DZ125合金钎焊接头窄钎缝区高温循环应力应变分析方法

董成利; 石多奇; 杨晓光; 张蕾; 齐红宇; 侯金保

DZ125合金钎焊接头窄钎缝区高温循环应力应变分析方法

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司北京航空制造工程研究所,北京 100024

计量
- 文章访问数: 1488
- HTML浏览量: 76
- PDF量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-13
- 修回日期: 2011-03-17
- 刊出日期: 2011-09-28

Research method of cyclic stress-strain analysis of narrow brazing seam zone of DZ125 alloy brazed joints at high temperature

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Beijing Aviation Manufacturing Engineering Institute, Aviation Industry Corporation of China, Beijing 100024, China

摘要

摘要: 针对钎焊接头窄钎缝区(大约150μm)在高温环境下的循环应力应变测量困难问题,提出一种基于反推法的新思想,依据以下两类数据进行计算和分析:第一类是采用有限元软件ABAQUS的用户材料子程序(UMAT)嵌入Chaboche热黏塑性本构模型计算得到的DZ125母材合金高温循环应力应变数据;第二类是经高温循环试验得到的钎焊接头的相应数据,最后经过数据处理和MATLAB软件编程获得窄钎缝区的应力应变.研究结果表明,钎焊接头在高温环境下的变形具有明显的不均匀性和局部性,并指出较之母材合金其钎缝区相对较“软”,而且它也是整个钎焊接头的薄弱环节,应给予足够的重视.推而广之,反推法的提出为研究普通焊接接头窄焊缝的力学行为提供了一条新的途径.
- DZ125合金 /
- 钎焊接头 /
- 窄钎缝区 /
- 定向凝固 /
- 热黏塑性 /
- 反推法
Abstract: A back-calculating method for solving difficult measurement of cyclic stress-strain of the narrow brazing seam zone (less than 150 μm) at high temperature was presented based on following two types of data: the first one was cyclic stress-strain data of DZ125 alloy base metal at high temperature,which was obtained by the finite element software ABAQUS coupling user material subroutine (UMAT) embedded into Chaboche viscoplastic model;the second one was cyclic stress-strain data of brazed joints obtained by the high-temperature cycle test;after data processing and MATLAB programming,the cyclic stress-strain of the brazing seam zone at high temperature was obtained concisely.The results show that the deformation of the brazed joints at high temperature has obvious heterogeneous and localized properties,and as compared to the base alloy metal,the brazing seam zone is relatively 'soft’,and also a weak link in brazed joints which should be given adequate attention.By extension,the proposed back-calculating method provides a new way for studying the general mechanical behavior of narrow seam of the welded joint.
- DZ125 alloy /
- brazed joint /
- narrow brazing seam zone /
- directionally solidification /
- heat visco-plastic /
- back-calculating method

HTML

参考文献(16)

[1]	《中国航空材料手册》编辑委员会.中国航空材料手册第2卷:变形高温合金、铸造高温合金[M].第2版.北京:中国标准出版社,2002.
[2]	Koo G H,Lee J H.Investigation of ratcheting characteristics of modified 9Cr-1Mo steel by using the Chaboche constitutive model[J].International Journal of Pressure Vessels and Piping,2007,84(5):284-292.
[3]	Lu F,Xu J Q.Evaluation of cyclic inelastic response in fretting based on unified Chaboche model[J].International Journal of Fatigue,2005,27(9):1062-1075.
[4]	Tong J,Zhan Z L,Vermeulen B.Modelling of cyclic plasticity and viscoplasticity of a nickel-based alloy using Chaboche constitutive equations[J].International Journal of Fatigue,2004,26(8):829-837.
[5]	Mohamad R P,Sina S.On the calibration of the Chaboche hardening model and a modified hardening rule for uniaxial ratcheting prediction[J].International Journal of Solids and Structures,2009,46(16):3009-3017.
[6]	Besson J,Leclercq S,Gaffard V,et al.Analysis of creep lifetime of an ASME Grade 91 welded pipe[J].Engineering Fracture Mechanics,2009,76(10):1460-1473.
[7]	Vivier F,Gourgues-Lorenzon A F,Besson J.Creep rupture of a 9Cr1Mo-NbV steel at 500℃:base metal and welded joint[J].Nuclear Engineering and Design,2010,240(10):2704-2709.
[8]	Tu S T,Segle P,Gong J M. Creep damage and fracture of weldments at high temperature[J].International Journal of Pressure Vessels and Piping,2004,81(2):199-209.
[9]	Watanabe T,Tabuchi,Yamazaki M,et al.Creep damage evaluation of 9Cr-1Mo-VNb steel welded joints showing Type Ⅳ fracture[J].International Journal of Pressure Vessels and Piping,2006,83(1):63-71.
[10]	Hayhurst R J,Vakili-Tahami F,Hayhurst D R. Verification of 3-D parallel CDM software for the analysis of creep failure in the HAZ region of Cr-Mo-V crosswelds[J].International Journal of Pressure Vessels and Piping,2009,86(8):475-485.
[11]	Tabuchi M,Watanabe T,Kubo K,et al.Creep crack growth behavior in the HAZ of weldments of W containing high Cr steel[J].International Journal of Press Vessels and Piping 2001,78(11-12):779-784.
[12]	Li Y K,Hongo H,Tabuchi M,et al.Evaluation of creep damage in heat affected zone of thick welded joint for Mod.9Cr-1Mo steel[J].International Journal of Pressure Vessels and Piping,2009,86(9):585-592.
[13]	Matsui M,Tabuchi M,Watanabe T,et al.Effect of heat treatment on creep properties and microstructures of HAZ for 9% Cr ferritic steel[J].Society of Materials Science,2003,52(2):119-123.
[14]	石多奇.热端部件材料先进黏塑性本构理论与高温多轴疲劳理论研究 .北京:北京航空航天大学,2004. SHI Duoqi.Viscoplastic constitutive modeling and multiaxial fatigue life prediction of nickel-based superalloy at elevated temperature .Beijing:Beijing University of Aeronautics and Astronautics,2004.(in Chinese)
[15]	周天朋.定向凝固涡轮叶片先进应力应变分析方法及低循环疲劳寿命研究 .北京:北京航空航天大学,2007. ZHOU Tianpeng.Research of advanced stress-strain analysis and low cycle fatigue life for directionally solidified turbine blade .Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
[16]	刘展.ABAQUS6.6基础教程与实例[M].北京:中国水利水电出版社,2008.
