基于状态空间法的低马赫数翼型气动载荷计算

邵松; 朱清华; 张呈林; 倪先平

基于状态空间法的低马赫数翼型气动载荷计算

南京航空航天大学航空宇航学院直升机旋翼动力学重点实验室,南京 210016

基金项目: 航空科学基金(08A52003); 南京航空航天大学基本科研业务费专项科研项目(NS2010035)

计量
- 文章访问数: 1957
- HTML浏览量: 135
- PDF量: 566
- 被引次数: 0
出版历程
- 收稿日期: 2011-01-25
- 修回日期: 2011-11-03
- 刊出日期: 2012-01-28

Prediction of airfoil airload at low Mach numbers based on state space formulation

Science and Technology on Rotorcraft Aeromechanics Laboratory, College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: Leishman-Beddoes(L-B)非定常动态失速模型适用于中等马赫数(Ma>0.3),而在低马赫条件(Ma<0.3)下存在与翼型气动试验数据不符合的问题,为此首先研究了低马赫数条件下翼型的非定常动态失速气动特性,其次采用状态空间法从翼型表面气流变化的角度修正了L-B模型,最后通过与翼型气动载荷试验数据的对比表明在低马赫数条件下对L-B模型的修正是正确的,能够准确预测及分析翼型的气动载荷,且该修正模型易于耦合进直升机综合分析代码中.
- 非定常 /
- 动态失速 /
- 状态空间 /
- 低马赫数 /
- 翼型气动载荷
Abstract: The Leishman-Beddoes (L-B) unsteady and dynamic stall model is applicable to the medium Mach numbers(Ma>0.3),and some inconsistent problems for predicting airfoil airload when comparing with airfoil airload test data at low Mach numbers (Ma<0.3),so firstly the unsteady and dynamic stall aerodynamic behavior of airfoil at low Mach numbers was investigated,secondly the modified L-B model was set from the viewpoint of the variation of the flow on the airfoil surface,finally the comparisons between the modified L-B and airfoil airload test data at low Mach numbers show that the modified L-B model with state space formulation is accurate and can be used to predict the airfoil airload at low Mach numbers,and also it can be easily incorporated into a helicopter comprehensive code.
- unsteady /
- dynamic stall /
- state space /
- low Mach number /
- airfoil airload
