旋转盘腔预旋角度的敏感性分析

丁水汀; 李烨; 张弓

旋转盘腔预旋角度的敏感性分析

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室适航技术研究中心,北京 100191

基金项目: 教育部长江学者创新团队“航空发动机复杂系统安全性”(IRT0905)

计量
- 文章访问数: 2193
- HTML浏览量: 330
- PDF量: 14
- 被引次数: 0
出版历程
- 收稿日期: 2010-12-25
- 修回日期: 2011-03-29
- 刊出日期: 2011-10-28

Sensibility analysis of inlet pre-swirl angle in the rotating cavity

Airworthiness Technologies Research Center, National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 采用单向FSI(fluid structure interaction)数值方法,研究转静系旋转盘腔进气预旋角度的变化对冷却效果的影响,并依据旋转盘腔冷却问题的工程评价体系对冷却效果进行评价.结果表明:当进气和旋转雷诺数均不变时,旋流比是进气预旋角度的单值函数.旋流比的改变能够使流动结构发生变化,影响盘面换热效果和转盘温度分布,导致与温度梯度相关的热应力也发生变化.随着旋流比的增加,旋转盘腔的流阻损失增大,迎风面平均换热效果呈现先减弱后增强的趋势,转盘整体应力水平上升,以及在盘心处的最大等效应力值增大.进气预旋角度的变化能够从部件承受能力和实际使用载荷两方面对涡轮盘的失效概率产生影响,因此,在涡轮盘腔设计阶段,需考虑预旋角度对涡轮盘安全性的影响.
- 适航 /
- 旋转盘腔 /
- 预旋角度 /
- 冷却效果 /
- 敏感性分析
Abstract: Unidirectional FSI (fluid structure interaction) numerical method was applied to investigate the influence of the inlet pre-swirl angle on the cooling effect of the rotating cavity.And the cooling effect was evaluated by an engineering evaluation system,which includes resistance evaluation,heat transfer evaluation and stress distribution evaluation for the safety of the turbine disk.The results show that,the swirl ratio is a monotropic function of the inlet pre-swirl angle,while the inlet Reynolds number and the rotational Reynolds number are constant.The swirl ratio has a great influence on the fluid structure in the rotating cavity,which determines the heat transfer and temperature distribution of the rotating disk.Furthermore,the thermal stress of the rotating disk related to the temperature gradient could be affected.With the rise of the swirl ratio,the frictional windage of the rotating cavity increases,the heat transfer of the windward of the disk presents up-down tendency,the stress level and maximum value enlarge.Therefore,the change of the pre-swirl angle has an effect on the failure probability of the turbine disk from two aspects:material affordability and working stress.
- airworthiness /
- rotating cavity /
- pre-swirl angle /
- cooling effect /
- sensibility analysis

HTML

参考文献(17)

[1]	Sehra A K,Whitlow W Jr.Propulsion and power for 21st century aviation[J].Progress in Aerospace Science,2004,40(5):199-235.
[2]	International Air Transport Association.Safety report 2008 .45th ed.Canada:International Air Transport Association,2009.
[3]	U.S.Department of Transportation FAA.Advisory circular 33.75-1A Guidance material for aircraft engine life-limited parts requirement[S].USA:U.S.Department of Transportation FAA,2009.
[4]	U.S.Department of Transportation FAA.FAR33FAR33 Federal aviation regulations Part 33:airworthiness standards:aircraft engines[S].USA:U.S.Department of Transportation FAA,2009.
[5]	U.S.Department of transportation FAA.Advisory circular 33.70-1 Guidance material for aircraft engine life-limited parts requirement[S].USA:U.S.Department of Transportation FAA,2009.
[6]	Karabay H,Pilbrow R,Wilson M,et al.Performance of pre-swirl rotating-disc systems[J].ASME Journal of Gas Turbines and Power,2000,122(3):442-450.
[7]	Wilson M,Pilbrow R,Owen J M.Flow and heat transfer in a preswirl rotor-stator system[J].Journal of Turbomachinery,1997,119(2):364-373.
[8]	Pilbrow R,Karabay H,Wilson M,et al.Heat transfer in a “cover-plate” preswirl rotating-disk system[J].Journal of Turbomachinery,1999,121(2):249-256.
[9]	Lock G D,Wilson M,Owen J M.Influence of fluid-dynamics on heat transfer in a pre-swirl rotating-disc system .ASME 2004-GT-53158,2004.
[10]	Karabay H,Chen J X,Pilbrow R,et al.Flow in a “cover-plate” preswirl rotor-stator system[J].Journal of Turbomachinery,1999,121(1):160-166.
[11]	罗翔,徐国强,陶智,等.30°预旋进气旋转盘流动与换热特性的实验[J].北京航空航天大学学报,2007,33(3):290-293. LUO Xiang,XU Guoqiang,TAO Zhi,et al.Flow and heat transfer in rotor-stator system with pre-swirl angle of 30°[J].Journal of Beijing University of Aeronautics and Astronautics,2007,33(3):290-293.(in Chinese)
[12]	罗翔,徐国强,陶智,等.进气角度对旋转盘冷却效果的影响[J].推进技术,2007,28(3):240-243. LUO Xiang,XU Guoqiang,TAO Zhi,et al.Cooling effectiveness in a rotor-stator system with different pre-swirl angles[J].Journal of Propulsion Technology,2007,28(3):240-243.(in Chinese)
[13]	王锁芳,朱强华,栾海峰,等.高位预旋进气转静盘腔换热实验[J].航空动力学报,2007,22(8):1216-1221. WANG Suofang,ZHU Qianghua,LUAN Haifeng,et al.Experimental study on heat transfer in rotor-stator cavity with high-positioned pre-swirl inflow[J].Journal of Aerospace Power,2007,22(8):1216-1221.(in Chinese)
[14]	丁水汀,陶智,徐国强,等.旋转盘腔冷却问题的工程评价[J].航空动力学报,1999,14(1):83-86. DING Shuiting,TAO Zhi,XU Guoqiang,et al.An engineering evaluation system of turbine disk cooling configuration[J].Journal of Aerospace Power,1999,14(1):83-86.(in Chinese)
[15]	FU Debin,TAO Zhi,ZHANG Gong,et al.Safety evaluation of cooling configuration in a rotor-stator cavity .Beijing,China:The 1st International Symposium on Aircraft Airworthiness,2009.
[16]	Enright M P,Chan K S,Moody J P,et al.Probabilistic fretting fatigue assessment of aircraft engine disks[J].Journal of Engineering of Gas Turbines and Power,2010,132(7):072502(9 pages).
[17]	Melis M E,Zaretsky E V,August R.Probabilistic analysis of aircraft gas turbine disk life and reliability[J].Journal of Propulsion and Power,1999,15(5):658-666.
