脉冲爆震燃烧室管壁冲击冷却效果的数值研究

王杏涛; 张靖周; 谭晓茗

脉冲爆震燃烧室管壁冲击冷却效果的数值研究

基金项目: 国家自然科学基金(50876041); 航空科学基金(2008ZB52014)

计量
- 文章访问数: 1791
- HTML浏览量: 108
- PDF量: 55
- 被引次数: 0
出版历程
- 收稿日期: 2010-11-15
- 修回日期: 2011-02-12
- 刊出日期: 2011-11-28

Numerical simulation on impingement cooling characteristics of pulsed detonation tube

摘要

摘要: 根据实验测量的脉冲爆震燃烧室壁温沿程分布,推算出符合脉冲爆震燃烧室特定频率下的准稳态热流阶梯分布;在此基础上,针对叉排阵列射流冲击冷却的脉冲爆震燃烧室壁面温度分布进行了数值计算.研究表明,由于冷却气流通道端壁效应的影响,靠近爆震燃烧室尾部的射流孔的冲击射流速度较大,热流最大的燃烧室尾部管壁的温度可以得到有效的降低,而燃烧室中部的射流由于受到前排射流形成的横流影响,对管壁的冲击冷却效果较弱,使得壁面温度的峰值向中部转移.在相同的环形冷却通道进口雷诺数下,阵列射流孔宜布置在脉冲爆震燃烧室中部,射流冲击间距比Z_n/d=1.5时,管壁的峰值温度最低而且整体的平均温度最小,较小的冲击孔直径对应的冲击冷却效果较好.
- 脉冲爆震燃烧室 /
- 冲击射流 /
- 强化传热 /
- 壁面冷却 /
- 数值模拟
Abstract: According to axial wall temperature distributions on pulsed detonation chamber wall measured from experiment,the quasi-steady state heat flux along the detonation tube with ladder distribution was deduced under a specific frequency.Based on the quasi-steady thermal load,a series of computations were conducted to analyze the cooling effects with array jet impingement.The results show that:the jet velocity from rear rows is bigger than that from the front rows due to end wall effects,the cooling action is stronger near the pulsed detonation tube edge,and the impingement cooling effect is worse in the middle part because the impinging jet is weakened by cross-flow forming from the front rows.Under the same cooling flow Reynolds number at circular passage inlet,the array jet holes are reasonably arranged at middle area of pulsed detonation chamber.When the ratio of the impinging space to diameter is 1.5,the cooling effect seems to be best with uniform axial temperature distribution and lowest peak temperature.And smaller diameter of the cooling holes is also beneficial to improving the cooling effects.
- pulsed detonation chamber /
- jet impingement /
- enhanced heat transfer /

HTML

参考文献(16)

[1]	严传俊,范玮.脉冲爆震发动机原理及关键技术[M].西安:西北工业大学出版社,2005.
[2]	Dean A J.A review of of PDE development for propulsion application .AIAA Paper 2007-985,2007.
[3]	黄希桥,严传俊,范玮,等.脉冲爆震燃烧效率的探索性试验研究[J].航空动力学报,2006,21(6):962-966. HUANG Xiqiao,YAN Chuanjun,FAN Wei,et al.Preliminary experimental study of pulse detonation combustion efficiency[J].Journal of Aerospace Power,2006,21(6):962-966.(in Chinese)
[4]	张义宁,王家骅,张靖周.两相多循环爆震波特性研究[J].航空动力学报,2006,21(5):789-794. ZHANG Yining,WANG Jiahua,ZHANG Jingzhou.Investigation of two-phase and multi-cycle detonation[J].Journal of Aerospace Power,2006,21(5):789-794.(in Chinese)
[5]	Hoke J,Bradley R,Schauer F.Heat transfer and thermal management in a pulsed detonation engine .AIAA Paper 2003-6486,2003.
[6]	Kasahara J,Takazava T,Arai T,et al.Experimental study of impulse and heat transfer on pulse detonation engines .AIAA Paper 2002-4071,2002.
[7]	郑龙席,严传俊,范玮,等.脉冲爆震发动机模型机爆震室壁温分布试验研究[J].燃烧科学与技术,2003,9(4):344-347. ZHENG Longxi,YAN Chuanjun,FAN Wei,et al.Experimental investigation on outer wall temperature distribution of a pulsed detonation engine model[J].Journal of Combustion Science and Technology,2003,9(4):344-347.(in Chinese)
[8]	郑龙席,严传俊,李牧.多循环PDE模型机爆震室壁温分布数值模拟[J].燃烧科学与技术,2007,13(5):414-420. ZHENG Longxi,YAN Chuanjun,LI Mu.Numerical simulation on detonation chamber wall temperature distribution of a multi-cycle pulse detonation engine model[J].Journal of Combustion Science and Technology,2007,13(5):414-420.(in Chinese)
[9]	宫继双,范育新,王家骅,等.爆震管壁面热负荷实验研究[J].航空动力学报,2009,24(9):1952-1958. GONG Jishuang,FAN Yuxin,WANG Jiahua,et al.Experimental study on heat load of detonation tube[J].Journal of Aerospace Power,2009,24(9):1952-1958.(in Chinese)
[10]	Ghosn L J, Zhu D.Thermal barrier and protective coating to improve the durability of a combustor under a pulse detonation engine enviroment .AIAA Paper 2007-2070, 2007.
[11]	Ajmani K,Breisacher K J.Multi-cycle analysis of an ejector-cooled pulse detonation device .AIAA Paper 2004-3915,2004.
[12]	Ajmani K,Breisacher K J,Ghosn L J,et al.Numerical and experimental studies of a film cooled pulsed detonation tube .AIAA Paper 2005-3059,2005.
[13]	涂洪妍,范玮,范珍涔,等.基于主动冷却的爆震爆震火箭发动机燃油加温实验研究[J].航空工程进展,2010,1(1):95-98. TU Hongyan,FAN Wei,FAN Zhencen,et al.The experimental of fule-heating based on active cooling in pulse detonation rocket engines[J].Advances in Aeronautical Science and Engineering,2010,1(1):95-98.(in Chinese)
[14]	范育新,王家骅,宫继双,等.壁温蒸发器对脉冲爆震发动机工作性能的影响[J].航空学报,2010,31(1):82-87. FAN Yuxin,WANG Jiahua,GONG Jishuang,et al.Effects of wall-evaporator on performance of a pulse detonation engine[J].Acta Aeronautica et Astronautica Sinica,2010,31(1):82-87.(in Chinese)
[15]	张靖周,李永康,谭晓茗,等.阵列射流冲击冷却局部对流换热特性的数值计算与试验验证[J].航空学报,2004,25(4): 339-342. ZHANG Jingzhou,LI Yongkang,TAN Xiaoming,et al.Numerical computation and experimental investigation on local convective heat transfer characteristics for jet array impingement[J].Acta Aeronautica et Astronautica Sinica,2004,25(4):339-342.(in Chinese)
[16]	谭蕾,张靖周,杨卫华.半封闭肋化通道射流冲击换热特性的数值研究与实验验证[J].航空学报,2008,29(5):1105- 1111. TAN Lei,ZHANG Jingzhou,YANG Weihua. Numerical computation and experimental examination of convective heat transfer characteristics of jet impingement inside semi-confined rib-roughed channel[J].Acta Aeronautica et Astronautica Sinica,2008,29(5):1105-1111.(in Chinese)
