主要几何参数对叶栅式反推力装置性能的影响
Influence of cascade configuration on aerodynamic performance of a cascade thrust reverser
-
摘要: 选取等厚叶栅进行数值模拟,采用混合网格生成技术,研究叶栅进口气流角、过渡段半径、叶片上下端轴向间距、稠密度和出口气流角对空气流量和轴向反推力的影响.计算结果表明:进口气流角、过渡段半径和叶片上下端轴向间距对风扇气流能否顺利导入叶栅起重要作用;稠密度影响着叶栅的出口面积和导流性能;出口气流角是反推力装置设计的关键因素,对反推性能起着决定性的作用.Abstract: The study chose equal-thickness shaped cascade blades,with the technology of hybrid grid system,and studied the influence of inlet flow angle,transition-radius,axial space between upside and underside of vane,solidity and outlet flow angle on the mass flow and axial reverser thrust.The final computation results show:the inlet flow angle,transition-radius,axial space between upside and underside of vane play the important role in whether the fan flow inducts the cascade smoothly;the solidity affects the outlet area and diverted performance of cascade;the outlet flow angle is a key-factor of design of the cascade thrust reverser,so it gives direction to the aerodynamic performance of a cascade thrust reverser.
-
Key words:
- cascade thrust reverser /
- cascade configuration /
- consistency /
- mass flow /
- axial reverser thrust
-
[1] Jeffrey A.Why do airlines want and use thrust reversers.NASA TM-109158,1995. [2] Chuck C.Computational procedures for complex three-dimensional geometries including thrust-reverser effluxes and APU.AIAA-2001-3747,2001. [3] John H P,Fred W,Jack G,et al.Summary of scale-model thrust-reverser investigation.NACA TN 3664,1956. [4] Dietrich D A,Gutierrez O A.Performance of a cascade thrust reverser for short-haul applications.AIAA-1974-1171,1974. [5] Butterfield J,Yao H,Price M,et al.Methodologies for structural optimization of a thrust reverser cascade using a multidisciplinary approach.AIAA-2003-107,2003. [6] Butterfield J,Yao H,Armstrong C,et al.Weight reduction methodologies for a thrust reverser cascade using aerodynamic and structural integration[J].Journal of Aerospace Engineering,2004,218(5):301-313. [7] Dietrich D A,Crooker A J.Effect on fan flow characteristics of length and axial location of a cascade thrust reverser.NASA TM X-3247,1975. [8] Yao H,Cooper R K.Numerical simulation on flow fields of the nature blockage thrust reverser.AIAA-2005-631,2005. [9] Scott C A,Jeffrey A Y.Static performance of six innovative thrust reverser concepts for subsonic transport applications.NASA/TM-2000-210300,2000. [10] Luis G T,Guilherme L O.Aircraft thrust reverser cascade configuration evaluation through cfd.AIAA-2003-723,2003. [11] 陈懋章.粘性流体动力学基础[M].北京:高等教育出版社,2002. [12] James G H,Jack G M.Preliminary performance date of several tail-pipe cascade-type model thrust reversers.NACA RM E55F09,1955.
