含分层损伤国产碳纤维CCF300与T300碳纤维复合材料层合板压缩失效模式

傅惠民; 杨雨松; 张勇波

含分层损伤国产碳纤维CCF300与T300碳纤维复合材料层合板压缩失效模式

基金项目: 国家自然科学基金 (10472006); 北京市教育委员会共建项目(XK100060418)

计量
- 文章访问数: 2467
- HTML浏览量: 159
- PDF量: 90
- 被引次数: 0
出版历程
- 收稿日期: 2011-08-19
- 修回日期: 2011-10-19
- 刊出日期: 2011-11-28

Failure mode research on CCF 300 and T300 carbon fiber composite laminates with delamination under compressive strength

摘要

摘要: 对含单个分层损伤国产碳纤维CCF300与T300碳纤维复合材料层合板进行压缩试验,通过对同种中等厚度含不同分层大小、不同分层位置的层合板压缩失效后的宏微形貌及超声波C扫描检测结果的分析,研究了分层大小及分层位置对于国产碳纤维及T300纤维复合材料层合板失效模式造成的影响,比较了两种纤维复合材料失效模式的异同.结果表明,预制分层在压缩过程中都发生了扩展,而分层位置是影响其压缩失效模式较为重要的因素.对于分层位置较深的层合板,其失效模式往往为首先发生分层扩展,进而子层板剪切屈曲失效.总的分析表明,国产碳纤维复合材料与T300纤维复合材料含分层损伤层合板的压缩失效模式基本相同.
- 国产碳纤维 /
- 复合材料 /
- 失效模式 /
- 宏观形貌 /
- 超声波C扫描
Abstract: The compression test was conducted on the homemade and T300 carbon fiber composite laminate with one delamination. According to the macro-shape and the ultrasonic C-scan result of post-failure specimens which contain different sizes and different positions of delaminations but the same thickness, an investigation has been conducted by this study on the effects of delmaination sizes and positions on the failure mechanism of homemade and T300 carbon fiber composite laminates. Also the differences of failure mode have been analyzed between these two kinds of composites. The final result shows that the imbedded delaminations have all propagated, and the position of delamination proposed to be the most important factors affecting the compressive failure mode. To the laminates with deep delamination the failure mode presented to be the first propagation of delamination and second shear buckling failure of sub-laminate. Based on these analyses we find that the failure mode of homemade carbon fiber composite is same with the T300 carbon fiber composite generally.
- homemade carbon fiber /
- composite /
- failure mode /
- macro-shape /

HTML

参考文献(12)

[1]	赵稼祥.碳纤维复合材料在民用航空上的应用[J].高科技纤维与应用,2003,28(3):1-4,35. ZHAO Jiaxiang.Application of carbon composite materials for civil aviation[J].Hi-Tech Fiber & Application,2003,28(3):1-4,35.(in Chinese)
[2]	赵稼祥.碳纤维在美国国防军工上的应用[J].高科技纤维与应用,2003,28(1):6-9. ZHAO Jiaxiang.Application of carbon fiber for defence and military use in USA[J].Hi-Tech Fiber & Application,2003, 28(1):6-9. (in Chinese)
[3]	霍肖旭,刘红林,曾晓梅.碳纤维复合材料在固体火箭上的应用[J].高科技纤维与应用,2000,25(3):1-7,20. HUO Xiaoxu,LIU Honglin,ZENG Xiaomei.Applications of carbon fiber composites on SRM[J].Hi-Tech Fiber & Application,2000,25(3):1-7,20.(in Chinese)
[4]	贺福,孙微.碳纤维复合材料在大飞机上的应用[J].高科技纤维与应用,2007,32(6):5-8,17. HE Fu,SUN Wei.The application of carbon fiber composite materials in giant plane[J].Hi-Tech Fiber & Application,2007,32(6):5-8,17.(in Chinese)
[5]	赵稼祥.民用航空和先进复合材料[J].高科技纤维与应用,2007,32(2):6-10. ZHAO Jiaxiang.Civil aviation and advanced composite materials[J].Hi-Tech Fiber & Application, 2007,32(2):6-10.(in Chinese)
[6]	李书乡,马全胜,刘清田.国产碳纤维现状及CCF300质量稳定性提高[J].材料工程,2009(S2):207-210. LI Shuxiang,MA Quansheng,LIU Qintian.Current status of homemade carbon fiber and the advance of performance of carbon fiber CCF300[J].Journal of Materials Engineering,2009(S2):207-210.(in Chinese)
[7]	范金娟,郑林斌,赵旭,等.含低速冲击损伤复合材料层合板的压缩失效[J].失效分析与预防,2009,4(1):19-23,38. FAN Jinjuan, ZHENG Linbin, ZHAO Xu, et al.Compression failure of composite laminates with low-velocity impact damage[J].Failure Analysis and Prevention,2009,4(1):19-23,38.(in Chinese)
[8]	Al-Mansour A,胡仁伟,程小全,等.含中央分层缺陷层合板的压缩性能研究[J].强度与环境,2007,34(5):14-21. Al-Mansour A,HU Renwei,CHEN Xiaoquan,et al.Study on compressive properties of composite laminates with center delamination defect[J].Structure & Environment Engineering,2007,34(5):14-21.(in Chinese)
[9]	程小全,王进,Al-Mansour A,等.含矩形边缘分层缺陷层合板的压缩性能[J].复合材料学报,2007,24(2):151-158. CHEN Xiaoquan,WANG Jin,Al-Mansour A,et al.Study on compressive properties of composite laminates with edge rectangular delamination defect[J].Acta Materiae Composite Sinica,2007,24(2):151-158.(in Chinese)
[10]	范金娟, 赵旭, 程小全.复合材料层合板低速冲击后压缩损伤特性研究[J].失效分析与预防,2006,1(2):33-36. FAN Jinjuan,ZHAO Xu,CHEN Xiaoquan.Compression damage characteristics of composite laminates after low velocity impact[J].Failure Analysis and Prevention,2006,1(2):33-36.(in Chinese)
[11]	孙先念, 陈浩然, 陈绍杰.含分层损伤复合材料层合板前后屈曲行为研究[J].航空学报,1999,20(3):224-229. SUN Xiannian,CHEN Haoran,CHEN Shaojie.Postbuckling analysis of composite laminates with delamination damage[J]. Acta Aeronautica et Astronautica Sinica,1999, 20(3):224-229.(in Chinese)
[12]	张凤鹏,黄宝宗,牛晚扬,等.非线性复合材料层板分层屈曲及后屈曲分析[J].东北大学学报,2000,21(3):343- 346. ZHANG Fengpeng,HUANG Baozong,NIU Wanyang,et al.Bucking and postbucking analysis of nonlinear composite laminates with delamination[J].Journal of Northeastern University,2000,21(3):343-346.(in Chinese)
