辅助动力装置喘振控制方法

苏三买; 常博博; 刘铁庚; 刘美凤

辅助动力装置喘振控制方法

1.
西北工业大学动力与能源学院,西安 71007
2.
中国航空工业集团公司中国航空动力机械研究所,湖南株洲 412002

基金项目: 航空科学基金(20100653006); APTD项目(APTD-0401-01)

计量
- 文章访问数: 2087
- HTML浏览量: 257
- PDF量: 29
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-30
- 修回日期: 2011-02-09
- 刊出日期: 2011-09-28

Research on control method of surge in auxiliary power unit

1.
School of Power and Energy, Northwestern Polytechnical University, Xi'an 71007
2.
China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China

摘要

摘要: 以带负载压气机的辅助动力装置(APU)为研究对象,分析了其引气工作特点及负载压气机喘振机理,提出采用出口换算流量小于最小稳定工作流量的方法来控制负载压气机稳定工作,当APU出口换算流量小于最小稳定工作流量2%时,通过打开喘振控制阀(SCV)防止APU喘振.设计了比例积分微分(PID)控制器控制SCV开度,试车数据与相同条件下的逼喘仿真试验结果对比表明,所提出的方法既可避免负载压气机喘振,又可保证出口压力满足引气要求.
- 辅助动力装置 /
- 负载压气机 /
- 喘振 /
- 出口换算流量 /
- 喘振控制阀(SCV)
Abstract: The surge mechanism of auxiliary power unit (APU) with load compressor was analyzed.To ensure load compressor's working stability,the method of controlling exit corrected flow less than the minimum stable work flow was put forward.When load compressor exit flow is less than 2%,compared with minimum stable flow,the surge control valve (SCV) used to avoid surge was opened.Proportion-integral-differential (PID) controller was designed to control the opening angle of SCV so as to avoid surge of load compressor,and make exit pressure of air meet certain requirements.Compared with APU actual test data,numerical simulation results show that the method can be used to ensure the load compressor's working stability.
- auxiliary power unit /
- load compressor /
- surge /
- exit corrected flow /
- surge control valve(SCV)

HTML

参考文献(12)

[1]	Rodger C,Johnson D C.APU fuel efficiency and affordability for commercial aircraft .AIAA-1987-1907,1987.
[2]	Rodgers C.Performance of single shaft load compressor auxiliary power units .AlAA-1983-1159,1983.
[3]	Rodgers C.Auxiliary power units for current and future aircraft .SAE Technical Paper,912059,1991.
[4]	De Jager B.Rotating stall and surge control:a survey //Proceedings of the 34th IEEE Conference on Decision and Control.New Orleans LA,USA:IEEE,1995,2:1857-1862.
[5]	屈霁云,马明明,王小峰,等.某型发动机喘振特征分析及消喘系统验证试验[J].航空动力学报,2010,25(6):1291-1296. QU Jiyun,MA Mingming,WANG Xiaofeng,et al.Investigation of surge characteristics and surge eliminating system verification based on a certain engine[J].Journal of Aerospace Power,2010,25(6):1291-1296.(in Chinese)
[6]	冯大庸.航空发动机设计手册(第十四册)[M].北京:航空工业出版社,2000.
[7]	宋静波.波音737飞机动力装置:CFM56-3 & APU[M].广州:中山大学出版社,2008.
[8]	金中平.辅助动力装置及其标准发展综述[J].航空标准化与质量,1998(4):19-22. JIN Zhongping.The auxiliary power uints and its development[J].Aeronautic Standardization and Quality,1998(4): 19-22.(in Chinese)
[9]	秦海波,孙健国.某型发动机喘振/消喘控制系统分析研究[J].航空动力学报,2006,21(1):202-206. QIN Haibo,SUN Jianguo.Investigation on aircraft engine anti-surge/surge eliminating control system[J].Journal of Aerospace Power,2006,21(1):202-206.(in Chinese)
[10]	叶巍,陆德雨,黄顺洲,等.航空发动机喘振系统设计与研究[J].燃气涡轮试验与研究,1998,11(4):45-49. YE Wei,LU Deyu,HUANG Shunzhou,et al.The design and research of air engine surge system[J].Gas Turbine Experiment and Research,1998,11(4):45-49.(in Chinese)
[11]	储朝霞.离心式压缩机防喘振控制方案及数学模型[J].石油化工自动化,2007,12(3):21-23. CHU Zhaoxia.The anti-surge control schemes and mathematic models for centrifgal compressors in merhnol plant[J].Automation in Petr-chemical Industry,2007,12(3):21-23.(in Chinese)
[12]	李小彪,于海生,孙健国,等.一种涡扇发动机喘振信号判定方法[J].推进技术,2009,30(6):728-729. LI Xiaobiao,YU Haisheng,SUN Jianguo,et al.A surge signal judge method for turbofan engine[J].Journal of Propulsion Technology, 2009,30(6):728-729.(in Chinese)
