六管吸气式脉冲爆震发动机试验

袁成; 范玮; 彭畅新; 张群; 陈文娟; 严传俊

六管吸气式脉冲爆震发动机试验

西北工业大学动力与能源学院,西安 710072

计量
- 文章访问数: 2112
- HTML浏览量: 97
- PDF量: 15
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-23
- 修回日期: 2010-12-18
- 刊出日期: 2011-09-28

Experimental investigation on a six-tube air-breathing pulse detonation engine

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 设计了单管内径为68mm的六管吸气式脉冲爆震发动机试验系统,以汽油为燃料,空气为氧化剂,成功地进行了多循环爆震试验.结果表明:六管均能形成多次可重复的爆震波;各管之间的相互影响小;共同工作的同步性好;长时间工作起爆稳定.研究结果对多管脉冲爆震发动机的工程应用具有较大的参考价值.
- 脉冲爆震发动机 /
- 六管 /
- 共同工作 /
- 相互影响 /
- 同步性 /
- 稳定性
Abstract: A experimental system for six-tube air-breathing pulse detonation engine (PDE) with the single tube's inner diameter of 68mm was designed.Using gasoline as fuel and air as oxidizer,multi-cycle experimental study was successfully performed.The results show that all of the six tubes can obtain continuous detonation waves.The interaction among the tubes is not obvious and the engine can work synchronously and stably.The research results are very helpful to engineering applications of multi-tube PDE.
- pulse detonation engine (PDE) /
- six-tube /
- working together /
- interaction /
- synchronization /
- stability

HTML

参考文献(12)

[1]	严传俊,范玮.脉冲爆震发动机原理及关键技术[M].西安:西北工业大学出版社,2005.
[2]	Rasheed A,Furman A,Dean A J.Wave attenuation and interactions in a pulsed detonation combustor-turbine hybrid system .AIAA 2006-1235,2006.
[3]	Rasheed A,Furman A,Dean A J.Experimental investigations of an axial turbine driven by a multi-tube pulsed detonation combustor system .AIAA 2005-4209,2005.
[4]	Rasheed A,Furman A,Dean A J.Wave interactions in a multi-tube pulsed detonation combustor-turbine hybrid system .AIAA 2006-4447,2006.
[5]	Rasheed A,Furman A,Dean A J.Pressure measurements and attenuation in a hybrid multi-tube pulse detonation turbine system .AIAA 2006-1235,2006.
[6]	李建中,王家骅,唐豪,等.煤油/空气三管气动阀式脉冲爆震发动机[J].航空学报,2009,30(11):2052-2058. LI Jianzhong,WANG Jiahua,TANG Hao,et al.Kerosene/air triple-tube aero-valve pulse detonation engine[J].Acta Aeronautica et Astronautica Sinica,2009,30(11):2052-2058.(in Chinese)
[7]	李建中,王家骅,唐豪,等.煤油/空气三管脉冲爆震发动机共用尾喷管研究[J]. 航空动力学报,2008,23(5):840-844. LI Jianzhong,WANG Jiahua,TANG Hao,et al.Investigation on common nozzle of triple-tube pulse detonation engine with kerosene/air[J].Journal of Aerospace Power,2008,23(5):840-844.(in Chinese)
[8]	Ebrahimi H B,Malo-Molina F J,Merkle C L.Numerical investigation of multi-tube pulse detonation .AIAA 2003-718,2003.
[9]	Ebrahimi H B.Multidimensional analysis of multitube pulse detonation .AIAA 2003-6975,2003.
[10]	刘建文,钟诚文,赵书苗.多管脉冲爆震发动机流场数值研究[J].推进技术,2007,28(6):674-678. LIU Jianwen,ZHONG Chengwen,ZHAO Shumiao.Numerical investigation of multi-tube pulse detonation engine[J].Journal of Propulsion Technology,2007,28(6):674-678.(in Chinese)
[11]	李建中,王家骅,王春,等.共用尾喷管多管脉冲爆震发动机数值模拟研究[J].空气动力学学报,2008,26(1):96-100. LI Jianzhong,WANG Jiahua,WANG Chun,et al.Numerical investigation of multi-tube pulse detonation engine with common nozzle[J].Acta Aerodynamica Sinica,2008,26(1):96-100.(in Chinese)
[12]	黄玥,唐豪,李建中,等.多管脉冲爆震发动机共用喷管特性的数值模拟[J].南京航空航天大学学报,2009,41(4):432-438. HUANG Yue,TANG Hao,LI Jianzhong,et al.Numerical investigation on characteristic of multi-tube pulse detonation engines with different common nozzles[J].Journal of Nanjing University of Aeronautics and Astronautics,2009,41(4):432-438.(in Chinese)
