可压流条件下凹腔驻涡流动试验

宋双文; 雷雨冰; 姚尚宏; 马辉; 胡好生

可压流条件下凹腔驻涡流动试验

1.
中国航空工业集团公司中国航空动力机械研究所,湖南株洲 41200
2.
南京航空航天大学能源与动力学院,南京 210016

基金项目: 湖南省自然科学基金(09JJ3107)

计量
- 文章访问数: 2016
- HTML浏览量: 131
- PDF量: 14
- 被引次数: 0
出版历程
- 收稿日期: 2010-11-23
- 修回日期: 2011-02-12
- 刊出日期: 2011-10-28

Experimental study on compressible flow in trapped vortex cavity

1.
China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 41200
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对几何因素和气动因素对凹腔驻涡流动的影响进行了研究.试验研究了改变凹腔的高长比、射流孔位置和主流进气角度等对凹腔驻涡流动的影响,研究了改变主次流进口流速等气动因素对凹腔流动的影响.总压损失采用总压探针测量,速度场采用粒子图像测速仪(PIV)测量.试验结果表明:①两股射流在中部和底部喷射时均能产生大尺度涡结构,在中部喷射时产生一对旋向相反的涡对,在底部喷射时产生单涡.②在中部喷射情况下,增加主流马赫数和主流进气角度,凹腔上部空间的涡度增强.③主流进口马赫数增加,试验件的总压损失显著增加.
- 驻涡燃烧室(TVC) /
- 凹腔 /
- 流场 /
- 单涡 /
- 双涡 /
- 总压测量 /
- 粒子图像测速仪(PIV)
Abstract: The effect of geometry and aerodynamic factors on the flow in trapped vortex cavity was evaluated.The effect of geometry was analyzed by altering the ratio of height to length(H/L) of the cavity,injection position and main-flow inlet angle;the impact of aerodynamics was analyzed by varying main-flow and second inject flow inlet velocity.Total pressure loss was measured by total pressure probe,and the velocity field was measured by particle image velocimetry (PIV).The results reveal that:(1) When the position of the injection holes is in the bottom or the middle position,large scale vortexes can be formed in the trapped vortex cavity.A couple of opposite swirling vortexes are formed in the middle position;and only a single vortex can be formed in the bottom. (2) For the middle injection configuration, increasing the main-flow mach number and inlet angle can enhance the vortex intensity in the upside of the cavity. (3) The total pressure loss increases apparently with the growing main-flow inlet Mach number.
- trapped vortex combustor(TVC) /
- cavity /
- flow field /
- single vortex /
- double vortexes /
- total pressure measurement /
- particle image velocimetry

HTML

参考文献(12)

[1]	Roquemore W M,Shouse D,Burrus D L,et al.Vortex combustor concept for gas turbine engines .AIAA 2001-0483,2001.
[2]	Straub D L,Casleton K H,Lewis R E,et al.Assessment of rich-burn,quick-mix,lean-burn trapped vortex combustor for stationary gas turbines[J].ASME Journal of Engineering for Gas Turbines and Power,2005,127(1):36-41.
[3]	Burrus D L,Johnson A W,Roquemor W M,et al.Performance assessment of a prototype trapped vortex combustor concept for gas turbine application .ASME 2001-GT-0087,2001.
[4]	Hendricks R C,Shouse D T,Roquemore W M.Experimental and computational study of trapped vortex combustor sector rig with tri-pass diffuser .NASA TM-2004-212507,2004.
[5]	Hendricks R C,Buehrle R,Liu N S,et al.Numerical simulation of the RTA combustion rig .NASA TM-2005-21389,2005.
[6]	Meyer T R,Brown M S,Fonov S,et al.Optical diagnostics and numerical characterization of a trapped-vortex combustor .AIAA 2002-3863,2002.
[7]	Zelina J,Ehret J,Hancock R D,et al.Ultra-compact combustion technology using high swirl for enhanced burning rate .AIAA 2002-3725,2002.
[8]	Thornburg H,Zelina B S,Greenwood R.Numerical study of an inter-turbine burner (ITB) concept with curved radial vane .AIAA 2007-649,2007.
[9]	樊未军,易琪,严明,等.驻涡燃烧室凹腔双涡结构研究[J].中国电机工程学报,2006,26(9):66-70. FAN Weijun,YI Qi,YAN Ming,et al.A study of double vortex structure in the trapped vortex combustor[J].Proceedings of the CSEE,2006,26(9):66-70.(in Chinese)
[10]	邢菲,樊未军,张荣春,等.蒸发管供油的单驻涡燃烧室贫油点火试验[J].推进技术,2009,30(5):523-527. XING Fei,FAN Weijun,ZHANG Rongchun,et al.Ignition performance of a single trapped vortex combustor with evaporation tube as fuel supply[J].Journal of Propulsion Technology,2009,30(5):523-527.(in Chinese)
[11]	孔祥雷,樊未军,邢菲,等.单涡/贫油驻涡燃烧室的出口温度分布试验[J].航空动力学报,2010,25(4):784-799. KONG Xianglei,FAN Weijun,XING Fei,et al.Experimental study on outlet temperature distribution in ingle vortex/lean oil trapped vortex combustor[J].Journal of Aerospace Power,2010,25(4):784-799.(in Chinese)
[12]	张弛.切向驻涡燃烧室基础研究 .北京:北京航空航天大学,2007. ZHANG Chi.Basal research on tangent trapped vortex combustor .Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
