轴流压气机转子近失速工况全通道 数值模拟

李清鹏; 吴艳辉; 楚武利; 张皓光

轴流压气机转子近失速工况全通道数值模拟

西北工业大学动力与能源学院,西安 710072

基金项目: 国家自然科学基金(51076133); 航空科技创新基金(08B53004); 航空科学基金(2010ZB53016)

计量
- 文章访问数: 1611
- HTML浏览量: 1
- PDF量: 7
- 被引次数: 0
出版历程
- 收稿日期: 2010-11-02
- 修回日期: 2011-03-01
- 刊出日期: 2011-10-28

Full-annulus simulations on axial compressor rotor at near stall condition

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 对某亚声速轴流压气机转子进行了全通道三维非定常数值模拟,获得了该压气机近失速工况下的详细流动情况.转子前缘均匀布置的十支静压数值探针监测结果表明,转子圆周上出现两个静压扰动区域,其中一个逐渐发展为突尖波.流场分析表明,叶顶通道中存在频繁的分离涡运动,静压扰动区域中分离涡的强度较大.分离涡诱发间隙流形成“前缘溢流”和“尾缘反流”.静压扰动区域沿圆周方向传播是由分离涡在通道之间的传递引起的.传播过程中,分离涡强度的持续增大是突尖波形成的关键因素.通道中较强的“尾缘反流”沿通道上行并绕过叶片形成“前缘溢流”的现象可作为突尖波形成的标志.
- 全通道 /
- 突尖波 /
- 分离涡 /
- 前缘溢流 /
- 尾缘反流
Abstract: Full-annulus unsteady simulations were performed on a subsonic axial compressor rotor,and the detailed flow parameters at near stall condition were achieved.Ten numerical static pressure probes arranged in front of the leading edge could detect two pressure disturbances,one of which was developed into a spike wave.According to analysis of the flow field,tip secondary vortexes exist in almost all passages near the blade tip and the most violent one appears in the disturbing areas.Tip secondary vortex could force tip clearance flow to form “leading edge spilling flow” and “trailing edge back flow”.The movement of the pressure disturbance along circumference was caused by the spreading of tip secondary vortex from one passage to the next.Continuous growth of tip secondary vortex in its spreading finally led to formation of spike wave.The phenomenon that the “trailing edge back flow” goes through the inlet and spills into the adjacent passage under the blade tip can be regard as the symbol of spike emergence.
- full-annulus /
- spike wave /
- tip secondary vortex /
- leading edge spilling flow /
- trailing edge back flow

HTML

参考文献(12)

[1]	Inoue M,Kuroumaru M,Fukuhara M.Behavior of tip leakage flow behind an axial flow compressor rotor[J].ASME Journal of Gas Turbine and Power,1986,108(1):7-14.
[2]	Inoue M,Kuroumaru M.Structure of tip clearance flow in an isolated axial flow compressor rotor[J].ASME Journal of Turbomachinery,1989,111(3):250-256.
[3]	Furukawa M,Inoue M,Saiki K,et al.The role of tip leakage vortex breakdown in compressor rotor aerodynamics[J].ASME Journal of Turbomachinery,1999,121(3):469-480.
[4]	März J,Hah C,Neise W,et al.An experimental and numerical investigation into the mechanisms of rotating instability[J].ASME Journal of Turbomachinery,2002,124(3):367-375.
[5]	Vo H D,Tan C S,Greitzer E M.Criteria for spike initiated rotating stall .ASME Paper GT2005-68374,2005.
[6]	吴艳辉,楚武利,刘志伟.轴流压气机转子性能及间隙流动研究[J].西北工业大学学报,2005,23(6):737-741. WU Yanhui,CHU Wuli,LIU Zhiwei.On detailed structure of tip clearance flow in an isolated axial flow compressor rotor and its effect on compressor performance[J].Journal of Northwestern Polytechnical University,2005,23(6):737-741.(in Chinese)
[7]	吴艳辉,楚武利,卢新根.间隙区域的流动结构对压气机气动性能的影响[J].工程热物理学报,2006,27(6):950-952. WU Yanhui,CHU Wuli,LU Xingen.The effect of tip leakage flow structure on compressor aerodynamics[J].Journal of Engineering Thermophysics,2006,27(6):950-952.(in Chinese)
[8]	吴艳辉,楚武利,张燕峰.间隙大小对压气机转子间隙泄漏流场的影响[J].西北工业大学学报,2007,25(6):838-842. WU Yanhui,CHU Wuli,ZHANG Yanfeng.Effects of tip clearance size on tip leakage flow fields in a subsonic compressor rotor[J].Journal of Northwestern Polytechnical University,2007,25(6):838-842.(in Chinese)
[9]	吴艳辉,楚武利,张皓光.间隙流动特征对压气机转子失速起始的影响[J].工程热物理学报,2008,29(7):1133-1135. WU Yanhui,CHU Wuli,ZHANG Haoguang.Role of leakage vortex behavior on stall inception in an axial compressor rotor[J].Journal of Engineering Thermophysics,2008,29(7):1133-1135.(in Chinese)
[10]	Wu Y H,Chu W L.Behavior of tip clearance flow in an axial flow compressor rotor .ASME Paper GT2006-90399,2006.
[11]	Wu Y H,Li Q,Chu W L,et al.Numerical investigation into unsteady behavior of tip clearance flow and its possible link with stall inception[J].Proceedings of the Institution of Mechanical Engineers Part A:Journal of Power and Energy,2010,224(A1):85-96.
[12]	卢新根.轴流压气机内部流动失稳及其被动控制研究 .西安:西北工业大学,2007. LU Xingen.Flow instability and its passive control strategies in axial-flow compressor .Xi'an:Northwestern Polytechnical University,2007.(in Chinese)
