混合排气二元收敛喷管与发动机流量匹配设计方法

李娜; 吉洪湖

混合排气二元收敛喷管与发动机流量匹配设计方法

李娜,
吉洪湖

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 2201
- HTML浏览量: 130
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2010-10-14
- 修回日期: 2011-01-10
- 刊出日期: 2011-09-28

Study on matching method for core and bypass mass flux of 2-D convergent nozzle of mixed flow

LI Na,
JI Hong-hu

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 发展了一种基于喷管三维黏性数值分析的内外涵气流质量流量匹配设计方法.该方法主要是通过建立以喷管待定几何参数为未知量的非线性无量纲内外涵气流质量流量匹配方程组,然后采用逐步线性迭代法结合喷管三维黏性数值分析对该非线性方程组进行求解,得到满足发动机内外涵流量匹配的喷管设计方案.通过数值算例验证分析,结果表明:①该方法可以快速确定满足涡扇发动机内外涵流量匹配要求的二元收敛喷管待定几何参数;②流量匹配后,出口面积较小、长度较长的二元收敛喷管总推力和推进效率较高.
- 二元收敛喷管 /
- 流量匹配 /
- 推力 /
- 几何参数 /
- 数值计算
Abstract: A design method of two-dimensional (2-D) convergent nozzle was developed to meet core and bypass mass flux requirements of mixed flow turbofan engine.A matching method for core and bypass mass flux based on three-dimensional (3-D) viscous numerical simulation was proposed.Non-linear dimensionless mass flux matching equations for core and bypass channel with 2-D nozzle were formulated.Solving procedure of the non-linear equations was presented.Numerical simulation and matching results for some nozzle cases indicate that : (1) The method for solving the non-linear mass flux equations is effective,geometric parameters could be determined quickly for 2-D convergent nozzle.(2) Nozzle length and throat area properly play a key role for the required nozzle gross thrust.A nozzle with greater length and smaller throat area has greater gross thrust and better efficiency.
- two-dimensional convergent nozzle /
- mass matching /
- gross thrust /
- geometric parameters /
- numerical simulation

HTML

参考文献(16)

[1]	Martens R E.F-15 nozzle afterbody integration . AIAA-1974-1100,1974.
[2]	Richey G K,Berrier B L,Palcza J L.Two-dimensional nozzle-airframe integration technology:an overview . AIAA-1977-839,1977.
[3]	Berrier B L,Palcza J L,Richey G K.Nonaxisymmetric nozzle technology program:an overview .AIAA-1977-1225,1977.
[4]	Hiley P E,Wallace H W,Booz D E.Study of non-axisymmetric nozzles installed in advanced fighter aircraft .AIAA-1975-1316,1975.
[5]	Willard C M,Capone F J,Konarshi M,et al.Static performance of vectoring- reversing non-axisymmetric nozzles .AIAA-1977-840,1977.
[6]	Stevens H L.F-15/Nonaxisymmetric nozzle system integration study support program .NASA-CR-135252,1978.
[7]	Hinz W W,Miller E R.Propulsion integration of a supersonic strike-fighter .AIM Paper No.79-0100,1979.
[8]	Lander J A,Palcza J L.Exhaust nozzle deflector systems for V/STOL fighter aircraft .AIAA-1974-1169,1974.
[9]	Lander J A,Nash D O,Palcza J L.Augmented deflector exhaust nozzle/ADEN/design for future fighters .AIAA-1975-1318,1975.
[10]	Maiden D L.Performance of a isolated two-dimensional wedge nozzle with fixed cowl and variable wedge centerbody at mach numbers up to 2.01 .NASA-TN D-8218,1976.
[11]	Maiden D L,Petit J E.Investigation of two-dimensional wedge exhaust nozzle for advanced aircraft[J].J.Aircraft,1976,13(10):809-816.
[12]	翟普,隋俊友,崔杰,等.弹用航空发动机尾喷流红外抑制技术研究[J].推进技术,1996,17(4):17-20. ZHAI Pu,SUI Junyou,CUI Jie,et al.A research on radiation restriction technique of a nozzle flow of aero-engine for missile[J].Journal of Propulsion Technology,1996,17(4):17-20.(in Chinese)
[13]	郑礼宝.二元喷管对发动机性能影响的实验研究[J].推进技术,1997,18(4):58-61. ZHENG Libao.Experimental investigation on the influence of 2-D nozzle on jet-engine performance[J].Journal of Propulsion Technology,1997,18(4):58-61.(in Chinese)
[14]	张勃.大宽高比矩形喷管的射流掺混与红外抑制特性研究 .南京:南京航空航天大学,2005. ZHANG Bo.Investigation of jet mixing characteristics and radiation restriction technology of rectangular nozzle with high aspect ratio .Nanjing:Nanjing University of Aeronautics and Astronautics,2005.(in Chinese)
[15]	罗明东.无人机排气系统红外隐身技术研究 .南京:南京航空航天大学,2006. LUO Mingdong.Investigation of infrared stealth technology of the exhaust system for unmanned Aerial vehicle .Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese)
[16]	陈玉春,黄兴,高本兵,等.发动机总体与尾喷管三维并行设计研究[J].航空动力学报,2007,22(10):1696-1699. CHEN Yuchun,HUANG Xing,GAO Benbing,et al.Parallel design of turbo engine and three-dimensional nozzle[J].Journal of Aerospace Power,2007,22(10):1696-1699. (in Chinese)
