2.5维C/SiC复合材料单胞模型及刚度预测
Unit cell of 2.5 dimension C/SiC and its stiffness prediction
-
摘要: 通过提取2.5维C/SiC复合材料经纱边界曲线,采用鲁棒最小二乘拟合得到了经纱轴向函数表达式,对拟合后的曲线进行合理简化,建立了参数化的2.5维C/SiC复合材料的有限元模型.采用双尺度模型对2.5维C/SiC复合材料进行刚度预测,分别为考虑纤维/基体/孔隙的微观尺度和考虑经纱/纬纱/孔隙的单胞尺度模型,刚度预测的方法采用刚度平均法和能量法.最后讨论了微观尺度的孔隙率对2.5维C/SiC复合材料弹性模量的影响.结果表明,刚度平均法和能量法的计算结果差异较小,考虑微观孔隙率后,计算结果与试验结果吻合得更好.
-
关键词:
- 2.5维C/SiC复合材料 /
- 鲁棒最小二乘 /
- 双尺度模型 /
- 刚度平均法 /
- 孔隙率
Abstract: A kind of unit cell for 2.5 dimension C/SiC composites was established by extracting the boundary of warp,fitting the curve using robust least square and simplifying the fitted curve.The elastic properties of 2.5 dimension C/SiC composites were predicted using dual-scale model;the dual-scale model was micro-scale which considered the scale of matrix/fiber/pore,and also meso-scale which considered the scale of warp/weft/cavity.The method for predicting the elastic properties of 2.5 dimension C/SiC composites was stiffness average method and energy method;finally the relationship between the porosity in the micro-scale and the elastic properties of 2.5 dimension C/SiC composites was discussed.Numerical results show that the theoretical results using energy method and stiffness average method have little difference;when considering the micro-scale porosity,the theoretical results can fit the experimental results better.-
Key words:
- 2.5 dimension C/SiC composites /
- robust least square /
- dual-scale model /
-
[1] Dalmaz A,Ducret D,Guerjouma R E,et al.Elastic moduli of a 2.5D Cf/SiC composite:experimental and theoretical estimates[J].Composites Science and Technology,2000,60(6):913-925. [2] 常岩军,矫桂琼,王波,等.倾斜内锁型三维机织陶瓷基复合材料的细观力学模型[J].应用力学学报,2007,24(1):146-150. CHANG Yanjun,JIAO Guiqiong,WANG Bo,et al.Micromechanical model for elastic properties of 3D angle-interlock woven ceremic composites[J].Chinese Journal of Applied Mechanics,2007,24(1):146-150.(in Chinese) [3] 董伟锋,肖军,李勇,等.2.5维编织复合材料弹性性能的理论研究[J]. 南京航空航天大学学报,2005,37(5):659- 663. DONG Weifeng,XIAO Jun,LI Yong,et al.Theoretical study on elastic properties of 2.5D braided composites[J].Journal of Nanjing University of Aeronautics & Astronautics,2005,37(5):659-663.(in Chinese) [4] 郑君,温卫东,崔海涛,等.2.5维机织结构复合材料的弹性性能预测[J].航空动力学报,2008,23(11):2031-2035. ZHENG Jun,WEN Weidong,CUI Haitao,et al.Elastic property prediction of 2. 5 dimensional woven structures[J].Journal of Aerospace Power, 2008,23(11):2031-2035. (in Chinese) [5] 杨振宇,俸翔,苏洲,等.2.5D编织复合材料细观结构及弹性性能[J].宇航材料工艺,2010,40(2):67-71. YANG Zhenyu,FENG Xiang,SU Zhou,et al.Meso-structure and elastic properties of 2.5D braided composites[J].Aerospace Materials & Technology,2010,40(2):67-71.(in Chinese) [6] Vandeurzen P,Ivens J,Verpoest I.A three-dimensional micromechanical analysis of woven-fabric composites Ⅱ:elastic analysis[J].Composites Science and Technology,1996,56(11):1317-1327. [7] Chang Y,Jiao G,Wang B,et al.Elastic behavior analysis of 3D angle-interlock woven ceramic composites[J].Acta Mechanica Solida Sinica,2006,19(2):152-159. [8] Whitney T J,Chou T W.Modeling of three-dimensional angle-interlock textile structural composite[J].Journal of Composite Materials,1989,23(9):890-911. [9] Byun J H,Chou T W.Elastic properties of three-dimensional angle-interlock fabric perform[J].Journal of Textile Institute.1990,81(4):538-548. [10] Ayranci C,Carey J.2D braided composites:a review for stiffness critical applications[J].Composite Structures,2008, 85(1):43-58. [11] Ivanov D,Ivanov S,Lomov S,et al.Strain mapping analysis of textile compositesnext term[J].Optics and Lasers in Engineering,2008,47(3-4):360-370. [12] Lomov S V,Ivanov D S,Verpoest I,et al.Full-field strain measurements for validation of meso-FE analysis of textile composites[J].Composites Part A:Applied Science and Manufacturing,2008,39(8):1218-1231. [13] 许英杰,张卫红,杨军刚.平纹机织多元多层碳化硅陶瓷基复合材料的等效弹性模量预测[J].航空学报,2008,29(5):1350-1355. XU Yingjie,ZHANG Weihong,YANG Jungang,et al.Prediction of effective elastic modulus of plain weave multi-phase and multi-layer silicon carbide ceramic matrix composite[J].Acta Aeronautica et Astronautica Sinica,2008,29(5):1350-1355.(in Chinese) [14] 汪海滨,张卫红,许英杰.C/C-SiC机织复合材料尺度参数对力学性能的影响[J].复合材料学报, 2010,27(5):93-100. WANG Haibin,ZHANG Weihong,XU Yingjie.Effects of different scale parameters on effective modulus of woven C/C-SiC composites[J].Acta Materiae Compositae Sinica,2010,27(5):93-100.(in Chinese) [15] Dong W F,Xiao J,Li Y.Finite element analysis of the tensile properties of 2.5D braided composites[J].Materials Science and Engineering:A,2007,457(1-2):199-204. [16] 赵冬青,赵振峰.基于改进鲁棒最小二乘法的发动机试验数据处理[J].中北大学学报(自然科学版),2009,30(4):338-342. ZHAO Dongqing,ZHAO Zhenfeng.Application of improved robust least-square method to experimental data processing of engine[J].Journal of North University of China (Natural Science Edition),2009,30(4):338-342.(in Chinese) [17] Puglia P D,Sheikh M A,Hayhurst D R.Classification and quantification of initial porosity in a CMC laminate[J].Composites Part A:Applied Science and Manufacturing,2004,35(2):223-230.
