时变转速下裂纹圆柱壳的参数振动稳定性分析
Stability analysis of parametric resonance of a crack cylindrical shell with time-varying rotating speed
-
摘要: 利用有限元方法建立周期时变转速影响下裂纹圆柱壳的有限元模型并且得到了系统的质量、刚度和阻尼矩阵.在对圆柱壳进行模态分析的基础上,利用Bolotin方法编制MATLAB程序进行周期时变转速影响下裂纹圆柱壳的参数振动稳定性分析,讨论裂纹长度C、模态阻尼比ξ、转速基值Ω0、静载荷因子α和动载荷因子β对不稳定区域的影响规律.Abstract: A crack cylindrical shell model with time-varying rotating speed was established using the finite element method and get the system quality stiffness and damping matrix.On the basis of modal analysis,Bolotin's method was applied to explore the dynamic instability region.Examples of stability charts were worked out and the dependence of stability on various parameters,including crack length C,modal damping ratio ξ,rotating speed basic value Ω0,steady load factor α and dynamic load factor β was discussed.
-
[1] 严砺堂.结构系统动力特性分析[M].北京:北京航空航天大学出版社,1989. [2] Sahu S K,Datta P K.Research advances in the dynamic stability behavior of plates and shells 1987-2005 part Ⅰ:conservative systems[J].Applied Mechanics Reviews,2007,60(2):65-76. [3] Bolotin V V.The dynamic stability of elastic systems[M].San Francisco:Holden-Day,1964. [4] Bieniek M P,Fan T C,Lackman L M.Dynamic stability of cylindrical shells[J].AIAA Journal,1966,4(3):495-500. [5] Koval L R.Effect of longitudinal resonance on the parametric stability of axially excited cylindrical shells[J].Journal of the Acoustical Society of America,1974,55(1):91-97. [6] Yamaki N,Nagai K.Dynamic stability of circular cylindrical shells under periodic shearing forces[J].Journal of Sound and Vibration,1976,45(4):513-527. [7] Yamaki N,Nagai K.Dynamic stability of circular cylindrical shells under periodic compressive forces[J].Journal of Sound and Vibration,1978,58(3):425-441. [8] Evenson H A,Iwanowski E.Dynamic response and stability of shallow spherical shells subjected to time dependent loading[J].AIAA Journal,1967,5(5):969-1075. [9] Ariaratnam S T,Namachchivaya N S.Dynamic stability of pipes conveying pulsating fluid[J].Journal of Sound and Vibration,1986,107(2):215-230. [10] Chiba M,Tani J,Hashimoto H,et al.Dynamic stability of liquid-filled cylindrical shells under horizontal excitation part I:experiment[J].Journal of Sound and Vibration,1986,104(2):301-319. [11] Mcrobie F A,Popov A A,Thompson J M.Chaotic energy exchange through auto-parametric resonance in cylindrical shells[J].Journal of Sound and Vibration,2001,248(3):395-411. [12] Zhu J Q,Chen C,Shen Y P.Three dimensional analysis of the dynamic stability of piezoelectric circular cylindrical shells [J].European Journal of Mechanics-A/Solids,2003,22(3):401-411. [13] Javidruzi M,Vafai A,Chen J F,et al.Vibration,buckling and dynamic stability of cracked cylindrical shells[J].Thin-walled Structures,2004,42(1):79-99. [14] Ng T Y,Lam K Y,Reddy J N.Parametric resonance of a rotating cylindrical shell subjected to periodic axial loads[J].Journal of Sound and Vibration,1998,214(3):513-529. [15] Ganesan P N,Kadoli R K.A study on the dynamic stability of a cylindrical shell conveying a pulsatile flow of hot fluid[J].Journal of Sound and Vibration,2004,274(3-5):953-984. [16] Young T H,Liou G T.Coriolis effect on the vibration of a cantilever plate with time-varying rotating speed[J].Journal of Vibration and Acoustics,1992,114(2):232-241. [17] Young T H,Liou G T.Dynamic response of a rotating blade with time-dependent rotating speed[J].Journal of Sound and Vibration,1993,164(1):157-171. [18] Turhan Ö,Bulut G.Dynamic stability of rotating blades (beams) eccentrically clamped to a shaft with fluctuating speed [J].Journal of Sound and Vibration,2005,280(3-5):945-964. [19] 宋兆泓.航空发动机典型故障分析[M].北京:北京航空航天大学出版社,1993. [20] Tang F Q,Huang T C.Modal analysis of a cylindrical shell with a longitudinal crack[J].Applied Mechanics Division,1983,59(13):77-84. [21] Cook R D.Concepts and applications of finite element analysis[M].New York:John Wiley and Sons,1981. [22] Sewall J L,Naumann E C.An experimental and analytical vibration study of thin cylindrical shells with and without longitudinal stiffeners .NASA TN D-4705,1968. [23] Turhan Ö.A generalized Bolotin's method for stability limit determination of parametrically excited systems[J].Journal of Sound and Vibration,1998,261(5):851-863.
