大弯角扩压叶栅吸力面全域压力分布的PSP实验

高丽敏; 高杰; 王欢; 周强; 刘波

大弯角扩压叶栅吸力面全域压力分布的PSP实验

西北工业大学动力与能源学院,西安 710072

基金项目: 国家自然基金(51076132); 航空基金(2010ZB53014); 西北工业大学基础研究基金; 2010年度新世纪人才计划

计量
- 文章访问数: 1945
- HTML浏览量: 259
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-21
- 修回日期: 2011-06-01
- 刊出日期: 2011-09-28

PSP experiment of global surface pressure distribution on suction surface of compressor cascade with large curved angle

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于自行组建的PSP(pressure sensitive paint)测量系统,采用中国科学院化学研究所PSP,实验测量了来流马赫数分别为0.4和0.5时大弯角扩压叶栅叶片吸力面全域压力分布,并与传统测压技术所得结果进行了比较.研究结果表明:①采用PSP技术测量可以获得叶片表面全域的连续压力分布,具有空间分布率高、定量测量的特点;②叶片中部PSP测量压力值与压力扫描阀结果吻合得非常好,但受到叶片吸力面曲率的影响,叶片前缘与尾缘附近的误差较大,最大误差为4.48%;③随着来流速度的提高,PSP与压力扫描阀之间的误差逐渐减小.
- PSP(pressure sensitive paint)测量技术 /
- 大弯角 /
- 扩压叶栅 /
- 压力分布 /
- 吸力面
Abstract: Based on the home-made PSP (pressure sensitive paint)system and ICCAS's (Institute of Chemistry,Chinese Academy of Sciences) PSP,the pressure distribution on the compressor cascade surface was performed on a subsonic cascade wind-tunnel while the conventional pressure scanner was employed to validate the PSP measurement.Comparison between the PSP and the pressure scanner indicates: (1) Pressure distribution on the suction surface of with use of PSP is quantitative,continuous and global,and that with use of pressure scanner is discrete and limited.(2) Compared with the results of pressure scanner,there is a good agreement on the pressure valley and the maximum measuring error near the leading edge and trailing edge,which does not exceed to 4.48%.(3) The maximum measuring error is decreasing when Mach number of the inflow is increasing.
- PSP(pressure sensitive paint) measurement technique /
- large curved angle /
- compressor cascade /
- pressure distribution /
- suction surface

HTML

参考文献(18)

[1]	刘波,周强,靳军,等.压力敏感涂料技术及其应用[J].航空动力学报, 2006,21(2):225-233. LIU Bo,ZHOU Qiang,JIN Jun,et al.Applications of pressure-sensitive paint technique[J].Journal of Aerospace Power,2006,21(2):225-233.(in Chinese)
[2]	Peterson J I,Fitzgerald R V.New technique of surface flow visualization based on oxygen quenching of fluorescence[J].Rev.Sci.Instrum., 1980,51(5):670-671.
[3]	Sakaue H,Gregory J W,Sullivan J P.Porous pressure sensitive paint for characterizing unsteady flow fields[J].AIAA Journal,2002,40(6):1094-1098.
[4]	Basu B J,Anandan C,Rajam K S.Study of the mechanism of degradation of pyrene-based pressure sensitive paints [J]. Sensors and Actuators B:Chemical,2003,94(3):257-266.
[5]	Bencic T J.Application of pressure-sensitive paint to ice-accreted wind tunnel models .AIAA-2000-0834,2000.
[6]	Fonov S D,Goss L P,Jones J W,et al.Surface pressure and shear force fields measurements using elastic polymeric film //The 11th International Symposium on Flow Visualization.IN,USA:IOS Press,2004:9-12.
[7]	Engler R H,Klein C.DLR PSP system:intensity and lifetime measurements //ICIASF'97 Record,International Congress on Instrumentation in Aerospace Simulation Facilities.CA,USA:IEEE ,1997:46-56.
[8]	Asai K.Status of pressure sensitive paint technology at national aerospace laboratory //18th International Congress on Instrumentation in Aerospace Simulation Facilities (ICIASF).Toulouse,France:IEEE,1999:15.1-15.11.
[9]	Nakakita K,Asai K.Pressure-sensitive paint application to a wing-body model in a hypersonic shock tunnel .AIAA-2002-2911,2002.
[10]	Bencic T J.Rotating pressure and temperature measurements on scale-model fans using luminescent paints .AIAA Paper,98-3452,1998.
[11]	Lepicovsky J,Bencic T J.Use of pressure-sensitive paint for diagnostics in turbomachinery flows with shocks[J].Experiments in Fluids,2002,33(4):531-538.
[12]	Engler R H,Klein C,Trinks O.Pressure sensitive paint systems for pressure distribution measurements in wind tunnels and turbomachines[J].Meas.Sci.Technol.,2000,11 (7):1077-1085.
[13]	高丽敏,王欢,刘波,等.测量系统特性对压敏涂料校准影响的实验研究[J].航空学报,2010,31(1):76-81. GAO Limin,WANG Huan,LIU Bo,et al.Experimental of study influence of measurement system characteristics on pressure-sensitive paint calibration[J].Acta Aeronautica et Astronautica Sinica,2010,31(1):76-81.(in Chinese)
[14]	金熹高,林勇,史燚,等.一类芘衍生物及其制备方法与应用:中国,200610112965.5 .2008-03-19. JIN Xigao,LIN Yong,SHI Yi,et al.The preparation method and application of pyrene derivatives:China,200610112965.5 .2008-03-19(in Chinese).
[15]	张永存,邢汉奇,赵文涛,等.光学压力测量技术的应用研究 //第六届全国实验流体力学学术会议论文集.太原:中国力学学会、中国空气动力学学会,2004:388-391. ZHANG Yongcun,XING Hanqi,ZHAO Wentao,et al.Application of optical pressure measurement //The Sixth Chinese Conference of Experiments in Fluid Mechanics Papers.Taiyuan:The Chinese Society of Theoretical and Applied Mechanics,Chinese Aerodynamics Research Society,2004:388-391.(in Chinese)
[16]	程厚梅,张永存,陈柳生.光学涂层测压技术 //2003空气动力学前沿研究论文集.北京:中国空气动力学学会,2003:108-115. CHEN Houmei,ZHANG Yongcun,CHEN Liusheng.The optical pressure paint measurement technique //2003 Aerodynamics Former Research Papers.Beijing:Chinese Aerodynamics Research Society,2003:108-115.(in Chinese)
[17]	郑立新,郝重阳,刘波,等.压力敏感涂料内流场测量系统及涂料校准[J].实验流体力学,2008,22(3):86-93. ZHENG Lixin,HAO Chongyang,LIU Bo,et al.Construction of pressure-sensitive paint measurement system and calibration for homemade paint[J].Journal of Experiments in Fluid Mechanics,2008,22(3):86-93.(in Chinese)
[18]	ZHOU Qiang,LIU Bo,GAO Limin,et al.Pressure measurement on suction surface of a single vane using pressure-sensitive paint[J].Chinese Journal of Aeronautics,2009,22(2):138-144.
