尾迹扫掠下超高负荷低压涡轮叶片附面层特性

李伟; 张波; 周敏; 卢新根; 朱俊强

尾迹扫掠下超高负荷低压涡轮叶片附面层特性

李伟^1,2,
张波^1,2,
周敏³,
卢新根¹,
朱俊强¹

1.
中国科学院工程热物理研究所轻型动力重点实验室,北京 100190
2.
中国科学院研究生院,北京 100190
3.
北京航空工程技术研究中心,北京 100076

基金项目: 国际科技合作项目(2010DFB70620); 国家自然科学基金(51176187)

计量
- 文章访问数: 1437
- HTML浏览量: 2
- PDF量: 539
- 被引次数: 0
出版历程
- 收稿日期: 2011-03-09
- 修回日期: 2011-07-14
- 刊出日期: 2012-01-28

Boundary layer behaviors on an ultra-high-lift low-pressure turbine profile under unsteady wakes

1.
Key Laboratory of Light-duty Gas-turbine, Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100190, China
3.
Beijing Aviation Engineering Research Center, Beijing 100076, China

摘要

摘要: 利用表面热膜测量上游尾迹周期性扫掠下某超高负荷低压涡轮叶片吸力面附面层的非定常流动特性.通过热膜测得的准壁面剪切力及其统计参数云图分析了尾迹与附面层的相互作用对分离、转捩及再附过程的影响.实验结果表明:对于低雷诺数Re超高负荷产生较大分离泡的情形,尾迹扫掠对涡轮叶片附面层的发展具有显著影响,能够有效地抑制附面层的流动分离.
- 尾迹扫掠 /
- 超高负荷 /
- 低压涡轮 /
- 转捩 /
- 表面热膜
Abstract: An experimental investigation on unsteady boundary layer behaviors of the suction surface of an ultra-high-lift low pressure turbine profile under periodically unsteady wakes was conducted with the help of surface-mounted hot film,and the influence of the wake-boundary layer interaction on the boundary layer separation,transition and reattachment was analyzed in detail with space-time (S-T) diagrams of quasi-wall shear stress and statistical parameters.The experimental results show that the wake has a significant influence on the boundary layer of turbine profile and the separation has been remarkably suppressed despite the larger separation bubble on the suction surface of ultra-high-lift profile at low Reynolds number.
- unsteady wake /
- ultra-high-lift /
- low-pressure turbine /
- transition /
- surface-mounted hot-film

HTML

参考文献(14)

[1]	Hodson H P ,Howell R J.The role of transition in high-lift low-pressure turbines for aeroengines[J].Progress in Aerospace Sciences,2005,41(6):419-454.
[2]	Kenneth W,Van T,Stephen T,et al.The challenges of high altitude gas turbine engine cycles.ASME Paper GT2010-23490,2010.
[3]	Mahallati A,Brian R,McAuliffe,et al.Aero dynamics of a low-pressure turbine airfoil at low-Reynolds number Part 1:steady flow measurements.ASME Paper GT2007-27347,2007.
[4]	Mahallati A,Steen A,Sjolander.Aero dynamics of a low-pressure turbine airfoil at low-Reynolds number Part 2:blade-wake interaction.ASME Paper GT2007-27348,2007.
[5]	ZHANG Xuefeng,Howard H P.Effects of Reynolds number and freestream turbulence intensity on the unsteady boundary layer development on an ultra-high-lift low pressure turbine airfoil[J].ASME,Journal of Turbomachinery,2010,132(1):011016(10 pages).
[6]	Darius D,Sanders,Chase A,et al.A CFD and experimental investigation of unsteady wake effects on a highly loaded low pressure turbine blade at low Reynolds number.ASME Paper GT2010-22977,2010.
[7]	张伟昊,刘火星,李维,等.尾迹与涡轮叶栅附面层的相互作用[J].航空动力学报,2009, 24 (4):844-850. ZHANG Weihao,LIU Huoxing,LI Wei,et al.Wake-boundary layer interaction on low pressure turbine cascade blades[J].Journal of Aerospace Power,2009,24(4):844-850.(in Chinese)
[8]	叶建,邹正平.低雷诺数下周期性尾迹/层流分离泡相互作用的大涡模拟[J].工程热物理学报,2007,28(2):215-218. YE Jian ,ZOU Zhengping.Large-eddy simulation of periodic wake/laminar separation bubble interaction under low Reynolds number conditions[J].Journal of Engineering Thermophysics,2007,28(2):215-218.(in Chinese)
[9]	Popovic I,ZHU Junqiang,Dai W,et al.Aerodynamics of a family of three highly loaded low-Pressure turbine airfoils:measured effects of Reynolds number and turbulence intensity in steady flow.ASME Paper GT2006-91271,2006.
[10]	雷志军,朱俊强,王明杰.低速压气机叶栅吸力面附面层分离的试验研究[J].工程热物理学报,2008,29(11):1839-1843. LEI Zhijun,ZHU Junqiang,WANG Mingjie.Experimental investigation on the suction surface boundary layer separation of a low-speed compressor cascade[J].Journal of Engineering Thermophysics,2008,29(11):1839-1843.(in Chinese)
[11]	Pfeil H,Herbst R.Transition procedure of instationary boundary layers.ASME Paper 79-GT-128,1979.
[12]	Funazaki K I,Shiba T.Effects of blade loading distribution on aerodynamic performance of ultra-high lift LP turbine airfoils under the influences of wake passing and freestream turbulence.ASME Paper GT2010-22134,2010.
[13]	李伟,朱俊强,李钢,等.基于表面热膜的超高负荷低压涡轮叶栅附面层特性[J].航空动力学报,2011,26(1):115-121. LI Wei,ZHU Junqiang,LI Gang.Experimental research for boundary layer behaviors on an ultra-high-lift low-pressure turbine profile based on surface hot-film[J].Journal of Aerospace Power,2011,26(1):115-121.(in Chinese)
[14]	Hodson H P,Dawes W N.On the interpretation of measured profile losses in unsteady wake-turbine blade interaction studies[J].ASME Journal of Turbomachinery,1998,120(2):276-284.
