CRGT循环燃气轮机性能仿真
Simulation research of the CRGT cycle gas turbine performance
-
摘要: 采用VC和MATLAB混合编程方法,进行了不同循环燃气轮机的变工况性能分析.其中,采用修正工程算法编制了工质热力性质计算程序,采用反向传播(BP)神经网络法建立了压气机和涡轮部件特性计算模型,采用模块化建模方法建立了简单循环、蒸汽回注(STIG)循环和化学回热(CRGT)循环性能仿真模型.仿真结果表明:在保持燃机几何结构和设计功率不变的条件下,STIG循环和CRGT循环均能降低燃气初温和提高循环热效率.其中,简单循环的热效率为35.16%,STIG循环的热效率可达到45%,CRGT循环的热效率可达到52.8%;为了进一步提高该型燃机的应用潜力和使用范围,可以将该型CRGT循环燃气轮机用于海水淡化应用中.
-
关键词:
- 化学回热(CRGT)循环 /
- 混合编程 /
- 反向传播 (BP) 神经网络法 /
- 模块化建模 /
- 性能仿真
Abstract: Design and off-design performance of the different cycle in one certain three -spool gas turbine,with the combination programming method of VC and MATLAB was analyzed.Among it,used the modification engineering algorithm method to program the computation procedure of the working medium's thermodynamic properties,used the BP (back propagation) neural network method to build the calculation models of the compressor and turbine component characteristics;used the modular modeling method to build the dynamic simulation models of the simple cycle,the STIG(steam injection gas turbine) cycle and the CRGT(chemically recuperated gas turbine) cycle.The calculation results show that the STIG cycle and CRGT cycle can both reduce the combustor exit temperature and improve total thermal efficiency,in which the simple cycle's efficiency was 35.16%,the STIG cycle was 45% and the CRGT cycle was 52.8%;and in order to ensure the efficiency and the application areas,this CRGT cycle units can be used in the seawater desalination systems,under the safe operation areas and without the redesign of the components. -
[1] Jonsson M,Yan J Y.Humidified gas turbines a review of proposed and implemented cycles[J].Energy,2005,30(7):1013-1078. [2] Poullikka S A.An overview of current and future sustainable gas turbine technologies[J].Renewableand Suatainable Energy Reviews,2005,9(5):409-443. [3] Saad M A,Cheng D Y.The new LM2500 cheng cycle for power generation and cogeneration[J].Energy Conver Manage,1997,38(15):1637-1646. [4] Camporeale S M,Fortunato B.Performance of a mixed gassteam cycle power plant obtained upgrading an aer-oderivative gas turbine[J].Energy Conver Manage,1998,39(16):1683-1692. [5] Kesser K F,Hoffman M A,Baughn J W.Analysis of a basic chemically recuperated gas turbine power plant[J].Journal of Engineering for Gas Turbines and Power,1994,116(2):277-284. [6] Abdallah H,Harvey S.Thermodynamic analysis of chemically recuperated gas turbines[J].Int Therm Sci,2001,40(4):372-384. [7] 刘志刚.工质热物理性质计算程序的编制及应用[M].北京:科学出版社,1992. [8] 瓦格纳,克鲁泽.水和蒸汽的性质[M].北京:科学出版社,2003. [9] Tirnovan R,Giurgea S,Miraoui A,et al.Modeling the ch-aracteristics of turbo-compressors for fuel-cell systems using hybrid method based on moving-least squares[J].Applied Energy,2009,86(7):1283-1289. [10] Ghorbanian K,Gholamrezaei M.An artificial neural netw-ork approach to compressor performance prediction[J].Applied Energy,2009,86(7):1210-1221. [11] 冯凤珍,孙允标,余又红.基于神经网络的压气机特性计算新方法[J].计算机与数字工程,2004,32(6):45-47. FENG Fengzhen,SUN Yunbiao,YU Youhong.A new approach of characteristic map calculating of compressor based on neural network[J].Computer & Digital Engineering,2004,32(6):45-47.(in Chinese). [12] Cortes O,Urquiza G,Hernandez J.Optimzation of operati-ng conditions for compressor performance by meansof neural network inverse[J].Applied Energy,2009,86(11):2487-2493. [13] Gońzalez J A,Sala J M,López L M,et al.Modelling and dynamic simulation of processes with‘MATLAB’:an application of a natural gas installation in a power plant[J].Energy,2007,32(7):1271-1282. [14] Carapellucci R,Milazzo A.Thermodynamic optimization of a reheat chemically recuperated gas turbine[J].Energy Conversion and Management,2005,46(18):2936-2953. [15] 肖琳.气垫船用三轴燃气轮机推进系统动态性能研究.上海:上海交通大学,2007. XIAO Lin.Research on systemic performance of hovercraft gas turbine propulsion.Shanghai:Shanghai Jiao Tong University,2007. [16] 李传军.C语言与MATLAB接口编程与实例[M].北京:北京邮电大学出版社,2004.
