直通型篦齿泄漏的特性试验

张效伟; 朱惠人; 张霞; 张文存

直通型篦齿泄漏的特性试验

1.
西北工业大学动力与能源学院,西安 71007
2.
陕西省石油化工研究设计院水处理所,西安 710054

基金项目: 国家重点基础研究发展计划(2007CB707701)

计量
- 文章访问数: 2018
- HTML浏览量: 92
- PDF量: 13
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-19
- 修回日期: 2011-01-23
- 刊出日期: 2011-09-28

Experiment on discharge characteristics of straight-through labyrinth

1.
School of Power and Energy, Northwestern Polytechnical University, Xi'an 71007
2.
Department of Water Treatment, Shannxi Research Institute of Petroleum and Chemical Industry, Xi'an 710054, China

摘要

摘要: 对广泛应用于航空发动机的直通型篦齿进行试验,测量了不同结构组合,不同工况参数下直通型篦齿的流量和压力,计算得出相应的换算流量系数,分析了倾斜角度、间隙以及转速对换算流量系数的影响,并获得经验关联式.研究表明:当进、出口气流压比较小时,篦齿换算流量系数随压比增加较快,然后增加缓慢,并渐趋于一定值;相同压比下,篦齿向来流方向倾斜角度和间隙宽度减小,换算流量系数均减小,倾斜角度存在最佳值,应在45°~60°;转速的影响过程较为复杂,在本试验范围内换算流量系数随其增加而减小.
- 航空发动机 /
- 直通式篦齿 /
- 封严特性 /
- 旋转效应 /
- 换算流量系数 /
- 倾斜角
Abstract: Experimental investigation was conducted on the discharge characteristics of the straight-through labyrinth,which was applied widely in aero-engines,under different configurations and operating parameters.Influences on the nominal discharge coefficients of the inclination angle,the clearance of the labyrinth pins and the revolving speed of the shaft were considered.Discharge flow rate and pressures at the entrance and the exit of the labyrinth were measured,and then nominal discharge coefficients and a correction equation were acquired.Moreover,comparisons of experiment data with data calculated from the classical correction equation were done.The results show that nominal discharge coefficients increase with the rising ratio of the inlet total pressure and the outlet pressure,and then tend to a certain constant for each configuration at each operating point.However,they decrease with the decreasing inclination angel and clearance of the through labyrinth in this study.Also the optimum value of inclination angel is in a range of 45°~60°.For the shaft revolving speed of the labyrinth disc,it works complicatedly,and nominal discharge coefficients decrease with its increase clearly.
- aero-engine /
- straight-through labyrinth /
- seal characteristics /
- rotation effect /
- nominal discharge coefficient /
- inclination angle

HTML

参考文献(16)

[1]	塔鲁达纳夫斯基.非接触密封[M].北京:机械工业出版社,1986.
[2]	Stargess G J.Application of CFD to gas turbine engine secondary flow system .The Labyrinth Seal,AIAA-SS-3203,1988.
[3]	纪国剑,吉洪湖,白花蕾.齿间环形凹槽结构对直通篦齿封严特性影响的数值研究[J].流体机械,2007,35(12):21-24;83. JI Guojian,JI Honghu,BAI Hualei.Numerical investigation of leakage effect of rub-groove on straight-through labyrinth seal[J].Fluid Machinery,2007,35(12):21-24;83.(in Chinese)
[4]	Rhode D L,Demko J A,Tragener U K,et al.Prediction of incompressible flow in labyrinth seals[J].Journal of Fluids Engineering,1986,108(1):19-25.
[5]	Rhode D L,Sobolik S R.Simulation of subsonic flow through a generic labyrinth seal[J].Journal of Engineering for Gas Turbines and Power,1986,108(4):674-680.
[6]	Morrison G L,Johnson M C,Tatterson G B.3-D laser anemometer measurements in a labyrinth seal[J].Journal of Engineering for Gas Turbines and Power,1991,113(1):119-125.
[7]	Michaud M,Vakili A,Meganathan A.An experimental study of labyrinth seal flow .USA:IJPGC2003-40097,2003.
[8]	吴丁毅.直通式篦齿封严特性的实验研究[J].推进技术,1997,18(3):79-82. WU Dingyi.An experimental investigation on seal Character of straight-through labyrinth[J].Journal of Propulsion Technology,1997,18(3):79-82.(in Chinese)
[9]	吴丁毅.直通式篦齿密封内部流场显示研究[J].流体机械,1997,25(2):11-15. WU Dingyi.An visual investigation on internal flow field of straight-through labyrinth[J].Fluid machinery,1997,25(2):11-15.(in Chinese)
[10]	杨军.直通型封严篦齿内流动特性试验研究及数值计算 .成都:电子科技大学,2009. YANG Jun.An experimental and numerical study on flow characteristics of straight-through labyrinth .Chengdu:Electronic Technology University,2009.(in Chinese)
[11]	张霞,张效伟,朱惠人,等.直通式篦齿封严特性的实验研究[J].航空动力学报,2010,25(8):1753-1757. ZHANG Xia,ZHANG Xiaowei,ZHU Huiren,et.al.Experimental investigation on seal characteristics of straight-through labyrinth[J].Journal of Aerospace Power,2010,25(8):1753-1757.(in Chinese)
[12]	王鹏飞,刘玉芳,郭文,等.高转速对直通型篦齿封严特性影响的试验研究[J].燃气涡轮试验与研究,2007,20(2):45-48. WANG Pengfei,LIU Yufang,GUO Wen,et al.Influence of high rotational speeds on the labyrinth sealing characteristics[J].Gas Turbine Experiment and Research,2007,5(2):45-48.(in Chinese)
[13]	刘振侠,赵海刚,张丽芬,等.静态封严篦齿内部流动与换热的数值计[J].航空动力学报,2008,23(3):449-453. LIU Zhenxia,ZHAO Haigang,ZHANG Lifen,et al.Numerical analyses of flow field and heat transfer in cavity of straight labyrinth seal at static state[J].Journal of Aerospace Power,2008,23(3):449-453.(in Chinese)
[14]	丁学俊,黄来,黄丕维,等.迷宫密封中可压流体流场的数值模拟[J].润滑与密封,2007,32(5):27-29. DING Junhai,HUANG Lai,HUANG Piwei,et.al.Numerical simulation of imcompressible flow in labyrinth seal[J].Lubrication Engineering,2007,32(5):27-29.(in Chinese)
[15]	杨军,曾军,康湧.直通型篦齿流场计算[J].燃气涡轮试验与研究,2002,15(4):13-16. YANG Jun,ZENG Jun,KANG Yong.Flow field calculation of straignht-through labyrinth[J].Gas Turbine Experiment and Research,2002,15(4):13-16.(in Chinese)
[16]	顾永泉.流体动密封(下册)[M].北京:中国石化出版社,1992.
