波形隔板形状对通道流动和换热的影响

李莉; 徐国强; 丁水汀; 邓宏武

波形隔板形状对通道流动和换热的影响

1.
北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191
2.
华北电力大学能源动力与机械工程学院,北京 102206

计量
- 文章访问数: 1907
- HTML浏览量: 171
- PDF量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-28
- 修回日期: 2011-04-14
- 刊出日期: 2011-09-28

Effect of the shape of divider wall on heat transfer and flow resistance characteristic of passage

1.
National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
School of Energy and Mechanical Engineering, North China Electric Power University, Beijing 102206, China

摘要

摘要: 采用数值模拟的方法,对基于波形隔板结构涡轮叶片尾缘复合通道的换热和流阻特性进行研究.设计了一种直隔板和三种不同折角的波形隔板结构,研究波形角度对通道中流动和换热的影响.数值结果表明,波形隔板结构折角越小,对整个通道,换热越好,尤其是对于第1通道,换热增强最大可达30%;同时折角越小,通道的流阻系数越大;从换热和流阻的综合效果来看,150°折角波形隔板结构和直隔板结构(180°折角)相当,120°折角和90°折角波形隔板结构的综合换热效果比直隔板结构的略大.
- 换热 /
- 流阻 /
- 折角 /
- 数值模拟 /
- 涡轮叶片
Abstract: Numerical simulation was performed to obtain heat transfer and flow resistance characteristics in a channel with zigzag divider wall in the trailing edge passage of turbine blade.One traditional divider wall and three configurations of zigzag divider walls with different angles were applied to research the effect of angle on the heat transfer and flow resistance.The calculated results indicate that the heat transfer is improved with decrease of the angle of the zigzag shape.For the first passage,the highest improvement was nearly 30 percent.At the same time,the passage with small angle divider wall encountered bigger flow resistance.By comparison of integrated effect of heat transfer,the configurations with smaller angle divider walls have higher values than those with larger angle divider walls.
- heat transfer /
- flow resistance /
- angle /
- numerical simulation /
- turbine blade

HTML

参考文献(12)

[1]	Fabbri G.Heat transfer optimization in corrugated wall channels[J].International Journal of Heat and Mass Transfer,2000,43(23):4299-4310.
[2]	Rush T A,Newell T A,Jacobi A M.An experimental study of flow and heat transfer in sinusoidal wavy passages [J]. International Journal of Heat and Mass Transfer,1999, 42(9):1541-1553.
[3]	Islamoglu Y,Parmaksizoglu C.Numerical investigation of convective heat transfer and pressure drop in a corrugated heat exchanger channel[J].Applied Thermal Engineering,2004,24(1):141-147.
[4]	Nishimura T,Oka N,Yoshinaka Y,et al.Influence of imposed oscillatory frequency on mass transfer enhancement of grooved channels for pulsatile flow[J].International Journal of Heat and Mass Transfer,2000,43(13):2365-2374.
[5]	Guzmán A M,Cárdenas M J,Urzúa F A,et al.Heat transfer enhancement by flow bifurcations in asymmetric wavy wall channels[J].International Journal of Heat and Mass Transfer,2009,52(15-16):3778-3789.
[6]	Chang S W,Lees A W,Chou T C.Heat transfer and pressure drop in furrowed channels with transverse and skewed sinusoidal wavy walls[J].International Journal of Heat and Mass Transfer,2009,52(19-20):4592-4603.
[7]	Ko T H,Cheng C S.Numerical investigation on developing laminar forced convection and entropy generation in a wavy channel[J]. International Communications in Heat and Mass Transfer,2007,34(8):924-933.
[8]	Naphon P,Kornkumjayrit K.Numerical analysis on the fluid flow and heat transfer in the channel with V-shaped wavy lower plate[J].International Communications in Heat and Mass Transfer,2008,35(7):839-843.
[9]	阴继翔,郭瑞,吕萍,等.波纹通道形状对流动与换热影响的数值研究[J].太原理工大学学报,2010,41(4):428-432. YIN Jixiang,GUO Rui,LV Ping,et al.Numerical investigation of the effect of different wavy channels on flow and heat transfer[J].Journal of Tai Yuan University of Technology,2010,41(4):428-432.(in Chinese)
[10]	李海朋,刘钊,丰镇平.两种波纹板通道内的流动及换热比较[J].工程热物理学报,2008,29(10):1755-1758. LI Haipeng,LIU Zhao,FENG Zhenping.Comparison study of flow and heat transfer characteristics in two kinds of wavy channels[J].Journal of Engineering Thermophysics,2008,29(10):1755-1758.(in Chinese)
[11]	丁水汀,刘丽艳,李莉,等.涡轮叶片尾缘复合通道中隔板结构对换热特性的影响[J].航空动力学报,2006,21(3):523-527. DING Shuiting,LIU Liyan,LI Li,et al.The effect of different clapboards structure in turbine blade trailing edge complex passages on heat transfer characteristics[J].Journal of Aerospace Power, 2006,21(3):523-527.(in Chinese)
[12]	李莉,徐国强,丁水汀,等.波形隔板穿流孔孔径对通道流动和换热的影响[J].北京航空航天大学学报,2010,36(6): 690-693. LI Li,XU Guoqiang,DING Shuiting,et al.Effect of orifices diameter on heat transfer and flow resistance characteristic of passage[J].Journal of Beijing University of Aeronautics and Astronautics,2010,36(6):690-693.(in Chinese)
