摇摆载荷作用下舰载固体火箭发动机药柱疲劳损伤
Fatigue damage of shipborne solid rocket motor propellant under swing loading
-
摘要: 以某固体火箭发动机为例,建立了摇摆载荷作用下发动机药柱的疲劳损伤评估方法.首先,通过推进剂定应力往复拉伸试验获得了复合固体推进剂的疲劳损伤特性;其次,运用有限元分析方法得到了发动机危险部位的应力谱;最后,运用雨流计数法和Miner线性累积损伤理论对发动机危险部位的损伤进行了评估.结果表明,发动机装药危险部位一年时间由于舰船摇摆载荷所造成的损伤为0.0855.Abstract: A fatigue damage evaluation method of propellant under swing loading was established for some solid rocket motor(SRM).Firstly,the fatigue damage property of composite solid propellant was acquired by fixed stress amplitude cycle loading experiment.Secondly,the stress spectrums of SRM nodes with time were obtained by method of finite element analysis.Finally,the rain-flowing counting method and the Miner's linear cumulative damage theory were applied to evaluate the fatigue damage of SRM.The results show that the fatigue damage of motor's dangerous area reaches 0.0855 by ship motion loading across a year.
-
Key words:
- shipborne missile /
- solid rocket motor(SRM) /
- finite element analysis /
-
[1] Heller R A,Thangjitham S,Janajreh I M.Probabilistic service life prediction for solid propellant motors subjected to environmental thermal loads .Greece:Athens,North Atlantic Treaty Organization,1996. [2] Maxey I H.Environmental data for rocket motor service life assessment .Greece:Athens,North Atlantic Treaty Organization,1996. [3] Holl G,Wilker S,Kaiser M,et al.Former and modern method for the determination of the service life of rocket propellant .Greece:Athens,North Atlantic Treaty Organization,1996. [4] 王玉峰,李高春,王晓伟.固体火箭发动机海洋环境下的贮存及寿命预估[J].火炸药学报,2008,31(6):87-90. WANG Yufeng,LI Gaochun,WANG Xiaowei.Storage and life prediction of solid rocket motor in sea environment[J].Chinese Journal of Explosives & Propellants,2008,31(6):87-90.(in Chinese) [5] 徐明.舰载摇摆载荷作用下固体发动机界面老化分析研究 .烟台:海军航空工程学院,2008. XU Ming.Research on linear aging of solid motor under the influence of ship swing load .Yantai:Naval Aeronautical and Astronautical University,2008.(in Chinese) [6] 许俊松.舰船摇摆运动载荷作用下固体发动机装药基于耗散能的寿命预估 .烟台:海军航空工程学院,2009. XU Junsong.Life prediction of solid motor grain under the influence of ship swing load based on the dissipated energy method .Yantai:Naval Aeronautical and Astronautical University,2009.(in Chinese) [7] 徐金洲,贾东明.舰上导弹固体火箭发动机贮存寿命的分析方法研究[J].固体火箭技术,2009,32(3):271-273. XU Jinzhou,JIA Dongming.Reasearch of analysis method for strorage life of SRM[J].Journal of Solid Rocket Technology,2009,32(3):271-273.(in Chinese) [8] 高凤云,丁华亭.QJ924285.复合固体推进剂单向拉伸试验方法[S].北京:航天工业部,1992:1-5. [9] Scott M.Non-linear rolling of ships in large sea waves .Monterey:Naval Postgraduate School,2007. [10] 李舜酩.机械疲劳与可靠性设计[M].北京:科学出版社, 2006. [11] Laheru K L.Development of a generalized failure criterion for viscoelastic materials[J].Journal of Propulsion and Power,1992,8(4):756-759. [12] 邢耀国,董可海,沈伟,等.固体火箭发动机使用工程[M].北京:国防工业出版社,2010.
