叶尖间隙高度对某高压涡轮级损失分布的影响

王大磊; 朴英

叶尖间隙高度对某高压涡轮级损失分布的影响

王大磊,
朴英

清华大学航天航空学院,北京 100084

计量
- 文章访问数: 1914
- HTML浏览量: 245
- PDF量: 456
- 被引次数: 0
出版历程
- 收稿日期: 2011-01-13
- 修回日期: 2011-06-29
- 刊出日期: 2012-01-28

Influence of tip clearance size on flow losses of a transonic high pressure turbine stage

School of Aerospace, Tsinghua University, Beijing 100084, China

摘要

摘要: 利用三维湍流数值模拟方法模拟某一级跨声速高压涡轮流场,研究转子叶片叶尖间隙高度对涡轮性能及二次流动损失分布的影响.研究结果表明:转子叶尖间隙高度对涡轮性能影响明显,随着间隙高度的增加涡轮效率明显降低,但效率的降低速度与间隙高度并非简单线性关系,间隙高度增加1%相对叶高,涡轮性能最快下降1.8%.分析表明:涡轮转子间隙高度变化主要影响转子叶栅通道上部流动并对通道内的损失分布产生影响.其中损失最严重的区域为转子通道中部至叶片尾缘处;尾缘后的损失则对间隙的高度最敏感,随着间隙高度的增加,叶片尾缘后损失明显增加.
- 航空发动机 /
- 高压涡轮级 /
- 叶尖间隙 /
- 流动损失 /
- 数值模拟
Abstract: The influence of the tip clearance height of turbine rotor blades on the aerodynamic performance and secondary flow losses of an axial turbine stage were investigated by numerical simulation and different tip clearance heights were taken into account.Results show that the efficiency of the turbine stage would decrease markedly due to the increase of the tip clearance height.The efficiency would decrease 1.8% as the tip clearance height increased 1% of blade relative height.Analyses of the rotor flow field indicated that as the height if tip clearance increased,the distribution of flow losses changed in the upper passage of the rotor.The most losses were induced in the region between the middle of the rotor blade and the trailing edge,while secondary flow losses increased most behind the trailing edge.Mixing losses were the main factors which led to the efficiency decreased as the height of tip clearance increased.
- aero-engine /
- high pressure turbine stage /
- tip clearance /
- flow loss /
- numerical simulation

HTML

参考文献(18)

[1]	刘宝杰,邹正平.叶轮机计算流体动力学技术现状与发展趋势[J].航空学报,2002,23(5):394-404. LIU Baojie,ZOU Zhengping.Persent status and future development of CFD in turbomachnery[J].Acta Aeronautica et Astronautica Sinica,2002,23(5):394-404.(in Chinese)
[2]	Gümmer V,Goller M,Swoboda M.Numerical investigation of endwall boundary layer removal on highly-loaded axial compressor blade rows.ASME GT 2005-68699,2005.
[3]	Rao N M,Camci C.Axial turbine tip desensitization by injection from a tip trench Part 1:effect of injection mass flow rat.ASME GT 2004-53256,2004.
[4]	Rao N M,Camci C.Axial turbine tip desensitization by injection from a tip trench Part 2:leakage flow sensitivity to injection location.ASME GT 2004- 53258,2004.
[5]	Wiseman M W,Guo T H.An investigation of life extending control techniques for gas turbine engines //Proceedings of the American Control Conference.Arlington,VA:Institute of Electrical and Electronic Engineers,2001:3706-3707.
[6]	Bindon J P.The measurement and formation of tip clearance loss[J].ASME Journal of Turbomachinery,1989,111(3):257-263.
[7]	Yamamoto A.Endwall flow/loss mechanisms in a linear turbine cascade with blade tip clearance[J].ASME Journal of Turbomachinery,1989,111(2):246-275.
[8]	XIAO Xinwen,Andrew A.Tip clearance effects in a turbine rotor Part Ⅰ:pressure field and loss.ASME GT2001 ,2001.
[9]	Andrew A,XIAO Xinwen.Tip clearance effects in a turbine rotor flow Part Ⅱ:velocity field and physics.ASME GT2001,2001.
[10]	XIAO Xinwen.Investigation of tip clearance flow physics in axial flow turbine rotors.Pennsylvania:The Pennsylvania State University,2000.
[11]	Papa M,Goldstein R,Gori F.Effects of tip geometry and tip clearance on the mass/heat transfer from a large-scale gas turbine blade[J].ASME Journal of Turbomachinery,2003,125(1):91-96.
[12]	祁明旭,丰镇平.透平动叶顶部间隙流的表现形式及其对透平性能的影响[J].西安交通大学学报,2005,39(3):244-246. QI Mingxu,FENG Zhenping.Representation formation of tip clearance flow and influence on turbine performance[J].Journal of Xi'an Jiaotong University,2005,39(3):244-246.(in Chinese)
[13]	祁明旭,丰镇平.透平动叶顶部间隙流的端壁二次流结构研究[J].西安交通大学学报,2005,39(5):445-449. QI Mingxu,FENG Zhenping.Study on tip clearance flow of turbine blade-endwall secondary flow structure[J].Journal of Xi'an Jiaotong University,2005,39(5):445-449.(in Chinese)
[14]	许开福,乔渭阳.涡轮叶尖间隙流动的数值模拟[J].热能动力工程,2009,24(4):432-436. XU kaifu,QIAO Weiyang.Numerical simulation of turbine blade tip leakage flows [J].Jouranl of Engineering for Theamal Energy and Power,2009,24(4):432-436.(in Chinese)
[15]	ZHAO Qingjun,QIAO Jiafei.Influence of tip clearance size on flow characteristics of a vaneless counter rotating turbine.AIAA 2009-4836,2009.
[16]	牛茂升,藏述升.间隙高度对涡轮叶顶间隙流动的影响[J].工程热物理学报,2008,29(6):935-939. NIU Maosheng,ZANG Shusheng.Effect of tip clearance height on tip clearance flow in turbine rotors [J].Journal of Engineering Thermophysics,2008,29(6):935-939.(in Chinese)
[17]	黄忠湖,王月奇.叶尖间隙对跨音涡轮性能影响的试验研究[J].航空动力学报,1989,4(4):333-390. HUANG Zhonghu,WANG Yueqi.An experiment study of tip clearance effects on the performance of an axial transonic turbine[J].Journal of Aerospace Power,1989,4(4):333-390.(in Chinese)
[18]	赵旺东,周禹彬.叶尖间隙对涡轮气动性能影响的试验研究[J].燃气涡轮试验与研究,2009,22(3):19-22. ZHAO Wangdong,ZHOU Yubin.Effects of turbine tip clearance on gas turbine performance[J].Gas Turbine Experiment and Research,2009,22(3):19-22.(in Chinese)
