AIAA Journal,1996,34(7):1386-1391.
[7]	Hu H,Saga T,Kobayashi T,et al.Investigation of the vortex structures downstream of a lobed nozzle by mean of dual-plane stereoscopic PIV .Göttingen,Germany:4th-International Symposium on Particle Image Velocimetry,PIV'01 Paper 1020,2001.
[8]	Gore J P,Zhan N J.NO_x emission and major species concentrations in partially premixed laminar methane/air co-flow jet flames[J].Combustion and Flame,1996,105(3):414-427.
[9]	Smith L L,Majamaki A J,Lam I T,et al.Mixing enhancement in a lobed injector[J].Physics of Fluids,1997,9(3):667-678.
[10]	Strickland J H,Selerland T,Karagozian A R.Numerical simulations of a lobed fuel injector[J].Physics of Fluids,1998,10(11):2950-2956.
[11]	Mitchell M G,Smith O I,Karagozian A R.Effects of passive fuel-air mixing and emissions control via lobed injectors[J].AIAA Journal,2004,42(1):61-69.
[12]	Majamark A J,Smith O I,Karagozian A R.Passive mixing control via lobed injectors in high-speed flow[J].AIAA Journal,2003,41(4):623-632.
