定向凝固涡轮叶片不同部位材料持久强度差异

邓瑛; 孙瑞杰; 谢建文; 闫晓军

定向凝固涡轮叶片不同部位材料持久强度差异

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家自然科学基金(10872015); 航空科学基金(2008ZB51017)

计量
- 文章访问数: 1465
- HTML浏览量: 60
- PDF量: 436
- 被引次数: 0
出版历程
- 收稿日期: 2011-01-30
- 修回日期: 2011-05-13
- 刊出日期: 2012-01-28

Creep property variation at different regions on a directionally solidified turbine blade

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 为了研究定向凝固涡轮叶片因不同部位显微组织不同而引起的宏观持久强度的差异,根据典型涡轮叶片几何特征,设计了两类叶片模拟件(缘板、叶冠模拟件)和对比试件(标准平板试件),开展了持久试验及对比研究,试验结果表明:缘板、叶冠模拟件的持久寿命分别为对比试件持久寿命的94.22%和75.65%.这说明了定向凝固涡轮叶片不同部位的持久强度存在差异,这种差异需要在定向凝固涡轮叶片结构、寿命设计中加以考虑.研究结果对提高定向凝固涡轮叶片设计水平、改进定向凝固成形工艺具有重要意义.
- 定向凝固 /
- 涡轮叶片 /
- 持久强度 /
- 叶片模拟件 /
- 显微组织
Abstract: In order to study the creep property variation at different regions on a directionally solidified (DS) turbine blade caused by microstructure difference among those regions,three types of DS specimen (platform-like specimen,shroud-like specimen and sheet specimen) were presented to investigate the difference by creep rupture tests at elevated temperature.The tests data shows that the performance of platform-like specimen and shroud-like specimen are 94.22% and 75.65% of sheet specimens' performance,respectively.Therefore,the difference of creep property among different regions on a DS turbine blade should be considered in blade structure design and creep life assessment.The research results may also help to improve the manufacture processes of directional solidification.
- directionally solidification(DS) /
- turbine blade /
- creep strength /
- blade-like specimen /
- microstructure

HTML

参考文献(17)

[1]	《机械工程材料性能数据手册》编委会.机械工程材料性能数据手册[M].北京:机械工业出版社,1995.
[2]	Marahleh G,Kheder A R,Hamad H F.Creep life prediction of service-exposed turbine blades[J].Materials Science and Engineering A,2006,433(1-2):305-309.
[3]	Sherby O D,Taleff E M.Influence of grain size,solute atoms and second-phase particles on creep behavior of polycrystalline solids[J].Materials Science and Engineering A,2002,322(1-2):89-99.
[4]	陈荣章.航空铸造涡轮叶片合金和工艺发展的回顾与展望[J].航空制造技术,2002(2):18-24. CHEN Rongzhang.Review and prospect of developments of cast super-alloys and technology of aeroengine turbine blade[J].Aeronautical Manufacturing Technology,2002(2): 18-24.(in Chinese)
[5]	胡壮麒,刘丽荣,金涛,等.镍基单晶高温合金的发展[J].航空发动机,2005,31(3):1-7. HU Zhuangqi,LIU Lirong,JIN Tao,et al.Development of the Ni-base single crystal superalloys[J].Aeroengine,2005, 31(3):1-7.(in chinese)
[6]	Yang X L,Dong H B,Wang W,et al.Microscale simulation of stray grain formation in investment cast turbine blades[J].Material Science and Engineering,2004,386(1-2):129-139.
[7]	许庆彦,熊守美,柳百成.铸造合金的微观组织模拟研究进展[J].材料导报,2002,16(1):11-14. XU Qingyan,XIONG Shoumei,LIU Baicheng.Advances in microstructure simulation of casting alloy[J].Materials Review,2002,16(1):11-14.(in chinese)
[8]	岳珠峰,吕震宙,杨治国,等.晶体取向的偏差和随机性对镍基单晶叶片强度与蠕变寿命的影响[J].航空动力学报,2003,18(4):477-480. YUE Zhufeng,LU Zhenzhou,YANG Zhiguo,et al.Influence of deviation and randomness of crystallographic orientations on the strength and life of nickel-base single crystal superalloy turbine blades[J].Journal of Aerospace Power,2003,18(4):477-480.(in Chinese)
[9]	Arakere N K,Swanson G.Effect of crystal orientation on fatigue failure of single crystal nickel base turbine blade superalloys[J].Journal of Engineering for Gas Turbines and Power,2002,124(1):161-176.
[10]	Zhao Y,Wang L,Li H Y,et al.Effects of recrystallization on the low cycle fatigue behavior of directionally solidified superalloy DZ40M[J].Rare Metals,2008,27(4):425-428.
[11]	Alexandre F,Deyber S,Pineau A.Modeling the optimum grain size on the low cycle fatigue life of a Ni-based superalloy in the presence of two possible crack initiation sites[J].Scripta Materialia,2004,50(1):25-30.
[12]	Wang W,Kermanpur A,Lee P D,et al.Simulation of dendritic growth in the platform region of single crystal superalloy turbine blades[J].Journal of Materials Science,2003,38(21):4385-4391.
[13]	Wang W,Lee P D,McLean M.A model of solidification microstructures in nickel-based superalloys:predicting primary dendrite spacing selection[J].Acta Material,2003,51(10):2971-2987.
[14]	孙瑞杰,闫晓军,聂景旭.定向凝固涡轮叶片高温低周疲劳的破坏特点[J].航空学报,2011,32(2):337-343. SUN Ruijie,YAN Xiaojun,NIE Jingxu.Failure characteristics of directional solidification turbine blade under high temperature low cycle fatigue load[J].Acta Aeronautica et Astronautica Sinica,2011,32(2):337-343.(in Chinese)
[15]	冯广召,沈军,邹敏佳,等.抽拉速度对高温合金DZ125定向凝固中缩松的影响[J].铸造,2009,58(5):427-430. FENG Guangzhao,SHEN Jun,ZOU Minjia,et al.Influence of withdrawal rate on the micro-porosity of super-alloy DZ125 in directional solidification[J].Foundry,2009,58(5):427-430.(in Chinese)
[16]	Yue Z F,Lu Z Z,Zheng C Q,et al.Life study of nickel-based single crystal turbine blades:viscoplastic ctrystallographic constitutive behavior[J].Theoretical and Applied Fracture Mechanics,1996,24(2):139-145.
[17]	Chen L J,Liu Y H,Xie L Y.Power-exponent function model for low-cycle fatigue life prediction and its applications[J].International Journal of Fatigue,2007,29(1):1-9.
