活塞发动机高空最小点火能量计算及试验

许善珍; 魏民祥; 白洪林

活塞发动机高空最小点火能量计算及试验

1.
南京航空航天大学能源与动力学院,南京 210016
2.
淮阴工学院交通工程学院,安徽淮安 22300
3.
天津大学天津大学内燃机研究所,天津 300072

计量
- 文章访问数: 2189
- HTML浏览量: 1
- PDF量: 8
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-06
- 修回日期: 2011-08-07
- 刊出日期: 2011-10-28

Calculation and experiment on minimum ignition energy at high altitude for a piston aero-engine

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Faculty of Transportation Engineering, Huaiyin Institute of Technology, Huai'an Anhui 22300
3.
Tianjin Internal Combustion Engine Research Institute, Tianjin University, Tianjin 300072, China

摘要

摘要: 根据原型机结构,应用AVL BOOST建立了航空活塞式发动机的一维仿真模型,通过地面特性仿真计算与试验研究,验证了发动机仿真模型的可行性和正确性;在深入分析可燃混合气燃烧机理基础上,建立了发动机最小点火能量计算数学模型;在此基础上,采用AVL BOOST与MATLAB联合仿真的方法,计算了发动机在不同高空、不同空燃比稳定运行工况下的最小点火能量,得出不同高空最小点火能量MAP图,并进行了试验验证,结果表明,所建立的最小点火能量的仿真计算模型是正确可行的,能够满足后续性能预测与研究的要求.
- 活塞发动机 /
- 高空 /
- 联合仿真 /
- 最小点火能量 /
- 仿真模型
Abstract: A one-dimensional simulation model of a piston aero-engine was established with AVL BOOST according to the structure of the prototype engine. And the simulation model was validated by the ground performance experiment and simulation computation. A mathematical model was set up to calculate the minimum ignition energy based on thorough analysis of combustion mechanism of the engine combustible mixture. Then the minimum ignition energy at high altitude with different air-fuel ratios under stable operation condition was calculated by using AVL BOOST and MATLAB, and the minimum ignition energy MAP was provided. Experiment was conducted to validate the calculation results. The results show that the model of calculating the minimum ignition energy is correct and feasible, and also can meet the requirements of further research and performance prediction.
- reciprocating aero-engine /
- high altitude /
- co-simulation /
- minimum ignition energy /
- simulation model

HTML

参考文献(13)

[1]	马法成,张宝来,吴顺毅.多功能汽油机点火测试系统及其应用[J].汽车技术,2003,34(11):17-20. MA Facheng,ZHANG Baolai,WU Shunyi.A multi-function ignition test system for gasoline engines and its application[J].Automobile Technology,2003,34(11):17-20.(in Chinese)
[2]	吴静波,郭志军,高建平.汽油发动机点火控制系统述评[J].河南科技大学学报(自然科学版),2005,26(5):32-36. WU Jingbo,GUO Zhijun,GAO Jianping.Review of gasoline engine ignition control system[J]. Journal of Henan University Science and Technology(Natural Science),2005,26(5): 32-36.(in Chinese)
[3]	汪洋,史家涛,王静,等.火花助燃HCCI燃烧最小点火能量的研究[J].车用发动机,2006,30(3):32-39. WANG Yang,SHI Jiatao,WANG Jing,et al.An investigation on the minimum ignition energy of spark supporting HCCI combustion[J].Vehicle Engine,2006,30(3):32-39.(in Chinese)
[4]	Fenn J B.Lean flammability limit and minimum spark ignition energy[J].Industrial and Engineering Chemistry,1951,43(12):2865-2869.
[5]	高孝洪.内燃机工作过程数值计算[M].北京:国防工业出版社,1986.
[6]	林杰伦.内燃机工作过程数值计算[M].西安:西安交通大学出版社,1986.
[7]	朱访君,吴坚.内燃机工作过程数值计算及其优化[M].北京:国防工业出版社,1997.
[8]	蒋德明.内燃机燃烧与排放学[M].西安:西安交通大学出版社,2001.
[9]	严传俊,范玮.燃烧学[M].西安:西北工业大学出版社,2005.
[10]	Kondo S,Takahashi A,Tokuhashi K.Calculation of minimum ignition energy of premixed gases[J].Journal of Hazardous Materials,2003,103(1-2):11-23.
[11]	陈林林.二冲程煤油发动机性能数值模拟与喷油控制研究 .南京:南京航空航天大学,2010. CHEN Linlin.Research on numerical simulation of performance and fuel injection control for two-strok kerosene engine .Nanjing:Nanjing University of Aeronautics and Astronautics,2010.(in Chinese)
[12]	AVL List GmbH.AVL Boost user manual[M].Austria:AVL List GmbH,2006.
[13]	林海英,龙向阳.某型增压航空活塞发动机仿真研究[J].航空动力学报,2009,24(6):1332-1338. LIN Haiying,LONG Xiangyang.Simulation study of an aero-piston engine with single stage turbocharger[J].Journal of Aerospace Power,2009,24(6):1332-1338.(in Chinese)
