基于VOF方法模拟离心式喷嘴内部流动过程

刘娟; 李清廉; 王振国; 吴海燕

基于VOF方法模拟离心式喷嘴内部流动过程

国防科技大学航天与材料工程学院,长沙 410073

基金项目: 国家自然科学基金(10802095)

计量
- 文章访问数: 2035
- HTML浏览量: 160
- PDF量: 20
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-18
- 修回日期: 2010-12-15
- 刊出日期: 2011-09-28

Numerical simulation of flow field in pressure-swirl injector based on VOF interface tracking method

College of Aerospace and Material Engineering, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 基于两相界面追踪方法VOF(volume of fluid)模拟了离心式喷嘴内部的流动过程,得到了液相填充喷嘴内部的过程,初始时刻,气液界面出现褶皱,随着进入液体的增多,褶皱逐渐消失;着重分析了喷嘴各个部位速度、压力分布,由于气液两相的存在,喷嘴内部流场变得异常复杂,流场分布不能用单相流的模式分析,总压损失大部分存在于喷嘴收缩段以及直管段,增大收缩段锥角、减小收缩段长度有利于减小总压损失;在喷嘴出口处设置一定扩张角,能够增加液相速度,减小液膜厚度,有利于雾化.
- 流体体积法 /
- 离心式喷嘴 /
- 总压损失 /
- 液膜厚度 /
- 雾化
Abstract: Interface-tracking method volume of fluid (VOF) was used to simulate the flow process in pressure-swirl injector.The process of liquid phase filling injector was exhibited:pucker appears at first,then distinguishes with the increase of liquid.Velocity and pressure distribution were especially analyzed in different sections of injector.As both liquid and gas phase coexist in the injector,the flow field is highly complex.Total pressure loss lies mostly in the convergent and columned sections,so increasing convergent angle helps to reduce total pressure loss.Setting a divergent angle at injector exit can increase liquid phase velocity and reducing liquid sheet thickness can get better atomization finally.
- volume of fluid(VOF) /
- pressure-swirl injector /
- loss of total pressure /
- liquid sheet thickness /
- atomization

HTML

参考文献(12)

[1]	甘晓华.航空燃气轮机燃油喷嘴技术[M].北京:国防工业出版社, 2006.
[2]	朱宁昌,刘国球.液体火箭发动机设计(上)[M].北京:宇航出版社,1994.
[3]	Hirt C W,Nichlos B D.Volume of fluid (VOF) method for the dynamics of free boundary[J].Journal of Computational Physics,1981,39(1):201-225.
[4]	王国辉,蔡体敏,何国强,等.一种旋流式喷嘴的实验和数值研究[J].推进技术,2003,24(1):28-32. WANG Guohui,CAI Timin,HE Guoqiang,et al.Experimental and numerical investigation of a swirl atomizer[J].Journal of Propulsion and Power,2003,24(1):28-32.(in Chinese)
[5]	岳明,徐行,杨茂林.离心式喷嘴内气液两相流动的数值模拟[J].工程热物理学报,2003,24(5):888-890. YUE Ming,XU Xing,YANG Maolin.Numerical study of two-phase flow in atomizer[J].Journal of Engineering Thermophysics,2003,24(5):888-890.(in Chinese)
[6]	Ibrahim A A,Jog M A.Nonlinear breakup model for a liquid sheet emanating from a pressure-swirl atomizer[J].Journal of Engineering for Gas Turbines and Power,2007,129(4):945-953.
[7]	Alhendal Y,Turan A,Aly W A.VOF simulation of marangoni flow of gas bubbles in 2D-axisymmetric column[J].Procedia Computer Science,2010,1(1):673-680.
[8]	赵大勇,李维仲.VOF方法中几种界面重构技术的比较[J].热科学与技术,2003,2(4):318-323. ZHAO Dayong,LI Weizhong.Comparison of three kinds of interface reconstruction methods applied to VOF[J].Journal of Thermal Science and Technology,2003,2(4):318-323.(in Chinese)
[9]	Gopala V R,Van Wachem B G M.Volume of fluids methods for immiscible-fluid and free-surface flows[J].Chemical Engineering Journal,2008,141(1-3):204-221.
[10]	阎昌琪.气液两相流[M].哈尔滨:哈尔滨工程大学出版社,2007.
[11]	李清廉.同轴式三组元喷嘴性能分析、工程应用及设计评定 .长沙:国防科技大学,2003. LI Qinglian.Performance analysis, engineering application, design and evaluating of coaxial tripropellant injector .Changsha:National University of Defense Technology,2003.(in Chinese)
[12]	田章福,吴继平,陶玉静,等.气液同轴式喷嘴雾化特性的试验[J].国防科技大学学报,2006,28(4):10-13. TIAN Zhangfu,WU Jiping,TAO yujing et al.Experimental study of atomization characteristics of liquid-gas coaxial atomizer[J].Journal of National University of Defense Technology,2006,28(4):10-13.(in Chinese)
