N<sub>2</sub>O单组元微推力器真空试验设计与分析

韩乐; 李茂; 方杰; 孙威; 蔡国飙

N₂O单组元微推力器真空试验设计与分析

北京航空航天大学宇航学院,北京 100191

计量
- 文章访问数: 1673
- HTML浏览量: 140
- PDF量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2010-11-03
- 修回日期: 2010-12-13
- 刊出日期: 2011-10-28

Vacuum experiment study on a N₂O monopropellant micro-thruster

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 提出了N₂O单组元微推力器冲量测量方案.通过多次试验结果拟合稳态推力与压力之间的关系,再采用动态压力计算动态推力和冲量.对催化床尺寸为 φ 8mm×35mm和 φ 10mm×25mm两个微推力器进行了高空模拟试验研究,考察了流量对微推力器比冲的影响,得到了不同流量条件下稳态推力和压力之间的关系.试验方案与分析结果为微推力器精确冲量控制提供了参考.
- N₂O微推力器 /
- 高空模拟试验 /
- 推力 /
- 比冲 /
- 冲量
Abstract: Impulse measurement scheme for a nitrous oxide (N₂O) monopropellant micro-thruster was presented.The experiment results were used to fit the relationship between the steady thrust and the pressure.Dynamic pressure was utilized to calculate the thrust and impulse.Two different micro-thrusters with catalytic bed of φ 8mm×35mm and φ 10mm×25mm were fabricated and experimented.The influence of the mass flow on the specific impulse performance was studied.The relationship between the steady thrust and the pressure in different mass flow rates was obtained.Experiment strategy and analysis result can provide some reference for accurate control of the micro-thruster impulse.
- nitrogen oxide micro-thruster /
- simulated altitude test /
- thrust /
- specific impulse /
- impulse

HTML

参考文献(14)

[1]	Norman C,Tevfik G.A review of micro propulsion technology .AIAA 2003-670,2003.
[2]	Jeffrey G R,Raymond J S,Manuel M S.Micro propulsion system selection for precision formation flying satellites .AIAA 2001-3646,2001.
[3]	Tiliakos N,Tyll J S,Herdy R,et al.Development and testing of a nitrous oxide/propane rocket engine .AIAA 2001-3258,2001.
[4]	Gibbon D,Zakirov V,Eioirdi R,et al.Energetic green propulsion for small spacecraft .AIAA 2001-3247,2001.
[5]	Zakirov V A,LI Luming.Propulsion challenges for small spacecraft 2005[J].Tsinghua Science and Technology,2006,11(5):507-514.
[6]	柴宁,姜培学,孙锡九,等.N₂O单组元微型推进器内参数敏感性的研究[J].热科学与技术,2004,3(2):157-161. CHAI Ning,JIANG Peixue,SUN Xijiu,et al.Investigation of parameter sensitivity in micro monopropellant thruster based on N₂O[J].Journal of Thermal Science and Technology,2004,3(2):157-161.(in Chinese)
[7]	霍雪亮,韦迪,李路明.N₂O单组元推进器预热过程的建模[J].推进技术,2005,26(1):80-83. HUO Xueliang,WEI Di,LI Luming.Modeling of N₂O monopropellant thruster pre-heating[J].Journal of Propulsion Technology,2005,26(1):81-83.(in Chinese)
[8]	方杰,田辉,蔡国飙.N₂O单组元微推进系统及其喷管流场的初步研究[J].推进技术,2005,26(6):495-498. FANG Jie,TIAN Hui,CAI Guobiao.Preliminary study on a N₂O micro propulsion system and its nozzle flow field[J].Journal of Propulsion Technology,2005,26(6):495-498.(in Chinese)
[9]	孙威,方杰,蔡国飙,等.N₂O单组元微推力器性能分析及试验[J].北京航空航天大学学报,2008,34(12):1469-1472. SUN Wei,FANG Jie,CAI Guobiao,et al.Performance analysis and experimental research on nitrous oxide monopropellant micro-thruster[J].Journal of Beijing University of Aeronautics and Astronautics,2008,34(12):1469-1472.(in Chinese)
[10]	FANG Jie,SUN Wei,LI Mao,et al.An update to nitrous oxide micro-thruster research .AIAA-2009-5203,2009.
[11]	Kenneth W S,Thomas D,Daniel M,et al.Design and development of a micro pound extended range thrust stand(MERTS) .NASA Technical Note D-7029,1971.
[12]	James L C,Greg C L,Greg S.Resonant operation of a micro-Newton thrust stand .AIAA-2002-3821,2002.
[13]	Koizumi H.Development of thrust stand for low impulse measurement from micro thrusters[J].Review of Scientific Instruments,2004,75(10):3185-3190.
[14]	汤海滨,刘畅,杨勇,等.一种适用于空间微小推力发动机的推力测量系统:中国,200610089041 .2007-02-21. TANG Haibin,LIU Chang,YANG Yong,et al.A thrust measurement for micro space propulsion thrusters:China,200610089041 .2007-02-21.(in Chinese)
